Rear lamp/room lamp (4DR) Diagram Suzuki SX4
- Year
- -
- Sales region
- Africa
- drive
- 4WD
- transmission
- 5MT
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35650-80J60-000 LAMP UNIT,RR COMB,R |
35650-80J60-000 |
US $326.80 |
||
|
2
|
2
35670-80J70-000 LAMP UNIT,RR COMB,LH |
35670-80J70-000 |
US $218.96 |
||
|
3
|
3
09471-12192-000 BULB(12V21/5W) |
09471-12192-000 |
from US $3.19 |
||
|
4
|
4
09471-12191-000 BULB(12V21W) |
09471-12191-000 |
from US $3.87 |
||
|
5
|
5
09471-12202-000 BULB(12V21W/WY21W,AMBER) |
09471-12202-000 |
from US $5.76 |
||
|
6
|
6
09471-12216-000 BULB(12V5W)Bulb (12v5w) |
09471-12216-000 |
from US $2.84 |
||
|
7
|
7
35658-80J60-000 SOCKET&CORD ASSY |
35658-80J60-000 |
US $31.28 |
||
|
8
|
8
35658-80J60-000 SOCKET&CORD ASSY |
35658-80J60-000 |
US $31.28 |
||
|
9
|
9
35153-65J00-000 GROMMET,RR COMB LAMP |
35153-65J00-000 |
from US $1.60 |
||
|
10
|
10
08316-1005A-000 NUT |
08316-1005A-000 |
from US $0.77 |
||
|
11
|
11
35950-79J01-000
Reflector assy,rear,r
|
35950-79J01-000 |
— | ||
| replacement | |||||
|
11
|
11
35950-79J02-000 REFLECTOR ASSY,REAR |
35950-79J02-000 |
from US $9.74 |
||
|
12
|
12
35970-79J01-000
Reflector assy,rear,l
|
35970-79J01-000 |
— | ||
| replacement | |||||
|
12
|
12
35970-79J02-000 REFLECTOR ASSY,REAR |
35970-79J02-000 |
from US $9.95 |
||
|
13
|
13
03141-0516A-000 SCREW |
03141-0516A-000 |
from US $0.80 |
||
|
14
|
14
35810-82D40-000
Lamp assy,high mt stop
|
35810-82D40-000 |
— | ||
| replacement | |||||
|
14
|
14
35810-82D42-000 LAMP ASSY,HIGH MT STOP |
35810-82D42-000 |
US $108.93 |
||
|
15
|
15
02112-1412A-000 SCREW |
02112-1412A-000 |
US $12.50 |
||
|
16
|
16
35910-55G00-000 Lamp assy,license |
35910-55G00-000 |
US $40.11 |
||
|
17
|
17
09471-12216-000 BULB(12V5W)Bulb (12v5w) |
09471-12216-000 |
from US $2.84 |
||
|
18
|
18
36258-70C30-000 SOCKET,BULB |
36258-70C30-000 |
US $6.40 |
||
|
19
|
19
36210-63J10-6GS
LAMP ASSY,ROOM
|
36210-63J10-6GS |
— | ||
| replacement | |||||
|
19
|
19
36210-63J11-6GS Lamp Assy,room |
36210-63J11-6GS |
US $33.44 |
||
|
20
|
20
09471-12181-000 BULB(12V10W) |
09471-12181-000 |
US $38.30 |
||
|
21
|
21
36212-63J00-000 LENS |
36212-63J00-000 |
US $9.20 |
||
|
22
|
22
36230-79J00-6GS LAMP ASSY,SPOT |
36230-79J00-6GS |
from US $59.13 |
||
|
23
|
23
09471-12113-000 BULB(12V8W) |
09471-12113-000 |
from US $1.49 |
||
|
24
|
24
36218-74F00-000 SOCKET |
36218-74F00-000 |
US $3.35 |
||
|
25
|
25
36230-70C00-000 LAMP ASSY,TRUNK ROOM |
36230-70C00-000 |
US $22.26 |
||
|
26
|
26
09471-12216-000 BULB(12V5W)Bulb (12v5w) |
09471-12216-000 |
from US $2.84 |
||
|
27
|
27
36232-70C00-000 LENS,TRUNK ROOM LAMP |
36232-70C00-000 |
US $4.31 |
||
