front-drive shaft (2WD:XR; 2000-11-01~2002-07-01) Diagram Suzuki WAGON R/PLUS/SOLIO/WIDE
- Year
- 2000 - 2011
- Sales region
- Japan
- Engine
- M13A
- drive
- 2WD
- transmission
- AT
- grade
- XR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
44101-80G10-000
SHAFT ASSY FRONT DRIVE RH
2WD:XR; 2000-11-01~2002-05-01 |
44101-80G10-000 |
— | ||
| replacement | |||||
|
1
|
1
44101-80G14-000 SHAFT ASSY,FRONT DRIVE,RH2WD:XR; 2000-11-01~2002-05-01 |
44101-80G14-000 |
from US $491.69 |
||
|
1
|
1
44101-80G11-000
SHAFT ASSYFRONT DRIVER
2WD:XR; 2002-05-01~2002-07-01 |
44101-80G11-000 |
— | ||
| replacement | |||||
|
1
|
1
44101-80G14-000 SHAFT ASSY,FRONT DRIVE,RH2WD:XR; 2002-05-01~2002-07-01 |
44101-80G14-000 |
from US $491.69 |
||
|
2
|
2
44118-60G00-000
BOOT SET,WHEEL SIDE
2WD:XR; 2000-11-01~2002-07-01 |
44118-60G00-000 |
— | ||
| replacement | |||||
|
2
|
2
44118-60GA0-000
BOOT SET,WHEEL SIDE
2WD:XR; 2000-11-01~2002-07-01 |
44118-60GA0-000 |
— | ||
|
3
|
3
44124-86011-000 BAND,BOOT2WD:XR; 2000-11-01~2002-07-01 |
44124-86011-000 |
from US $3.20 |
||
|
4
|
4
44122-86010-000 BAND,BOOTClamp, differential side outer boot 2WD:XR; 2000-11-01~2002-07-01 |
44122-86010-000 |
from US $4.66 |
||
|
5
|
5
44117-60G00-000
JOINT ASSY,DIFF SIDE,R
2WD:XR; 2000-11-01~2002-05-01 |
44117-60G00-000 |
— | ||
|
5
|
5
44117-80G30-000
ジョイントアッシ,ディファレンシャルサイド,ライト
2WD:XR; 2002-05-01~2002-07-01 |
44117-80G30-000 |
— | ||
| replacement | |||||
|
5
|
5
44117-80G41-000 JOINT ASSY,FR DRIVE2WD:XR; 2002-05-01~2002-07-01 |
44117-80G41-000 |
US $393.76 |
||
|
6
|
6
44119-72F00-000
BOOT SET,DIFF SIDE
2WD:XR; 2000-11-01~2002-05-01 |
44119-72F00-000 |
— | ||
| replacement | |||||
|
6
|
6
44119-72F01-000 BOOT SET,DIFF SIDE2WD:XR; 2000-11-01~2002-05-01 |
44119-72F01-000 |
from US $98.73 |
||
|
6
|
6
44119-75F60-000
BOOT SET,DIFF SIDE
2WD:XR; 2002-05-01~2002-07-01 |
44119-75F60-000 |
— | ||
| replacement | |||||
|
6
|
6
44119-75F61-000 BOOT SET,DIFF SIDE2WD:XR; 2002-05-01~2002-07-01 |
44119-75F61-000 |
from US $69.92 |
||
|
7
|
7
44111-64B90-000 RING,SNAP2WD:XR; 2000-11-01~2002-05-01 |
44111-64B90-000 |
from US $1.71 |
||
|
7
|
7
44111-78010-000 RING,SNAP2WD:XR; 2002-05-01~2002-07-01 |
44111-78010-000 |
from US $2.80 |
||
|
8
|
8
44124-86011-000 BAND,BOOT2WD:XR; 2000-11-01~2002-07-01 |
44124-86011-000 |
from US $3.20 |
||
|
9
|
9
44122-86011-000
バンド,ブーツ
2WD:XR; 2002-05-01~2002-07-01 |
44122-86011-000 |
— | ||
|
9
|
9
44121-60B00-000 BAND,BOOT2WD:XR; 2000-11-01~2002-05-01 |
44121-60B00-000 |
US $8.80 |
||
|
10
|
10
44112-78010-000 CIRCLIP2WD:XR; 2002-05-01~2002-07-01 |
44112-78010-000 |
from US $2.48 |
||
|
11
|
11
44102-79C00-000
シャフトアッシ,フロントドライブ,レフト
2WD:XR; 2000-11-01~2002-07-01 |
44102-79C00-000 |
— | ||
| replacement | |||||
|
11
|
11
44102-79C04-000 SHAFT ASSY,FRONT DRIVE,LH2WD:XR; 2000-11-01~2002-07-01 |
44102-79C04-000 |
US $1,499.20 |
||
|
12
|
12
44118-75F60-000
BOOT SET,WHEEL SIDE
2WD:XR; 2000-11-01~2002-07-01 |
44118-75F60-000 |
— | ||
| replacement | |||||
|
12
|
12
44118-80G11-000 BOOT SET,WHEEL SIDE2WD:XR; 2000-11-01~2002-07-01 |
44118-80G11-000 |
from US $99.36 |
||
|
13
|
13
44122-86010-000 BAND,BOOTClamp, differential side outer boot 2WD:XR; 2000-11-01~2002-07-01 |
44122-86010-000 |
from US $4.66 |
||
|
14
|
14
44124-86011-000 BAND,BOOT2WD:XR; 2000-11-01~2002-07-01 |
44124-86011-000 |
from US $3.20 |
||
|
15
|
15
44117-79C00-000
ジョイントアッシ,ディファレンシャルサイド,レフト
2WD:XR; 2000-11-01~2002-07-01 |
44117-79C00-000 |
— | ||
| replacement | |||||
|
15
|
15
44117-79CA0-000 JOINT ASSY,DIFF SIDE,L2WD:XR; 2000-11-01~2002-07-01 |
44117-79CA0-000 |
US $382.72 |
||
|
16
|
16
44119-75F60-000
BOOT SET,DIFF SIDE
2WD:XR; 2000-11-01~2002-07-01 |
44119-75F60-000 |
— | ||
| replacement | |||||
|
16
|
16
44119-75F61-000 BOOT SET,DIFF SIDE2WD:XR; 2000-11-01~2002-07-01 |
44119-75F61-000 |
from US $69.92 |
||
|
17
|
17
44111-78010-000 RING,SNAP2WD:XR; 2000-11-01~2002-07-01 |
44111-78010-000 |
from US $2.80 |
||
|
18
|
18
44112-78010-000 CIRCLIP2WD:XR; 2000-11-01~2002-07-01 |
44112-78010-000 |
from US $2.48 |
||
|
19
|
19
44122-86010-000 BAND,BOOTClamp, differential side outer boot 2WD:XR; 2000-11-01~2002-07-01 |
44122-86010-000 |
from US $4.66 |
||
|
20
|
20
44124-86011-000 BAND,BOOT2WD:XR; 2000-11-01~2002-07-01 |
44124-86011-000 |
from US $3.20 |
||
|
21
|
21
09381-24001-000 RING,SNAPRing (od:24,d:1.6) 2WD:XR; 2000-11-01~2002-07-01 |
09381-24001-000 |
from US $1.60 |
||
