Throttle Link & Valve Lever (Atm) ([04.2017 - ] (1704- )ATM) Diagram Toyota AGYA/ WIGO
- Year
- 2017 - 2018
- Sales region
- General
- Frame
- B101
- grade
- HIS
- ENGINE
- 3NRVE
- TRANSMISSION
- ATM
- Model
- AGYA
- From
- 04.2017
- No.of Doors
- 5D
- Vehicle Model
- AGYA
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35402B
|
35402B
90043-11256 Seal, Transmission Case Dust[04.2017 -] B10#..ATM |
90043-11256 |
from US $3.63 |
||
|
35409D
|
35409D
35409-B1010 Spring Sub-Assy, Manual Detent[04.2017 -] B10#..ATM |
35409-B1010 |
US $19.95 |
||
|
35501
|
35501
35501-B1010 Rod Sub-Assy, Parking Lock[04.2017 -] B10#..ATM |
35501-B1010 |
US $24.17 |
||
|
35506
|
35506
35506-B1010
Shaft Sub-Assy, Manual Valve Lever
[04.2017 -] B10#..ATM |
35506-B1010 |
— | ||
|
35507E
|
35507E
35572-B1020 Lever,transmission Control Shaft[04.2017 -] B10#..ATM |
35572-B1020 |
US $9.46 |
||
|
35556
|
35556
35556-87202 Shaft, Parking Lock Pawl[04.2017 -] B10#..ATM |
35556-87202 |
US $4.66 |
||
|
35557
|
35557
35557-B1010
Pawl, Parking Lock
[04.2017 -] B10#..ATM |
35557-B1010 |
— | ||
|
35557A
|
35557A
90045-08418
Spring, Torsion (For Parking Lock Pawl)
[04.2017 -] B10#..ATM |
90045-08418 |
— | ||
|
35593
|
35593
35593-B1010
Sleeve, Cam Guide
[04.2017 -] B10#..ATM |
35593-B1010 |
— | ||
|
35595
|
35595
35595-B1010
Bracket, Parking Lock Pawl
[04.2017 -] B10#..ATM |
35595-B1010 |
— | ||
|
9004105412
|
9004105412
90041-05412 Bolt (For Pawl Stopper Plate) |
90041-05412 |
US $2.18 |
||
|
9004179109
|
9004179109
90041-79109 New Genuine Part |
90041-79109 |
US $1.31 |
