Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191) Diagram Toyota CALDINA
- Year
- 1992 - 1996
- Sales region
- Japan
- Frame
- ST190
- grade
- FZ
- body
- WG
- ENGINE
- 4SFE
- TRANSMISSION
- ATM
- From
- 11.1992
- To
- 01.1996
- Gear Shift Type
- 4FC
- Fuel Induction
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42304
|
42304
42304-20140 Carrier Sub-Assy, Rear Axle, Rh[11.1992 - 01.1996] CT190,ST190 |
42304-20140 |
US $219.86 |
||
| replacement | |||||
|
42304
|
42304
42304-20320 Carrier Sub-Assy, Rear Axle, Rh[11.1992 - 01.1996] CT190,ST190 |
42304-20320 |
US $219.86 |
||
|
42304
|
42304
42304-20160 Carrier Sub-Assy, Rear Axle, Rh[11.1992 - 01.1996] CT190,ST190 ｱﾘ(ABS) |
42304-20160 |
US $219.86 |
||
| replacement | |||||
|
42304
|
42304
42304-20300 Carrier Sub-Assy, Rear Axle, Rh[11.1992 - 01.1996] CT190,ST190 ｱﾘ(ABS) |
42304-20300 |
US $215.49 |
||
|
42304D
|
42304D
90105-15001 Bolt (For Rear Axle Carrier)[11.1992 - 02.1995] CT190,ST19# |
90105-15001 |
US $6.56 |
||
|
42304E
|
42304E
90179-15001 Nut (For Rear Axle Carrier)[11.1992 - 02.1995] CT190,ST19# |
90179-15001 |
from US $3.24 |
||
|
42305
|
42305
42305-20140 Carrier Sub-Assy, Rear Axle, Lh[11.1992 - 01.1996] CT190,ST190 |
42305-20140 |
US $219.86 |
||
| replacement | |||||
|
42305
|
42305
42305-20320 Carrier Sub-Assy, Rear Axle, Lh[11.1992 - 01.1996] CT190,ST190 |
42305-20320 |
US $219.86 |
||
|
42305
|
42305
42305-20160 Carrier Sub-Assy, Rear Axle, Lh[11.1992 - 01.1996] CT190,ST190 ｱﾘ(ABS) |
42305-20160 |
US $219.86 |
||
| replacement | |||||
|
42305
|
42305
42305-20300 Carrier Sub-Assy, Rear Axle, Lh[11.1992 - 01.1996] CT190,ST190 ｱﾘ(ABS) |
42305-20300 |
US $215.49 |
||
|
42305A
|
42305A
90105-15001 Bolt (For Rear Axle Carrier)[11.1992 - 02.1995] CT190,ST19# |
90105-15001 |
US $6.56 |
||
|
42305B
|
42305B
90179-15001 Nut (For Rear Axle Carrier)[11.1992 - 02.1995] CT190,ST19# |
90179-15001 |
from US $3.24 |
||
|
48231A
|
48231A
48231-2G060 Spring, Coil, Rear Rh[11.1992 - 05.1993] CT190,ST190,191 |
48231-2G060 |
US $141.23 |
||
|
48231A
|
48231A
48231-2G250 Spring, Coil, Rear Rh[05.1993 - 02.1994] ST190,191 |
48231-2G250 |
US $136.86 |
||
|
48231B
|
48231B
48231-2G060 Spring, Coil, Rear Rh[11.1992 - 05.1993] CT190,ST190,191 |
48231-2G060 |
US $141.23 |
||
|
48231B
|
48231B
48231-2G250 Spring, Coil, Rear Rh[05.1993 - 02.1994] ST190,191 |
48231-2G250 |
US $136.86 |
||
|
48258B
|
48258B
48258-32010 Insulator, Rear Coil Spring, Lower[11.1992 - 02.1995] CT190,ST19# |
48258-32010 |
from US $11.84 |
||
|
48258C
|
48258C
48258-32010 Insulator, Rear Coil Spring, Lower[11.1992 - 02.1995] CT190,ST19# |
48258-32010 |
from US $11.84 |
||
|
48341A
|
48341A
48341-20210
Bumper, Rear Spring, No.1 Rh
[11.1992 - 01.1996] CT190,ST190 |
48341-20210 |
— | ||
|
48341B
|
48341B
48341-20210
Bumper, Rear Spring, No.1 Rh
[11.1992 - 01.1996] CT190,ST190 |
48341-20210 |
— | ||
|
48530
|
48530
48530-20700 Absorber Assy, Shock, Rear Rh[11.1992 - 02.1994] CT190,ST190 |
