rear suspension (4WD; 2003-09-01~2004-03-01) Diagram Suzuki WAGON R/PLUS/SOLIO/WIDE
- Year
- 2003 - 2011
- Sales region
- Japan
- Engine
- 4V
- drive
- 4WD
- transmission
- AT
- grade
- FB
- abs
- ABS
- 寒冷地
- COLD
- deice
- DEICE-N
- side air bag
- SAB-N
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
41311-58JA0-000
スプリング,リヤコイル
4WD:(FA,FB,FC,FD); 2003-09-01~2004-03-01 |
41311-58JA0-000 |
— | ||
|
2
|
2
42251-73H00-000 STOPPER,RR BUMP4WD; 2003-09-01~2004-03-01 |
42251-73H00-000 |
US $18.18 |
||
|
3
|
3
41341-79A00-000 SEAT,REAR SPRING UPPER4WD; 2003-09-01~2004-03-01 |
41341-79A00-000 |
from US $6.10 |
||
|
4
|
4
41800-58JA0-000
アブソーバアッシ,リヤショック
4WD:(FA,FB,FC,FD); 2003-09-01~2004-03-01 |
41800-58JA0-000 |
— | ||
| replacement | |||||
|
4
|
4
41800-58JA1-000
アブソーバアッシ,リヤショック
4WD:(FA,FB,FC,FD); 2003-09-01~2004-03-01 |
41800-58JA1-000 |
— | ||
|
5
|
5
41981-83H00-000 BOLT,RR SHK ABSORBER UPR4WD; 2003-09-01~2004-03-01 |
41981-83H00-000 |
US $6.81 |
||
|
6
|
6
41982-58JA0-000 BOLT,RR SHK ABSORBER LWR4WD; 2003-09-01~2004-03-01 |
41982-58JA0-000 |
US $5.85 |
||
|
7
|
7
08316-10123-000
Nut
4WD; 2003-09-01~2004-03-01 |
08316-10123-000 |
— | ||
| replacement | |||||
|
7
|
7
08316-1012A-000 NUT4WD; 2003-09-01~2004-03-01 |
08316-1012A-000 |
from US $0.96 |
||
|
8
|
8
46201-58JA0-000
アームアッシ,リヤトレーリング,ライト
4WD; 2003-09-01~2004-03-01 |
46201-58JA0-000 |
— | ||
|
9
|
9
46202-58JA0-000
アームアッシ,リヤトレーリング,レフト
4WD; 2003-09-01~2004-03-01 |
46202-58JA0-000 |
— | ||
|
10
|
10
46292-60J00-000
ナット
4WD; 2003-09-01~2004-03-01 |
46292-60J00-000 |
— | ||
| replacement | |||||
|
10
|
10
09159-12068-000 NUT4WD; 2003-09-01~2004-03-01 |
09159-12068-000 |
from US $1.49 |
||
|
11
|
11
09103-12044-000 BOLT(12X87)4WD; 2003-09-01~2004-03-01 |
09103-12044-000 |
from US $3.02 |
||
|
12
|
12
09103-12051-000 BOLT(12X50)4WD; 2003-09-01~2004-03-01 |
09103-12051-000 |
from US $2.56 |
||
|
13
|
13
09103-12064-000
ボルト,12X80
4WD; 2003-09-01~2004-03-01 |
09103-12064-000 |
— | ||
| replacement | |||||
|
13
|
13
09103-12068-000 BOLT(12X80)4WD; 2003-09-01~2004-03-01 |
09103-12068-000 |
from US $3.20 |
||
|
14
|
14
08316-10123-000
Nut
4WD; 2003-09-01~2004-03-01 |
08316-10123-000 |
— | ||
| replacement | |||||
|
14
|
14
08316-1012A-000 NUT4WD; 2003-09-01~2004-03-01 |
08316-1012A-000 |
from US $0.96 |
||
|
15
|
15
46300-58JA0-000
ロッドアッシ,ラテラル
4WD; 2003-09-01~2004-03-01 |
46300-58JA0-000 |
— | ||
|
16
|
16
08316-10123-000
Nut
4WD; 2003-09-01~2004-03-01 |
08316-10123-000 |
— | ||
| replacement | |||||
|
16
|
16
08316-1012A-000 NUT4WD; 2003-09-01~2004-03-01 |
08316-1012A-000 |
from US $0.96 |
||
|
17
|
17
09164-12017-000 WASHER4WD; 2003-09-01~2004-03-01 |
09164-12017-000 |
from US $1.44 |
||
