Clutch Pedal & Flexible Hose ([10.2016 - ] (1610- )LHD..6F) Diagram Toyota C-HR
- Year
- 2016 - 2018
- Sales region
- U.S.A.
- Frame
- NGX10
- ENGINE
- 8NRFTS
- TRANSMISSION
- MTM
- DESTINATION
- RUS
- From
- 10.2016
- Gear Shift Type
- 6F
- Model Mark
- D
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-F4010
Pedal Sub-Assy, Clutch
[10.2016 -] NGX10..LHD..6F |
31301-F4010 |
— | ||
|
31301A
|
31301A
90949-03068 Spring(For Clutch Pedal)[10.2016 -] NGX10..6F |
90949-03068 |
US $9.14 |
||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[10.2016 -] NGX10..6F |
90386-13015 |
from US $0.64 |
||
|
31321
|
31321
31321-42010 Pad, Clutch Pedal[10.2016 -] NGX10..6F |
31321-42010 |
US $4.12 |
||
|
31324
|
31324
90105-10524 Shaft, Clutch Pedal[10.2016 -] NGX10..6F |
90105-10524 |
US $2.04 |
||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[10.2016 -] NGX10..6F |
90387-10003 |
from US $3.94 |
||
|
31353
|
31353
31353-26010 Holder, Clutch Pedal Spring[10.2016 -] NGX10..6F |
31353-26010 |
from US $3.02 |
||
|
31453A
|
31453A
90240-08083
Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)
[10.2016 -] NGX10..6F |
90240-08083 |
— | ||
|
31453B
|
31453B
90386-08033 Bush(For Clutch Master Cylinder Push Rod Clevis)[10.2016 -] NGX10..6F |
90386-08033 |
from US $1.31 |
||
|
55105D
|
55105D
55105-F4010
Bracket Sub-Assy, Clutch Pedal
[10.2016 -] NGX10..LHD..6F |
55105-F4010 |
— | ||
|
55107A
|
55107A
55107-F4010
Support Sub-Assy, Clutch Pedal
[10.2016 -] NGX10..LHD..6F |
55107-F4010 |
— | ||
|
90119W0012
|
90119W0012
90119-W0012
New Genuine Part
|
90119-W0012 |
— | ||
|
9011908C96
|
9011908C96
90119-08C96 New Genuine Part |
90119-08C96 |
US $1.43 |
||
|
9017910088
|
9017910088
90179-10088 Nut |
90179-10088 |
from US $0.99 |
||
|
9018508002
|
9018508002
90185-08002 New Genuine Part |
90185-08002 |
US $2.62 |
||
|
9038906055
|
9038906055
90389-06055 Bush(For Clutch Pedal Turnover) |
90389-06055 |
from US $1.79 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
