Steering Wheel ([02.2012 - ] 3-SPOKE,LEATHER (1202- )) Diagram Toyota AYGO
- Year
- 2005 - 2014
- Sales region
- Europe
- Frame
- KGB10
- grade
- LEDIN
- ENGINE
- 1KRFE
- TRANSMISSION
- MTM
- From
- 02.2005
- To
- 06.2014
- Gear Shift Type
- 5F
- No.of Doors
- 3D
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
45100
|
45100
45100-0H010-B0
Wheel Assy, Steering
[02.2005 - 12.2008] KGB10,WNB10 3-SPOKE,URETHANE,DARK GREY,TRIM1# |
45100-0H010-B0 |
— | ||
|
45100
|
45100
45100-0H030-B0
Wheel Assy, Steering
[02.2012 - 03.2013] KGB10..5F 3-SPOKE,LEATHER,STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45100-0H030-B0 |
— | ||
| replacement | |||||
|
45100
|
45100
45100-0H030-B2
Wheel Assy, Steering
[02.2012 - 03.2013] KGB10..5F 3-SPOKE,LEATHER,STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45100-0H030-B2 |
— | ||
|
45100
|
45100
45100-0H030-B1
Wheel Assy, Steering
[07.2013 - 05.2014] KGB10..LEDIN 3-SPOKE,LEATHER,STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY & SODA,TRIM10; KGB10..5F..LV1 3-SPOKE,LEATHER,STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY & SODA,TRIM10,16 |
45100-0H030-B1 |
— | ||
|
45100
|
45100
45100-0H030-B2
Wheel Assy, Steering
[03.2013 - 07.2013] KGB10..5F 3-SPOKE,LEATHER,STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45100-0H030-B2 |
— | ||
|
45130
|
45130
45130-0H010-B0
Button Assy, Horn
[02.2005 - 12.2008] KGB10,WNB10 DARK GREY,TRIM1# |
45130-0H010-B0 |
— | ||
|
45130
|
45130
45130-0H060-B0
Button Assy, Horn
[02.2012 - 05.2014] KGB10..5FS DARK GREY,TRIM1#; KGB10..5F STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45130-0H060-B0 |
— | ||
|
45186
|
45186
45186-0H010-B0
Cover, Steering Wheel, Lower No.2
[02.2012 - 05.2014] KGB10..5FS DARK GREY,TRIM1#; KGB10..5F STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45186-0H010-B0 |
— | ||
|
45187
|
45187
45187-0H010-B0
Cover, Steering Wheel, Lower No.3
[02.2012 - 05.2014] KGB10..5FS DARK GREY,TRIM1#; KGB10..5F STEERING WHEEL-TOYOTA, 3-SPOKE, LEATHER,DARK GREY,TRIM1# |
45187-0H010-B0 |
— | ||
|
45188
|
45188
45188-60010 Screw, Steering Wheel Pad Attaching[02.2005 - 12.2008] KGB10,WNB10 L=18 |
45188-60010 |
US $2.56 |
||
|
45201P
|
45201P
90178-W0030
Nut, Steering Wheel Set
[02.2005 - 12.2008] KGB10,WNB10 |
90178-W0030 |
— | ||
| replacement | |||||
|
45201P
|
45201P
90179-12071 Nut, Steering Wheel Set[02.2005 - 12.2008] KGB10,WNB10 |
90179-12071 |
from US $1.58 |
||
|
45201P
|
45201P
90179-12071 Nut, Steering Wheel Set[12.2008 - 02.2012] KGB10 |
90179-12071 |
from US $1.58 |
||
|
9015950199
|
9015950199
90159-50199 SCREW |
90159-50199 |
from US $0.78 |
||