48530-20700 |
US $358.18 |
||
| replacement | |||||
|
48530
|
48530
48530-2B310 Absorber Assy, Shock, Rear RhSHOCK, REAR RH [11.1992 - 02.1994] CT190,ST190 |
48530-2B310 |
US $345.07 |
||
|
48530
|
48530
48530-2B470 Absorber Assy, Shock, Rear Rh[02.1994 - 01.1996] CT190,ST190 |
48530-2B470 |
US $343.62 |
||
| replacement | |||||
|
48530
|
48530
48530-2B310 Absorber Assy, Shock, Rear RhSHOCK, REAR RH [02.1994 - 01.1996] CT190,ST190 |
48530-2B310 |
US $345.07 |
||
|
48540
|
48540
48540-20700 Absorber Assy, Shock, Rear Lh[11.1992 - 02.1994] CT190,ST190 |
48540-20700 |
US $358.18 |
||
| replacement | |||||
|
48540
|
48540
48540-2B310 Absorber Assy, Shock, Rear LhSHOCK, REAR LH [11.1992 - 02.1994] CT190,ST190 |
48540-2B310 |
US $345.07 |
||
|
48540
|
48540
48540-2B470 Absorber Assy, Shock, Rear Lh[02.1994 - 01.1996] CT190,ST190 |
48540-2B470 |
US $343.62 |
||
| replacement | |||||
|
48540
|
48540
48540-2B310 Absorber Assy, Shock, Rear LhSHOCK, REAR LH [02.1994 - 01.1996] CT190,ST190 |
48540-2B310 |
US $345.07 |
||
|
48559C
|
48559C
48559-20040 Cover, Rear Shock Absober Dust, Rh No.1[11.1992 - 02.1995] CT190,ST19# 東海ゴム |
48559-20040 |
from US $30.23 |
||
|
48559D
|
48559D
48559-20040 Cover, Rear Shock Absober Dust, Rh No.1[11.1992 - 02.1995] CT190,ST19# 東海ゴム |
48559-20040 |
from US $30.23 |
||
|
48703C
|
48703C
90179-14019 Nut[11.1992 - 08.1997] ST195 ｷﾔﾘｱ ｻｲﾄﾞ; AT191,CT190,ST190,191 |
90179-14019 |
from US $1.40 |
||
|
48703E
|
48703E
90901-09001 Bolt(For Rear Suspension Arm)[11.1992 - 08.1997] AT191,CT190,ST190,191 ＊１４−１．５０ＰＸ２６０−２６,ボデー側 |
90901-09001 |
from US $20.62 |
||
|
48703E
|
48703E
90901-19001 Bolt(For Rear Suspension Arm)[11.1992 - 08.1997] AT191,CT190,ST190,191 ＊１４−１．５０ＰＸ２６０−２６,ｷﾔﾘｱ ｻｲﾄﾞ |
90901-19001 |
from US $17.82 |
||
|
48703H
|
48703H
90201-14017 Washer(For Rear Suspension Arm)[11.1992 - 08.1997] AT191,CT190,ST190,191 |
90201-14017 |
US $4.89 |
||
|
48703J
|
48703J
48715-32010
Washer, No.2(For Rear Suspension Arm)
[11.1992 - 01.1996] CT190,ST190,191 |
48715-32010 |
— | ||
|
48710A
|
48710A
48710-20190 Arm Assy, Rear Suspension, No.1 Rh[11.1992 - 02.1994] CT190,ST190,191 |
48710-20190 |
US $97.55 |
||
|
48710A
|
48710A
48710-20230
Arm Assy, Rear Suspension, No.1 Rh
[02.1994 - 01.1996] CT190,ST190,191 |
48710-20230 |
— | ||
|
48720A
|
48720A
48710-20190 Arm Assy, Rear Suspension, No.1 Rh[11.1992 - 02.1994] CT190,ST190,191 |
48710-20190 |
US $97.55 |
||
|
48720A
|
48720A
48710-20230
Arm Assy, Rear Suspension, No.1 Rh
[02.1994 - 01.1996] CT190,ST190,191 |
48710-20230 |
— | ||
|
48730F
|
48730F
48730-20160
Arm Assy, Rear Suspension, No.2 Rh
[11.1992 - 01.1996] CT190,ST190,191 |
48730-20160 |
— | ||
|
48730G
|
48730G
90179-16022 Nut, No.1(For Rear Suspension Arm No.2)[11.1992 - 08.1997] AT191,CT190,ST190,191 |
90179-16022 |
US $3.20 |
||
|
48730H
|
48730H
90179-16021 Nut, No.2(For Arm Assy, Rear Suspension, No.2)[11.1992 - 08.1997] AT191,CT190,ST190,191 |
90179-16021 |
