Rear lamp (REAR LAMP) Diagram Suzuki WAGON R/PLUS/SOLIO/WIDE
- Year
- -
- Sales region
- Pacific
- grade
- GA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35650-75F10-000 LAMP UNIT,RR COMB,R |
35650-75F10-000 |
US $86.85 |
||
|
2
|
2
35670-75F10-000 LAMP UNIT,RR COMB,L |
35670-75F10-000 |
US $86.85 |
||
|
3
|
3
09471-12192-000 BULB(12V21/5W) |
09471-12192-000 |
from US $3.19 |
||
|
4
|
4
09471-12191-000 BULB(12V21W) |
09471-12191-000 |
from US $4.23 |
||
|
5
|
5
35658-75F00-000 SOCKET&CORD ASSY |
35658-75F00-000 |
US $51.52 |
||
|
6
|
6
08316-10063-000
Nut
|
08316-10063-000 |
— | ||
| replacement | |||||
|
6
|
6
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
|
7
|
7
35690-74F01-000
COVER,RR COMB LAMP,R
|
35690-74F01-000 |
— | ||
|
8
|
8
35691-74F01-000 COVER,RR COMB LAMP,L |
35691-74F01-000 |
US $15.97 |
||
|
9
|
9
03541-05163-000
Screw
|
03541-05163-000 |
— | ||
| replacement | |||||
|
9
|
9
03541-0516A-000 SCREW |
03541-0516A-000 |
from US $0.76 |
||
|
10
|
10
35910-75F10-000
LAMP ASSY LICENSE
|
35910-75F10-000 |
— | ||
| replacement | |||||
|
10
|
10
35910-75F12-000 Lamp assy,license |
35910-75F12-000 |
from US $14.33 |
||
|
11
|
11
09471-12081-000
Bulb (12v,5w)
|
09471-12081-000 |
— | ||
| replacement | |||||
|
11
|
11
09471-12216-000 BULB(12V5W)Bulb (12v5w) |
09471-12216-000 |
from US $3.02 |
||
|
12
|
12
35820-75F00-000
LAMP UNIT,HIGH MT STOP
GL,Australia:GA |
35820-75F00-000 |
— | ||
|
13
|
13
09471-12045-000 BULB(12V21W)GL,Australia:GA |
09471-12045-000 |
from US $3.11 |
||
|
14
|
14
35818-75F00-000 SOCKET,BULBGL,Australia:GA |
35818-75F00-000 |
US $14.57 |
||
|
15
|
15
35821-74F10-5PK COVER,H/M STOP LAMPGL,Australia:GA |
35821-74F10-5PK |
US $10.16 |
||
|
16
|
16
02162-06123-000
Bolt (6x12)
GL,Australia:GA |
02162-06123-000 |
— | ||
| replacements | |||||
|
16
|
16
02162-0612B-000 SCREWBolt GL,Australia:GA |
02162-0612B-000 |
from US $0.80 |
||
|
16
|
16
02162-0612A-000 SCREWBolt, bracket GL,Australia:GA |
02162-0612A-000 |
from US $0.79 |
||
|
17
|
17
09409-06311-5ES CAP(BLACK),Belgium:GA |
09409-06311-5ES |
US $17.30 |
||
|
18
|
18
84761-50X50-000 SEAL,140X190Seal, rr defogger wire hole ,Belgium:GA,CUT AS REQURED |
84761-50X50-000 |
from US $6.72 |
||
|
19
|
19
35810-75F20-000
LAMP ASSY,HIGH MT STOP
GLX |
35810-75F20-000 |
— | ||
|
20
|
20
02142-04123-000
Screw
GLX |
02142-04123-000 |
— | ||
| replacement | |||||
|
20
|
20
02142-0412A-000 SCREWGLX |
02142-0412A-000 |
from US $0.43 |
||
|
21
|
21
36842-75F00-000 WIRE,HIGH MOUNT STOP LAMPGLX |
36842-75F00-000 |
from US $5.09 |
||
|
22
|
22
36570-75F10-000
LAMP ASSY,RR FOG
|
36570-75F10-000 |
— | ||
|
22
|
22
36570-75F00-000
LAMP ASSY,RR FOG
Belgium |
36570-75F00-000 |
— | ||
|
23
|
23
36573-79000-000 GASKET,Belgium |
36573-79000-000 |
US $2.17 |
||
|
24
|
24
36572-79000-000
LENS
,Belgium |
36572-79000-000 |
— | ||
|
25
|
25
03212-04169-000 SCREWScrew ,Belgium |
03212-04169-000 |
from US $2.13 |
||
|
26
|
26
35129-04030-000 WASHER,Belgium |
35129-04030-000 |
US $1.18 |
||
|
27
|
27
09471-12045-000 BULB(12V21W),Belgium |
09471-12045-000 |
from US $3.11 |
||
|
28
|
28
36580-75F00-000 BRACKET,RR FOG LAMP |
36580-75F00-000 |
US $11.89 |
||
|
28
|
28
36590-75F00-000
BRACKET,RR FOG LAMP
Belgium |
36590-75F00-000 |
— | ||
|
29
|
29
08310-00083-000
Nut
,Belgium |
08310-00083-000 |
— | ||
| replacements | |||||
|
29
|
29
08310-0008B-000 NUT,Belgium |
08310-0008B-000 |
from US $0.96 |
||
|
29
|
29
08310-0008A-000 NUTNut, bead stopper ,Belgium |
08310-0008A-000 |
from US $0.76 |
||
|
30
|
30
09160-08133-000
Washer
,Belgium |
09160-08133-000 |
— | ||
| replacement | |||||
|
30
|
30
09160-08151-000 WASHER(8.5X26X1.6)Washer, shift rod (8.5x26x1.6) ,Belgium |
09160-08151-000 |
from US $0.91 |
||
|
31
|
31
03541-05163-000
Screw
,Belgium |
03541-05163-000 |
— | ||
| replacement | |||||
|
31
|
31
03541-0516A-000 SCREW,Belgium |
03541-0516A-000 |
from US $0.76 |
||
