Rr windshield wiper (V) Diagram Suzuki VITARA
- Year
- -
- Sales region
- Africa
- transmission
- 3AT
- grade
- JLX
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
38811-61A00-000 MOTOR ASSY,RR WIPER |
38811-61A00-000 |
US $264.96 |
||
|
2
|
2
09125-06058-000
Screw
|
09125-06058-000 |
— | ||
| replacement | |||||
|
2
|
2
09125-06058-XC0
SCREW(6X10)
|
09125-06058-XC0 |
— | ||
|
3
|
3
38813-61A00-000 LINK ASSY,RR WIPER |
38813-61A00-000 |
US $73.97 |
||
|
4
|
4
38814-61A00-000 PIVOT,REAR WIPER |
38814-61A00-000 |
US $33.86 |
||
|
5
|
5
38272-61A00-000 GASKET,WIPER PIVOT |
38272-61A00-000 |
US $3.64 |
||
|
6
|
6
38271-61A00-000 WASHER,WIPER PIVOT |
38271-61A00-000 |
US $3.02 |
||
|
7
|
7
38278-61A00-000 NUT,WIPER PIVOT |
38278-61A00-000 |
US $4.27 |
||
|
8
|
8
38274-61A00-000 CAP,WIPER PIVOT |
38274-61A00-000 |
US $3.02 |
||
|
9
|
9
38821-61A00-000 ARM ASSY,RR WIPER |
38821-61A00-000 |
US $82.85 |
||
|
10
|
10
08316-10063-000
Nut
|
08316-10063-000 |
— | ||
| replacement | |||||
|
10
|
10
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
|
11
|
11
38822-61A00-000
Blade assy,rear wiper
|
38822-61A00-000 |
— | ||
| replacement | |||||
|
11
|
11
38340-76F10-000 BLADE ASSY,WIPER,L |
38340-76F10-000 |
US $23.20 |
||
|
12
|
12
38346-61A00-000
Blade,rubber
|
38346-61A00-000 |
— | ||
|
13
|
13
38315-61A00-000 COVER,HEAD |
38315-61A00-000 |
US $11.20 |
||
|
14
|
14
38842-61A00-000 NOZZLE,RR WASHER |
38842-61A00-000 |
US $15.79 |
||
|
15
|
15
38843-61A01-000 GASKET,WASHER NOZZLE |
38843-61A01-000 |
US $1.52 |
||
|
16
|
16
38491-61A00-000 HOSE,WASHER L:1300Hose, washer (l:1300->80) |
38491-61A00-000 |
US $5.12 |
||
|
17
|
17
38496-61A00-000 VALVE,CHECK |
38496-61A00-000 |
from US $1.71 |
||
|
18
|
18
38491-61A10-000 HOSE,WASHER L:2100 |
38491-61A10-000 |
US $5.44 |
||
|
19
|
19
38835-61A00-000
HOSE,WASHER
|
38835-61A00-000 |
— | ||
|
20
|
20
38838-82000-000 CONNECTOR |
38838-82000-000 |
US $1.32 |
||
|
21
|
21
38839-82000-000 GROMMET |
38839-82000-000 |
US $8.83 |
||
|
22
|
22
38491-61A00-000 HOSE,WASHER L:1300Hose, washer (l:1300->80) LHD |
38491-61A00-000 |
US $5.12 |
||
|
23
|
23
38496-56B00-000 CONNECTORLHD |
38496-56B00-000 |
from US $1.60 |
||
|
24
|
24
36930-82010-000 COVER,HARNESSCover, roof wire <-36930-82000 |
36930-82010-000 |
from US $1.73 |
||
|
25
|
25
09139-05028-000 SCREW(5X14) |
09139-05028-000 |
US $11.40 |
||
