Rear Drum Brake Wheel Cylinder & Backing Plate ([12.2012 - ] (1212- )) Diagram Toyota AGYA/ WIGO
- Year
- 2017 - 2018
- Sales region
- General
- Frame
- B101
- grade
- HIS
- ENGINE
- 3NRVE
- TRANSMISSION
- ATM
- Model
- AGYA
- From
- 04.2017
- No.of Doors
- 5D
- Vehicle Model
- AGYA
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04474
|
04474
04474-BZ060
Cylinder Kit, Rear Wheel
[04.2017 -] B10# |
04474-BZ060 |
— | ||
|
04495
|
04495
04495-BZ111
Shoe Kit, Rear Brake
[04.2017 -] B10# |
04495-BZ111 |
— | ||
|
04906
|
04906
04906-BZ080
Cup Kit, Rear Wheel Cylinder
[04.2017 -] B10# |
04906-BZ080 |
— | ||
|
47043
|
47043
47043-BZ090
Plate Sub-Assy, Brake Backing, Rear Rh
[04.2017 -] B10# |
47043-BZ090 |
— | ||
|
47044
|
47044
47044-BZ090
Plate Sub-Assy, Brake Backing, Rear Lh
[04.2017 -] B10# |
47044-BZ090 |
— | ||
|
47430B
|
47430B
47459-BZ030
Spring, Tension(For Rear Brake Shoe Return)
[04.2017 -] B10# |
47459-BZ030 |
— | ||
|
47430C
|
47430C
47446-BZ050
Spring(For Rear Brake Shoe Hold Down)
[04.2017 -] B10# OD=17 |
47446-BZ050 |
— | ||
|
47430E
|
47430E
47459-BZ040
Spring, Tension(For Rear Brake Shoe Return)
[04.2017 -] B10# |
47459-BZ040 |
— | ||
|
47430H
|
47430H
47459-BZ050
Spring, Compression(For Parking Brake Shoe Strut)
[04.2017 -] B10# RH |
47459-BZ050 |
— | ||
|
47430H
|
47430H
47459-BZ060
Spring, Compression(For Parking Brake Shoe Strut)
[04.2017 -] B10# LH |
47459-BZ060 |
— | ||
|
47447G
|
47447G
47447-BZ050
Pin, Shoe Hold Down Spring(For Rear Brake)
[04.2017 -] B10# |
47447-BZ050 |
— | ||
|
47449B
|
47449B
47449-BZ050
Cup, Shoe Hold Down Spring(For Rear Brake)
[04.2017 -] B10# |
47449-BZ050 |
— | ||
|
47491B
|
47491B
47419-BZ020
Plug, Hole(For Rear Brake)
[04.2017 -] B10# |
47419-BZ020 |
— | ||
|
47547R
|
47547R
47547-BZ070
Plug, Bleeder(For Front Disc Brake)
[04.2017 -] B10# |
47547-BZ070 |
— | ||
|
47548R
|
47548R
47548-BZ010
Cap, Bleeder Plug(For Front Disc Brake)
[04.2017 -] B10# |
47548-BZ010 |
— | ||
|
47550
|
47550
47550-BZ060
Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
[04.2017 -] B10# |
47550-BZ060 |
— | ||
|
47559C
|
47559C
47559-BZ040
Spring, Rear Automatic Adjust Lever Support
[04.2017 -] B10# |
47559-BZ040 |
— | ||
|
47570
|
47570
47550-BZ060
Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
[04.2017 -] B10# |
47550-BZ060 |
— | ||
|
47601
|
47601
47601-BZ030
Lever Sub-Assy, Parking Brake Shoe, Rh(For Rear Brake)
[04.2017 -] B10# |
47601-BZ030 |
— | ||
|
47602
|
47602
47602-BZ030
Lever Sub-Assy, Parking Brake Shoe, Lh (For Rear Brake)
[04.2017 -] B10# |
47602-BZ030 |
— | ||
|
47635C
|
47635C
47635-BZ040
Retainer, Adjusting Bolt Spring
[04.2017 -] B10# |
47635-BZ040 |
— | ||
|
47643A
|
47643A
47608-BZ020
Lever, Rear Brake Automatic Adjust, Rh
[04.2017 -] B10# |
47608-BZ020 |
— | ||
|
47644A
|
47644A
47609-BZ020
Lever, Rear Brake Automatic Adjust, Lh
[04.2017 -] B10# |
47609-BZ020 |
— | ||
|
9004A10131
|
9004A10131
9004A-10131
New Genuine Part
|
9004A-10131 |
— |