US $3.06 |
||
|
48740F
|
48740F
48740-20050
Arm Assy, Rear Suspension, No.2 Lh
[11.1992 - 01.1996] CT190,ST190,191 |
48740-20050 |
— | ||
|
48740L
|
48740L
90179-16022 Nut, No.1(For Rear Suspension Arm No.2)[11.1992 - 08.1997] AT191,CT190,ST190,191 |
90179-16022 |
US $3.20 |
||
|
48740M
|
48740M
90179-16021 Nut, No.2(For Arm Assy, Rear Suspension, No.2)[11.1992 - 08.1997] AT191,CT190,ST190,191 |
90179-16021 |
US $3.06 |
||
|
48750G
|
48750G
90179-08122 Nut(For Rear Suspension Support)[11.1992 - 02.1995] CT190,ST19# |
90179-08122 |
US $7.04 |
||
|
48750H
|
48750H
48750-20100
Support Assy, Rear Suspension, Rh
[11.1992 - 02.1995] CT190,ST19# |
48750-20100 |
— | ||
| replacement | |||||
|
48750H
|
48750H
48750-21020 Support Assy, Rear Suspension, Rh[11.1992 - 02.1995] CT190,ST19# |
48750-21020 |
US $115.32 |
||
|
48750J
|
48750J
90179-14015 Nut, Castle (For Front Lower Ball Joint Setting)[11.1992 - 02.1995] CT190,ST19# |
90179-14015 |
from US $1.93 |
||
|
48750J
|
48750J
94184-61400 Nut(For Idler Arm Support)[06.1995 - 08.1997] AT191,CT190,ST19# |
94184-61400 |
US $3.84 |
||
|
48750K
|
48750K
90387-15012
Collar(For Rear Support To Rear Shock Absorber)
[11.1992 - 07.1994] CT190,ST19# |
90387-15012 |
— | ||
| replacement | |||||
|
48750K
|
48750K
90387-15027 Collar(For Rear Support To Rear Shock Absorber)[11.1992 - 07.1994] CT190,ST19# |
90387-15027 |
US $4.32 |
||
|
48750K
|
48750K
90387-15027 Collar(For Rear Support To Rear Shock Absorber)[07.1994 - 02.1995] CT190,ST19# |
90387-15027 |
US $4.32 |
||
|
48753B
|
48753B
48753-20040 Cover, Rear Suspension Supoport, No.1 Rh[11.1992 - 02.1995] CT190,ST19# |
48753-20040 |
US $8.88 |
||
|
48753C
|
48753C
48753-20040 Cover, Rear Suspension Supoport, No.1 Rh[11.1992 - 02.1995] CT190,ST19# |
48753-20040 |
US $8.88 |
||
|
48753D
|
48753D
48753-20060 Cover, Rear Suspension Supoport, No.2 Rh[05.1993 - 02.1995] ST190,191 |
48753-20060 |
US $5.82 |
||
|
48753E
|
48753E
48753-20060 Cover, Rear Suspension Supoport, No.2 Rh[05.1993 - 02.1995] ST190,191 |
48753-20060 |
US $5.82 |
||
|
48760B
|
48760B
48750-20100
Support Assy, Rear Suspension, Rh
[11.1992 - 02.1995] CT190,ST19# |
48750-20100 |
— | ||
| replacement | |||||
|
48760B
|
48760B
48750-21020 Support Assy, Rear Suspension, Rh[11.1992 - 02.1995] CT190,ST19# |
48750-21020 |
US $115.32 |
||
|
48760C
|
48760C
90179-14015 Nut, Castle (For Front Lower Ball Joint Setting)[11.1992 - 02.1995] CT190,ST19# |
90179-14015 |
from US $1.93 |
||
|
48760C
|
48760C
94184-61400 Nut(For Idler Arm Support)[06.1995 - 08.1997] AT191,CT190,ST19# |
94184-61400 |
US $3.84 |
||
|
48760D
|
48760D
90387-15012
Collar(For Rear Support To Rear Shock Absorber)
[11.1992 - 07.1994] CT190,ST19# |
90387-15012 |
— | ||
| replacement | |||||
|
48760D
|
48760D
90387-15027 Collar(For Rear Support To Rear Shock Absorber)[11.1992 - 07.1994] CT190,ST19# |
90387-15027 |
US $4.32 |
||
|
48760D
|
48760D
90387-15027 Collar(For Rear Support To Rear Shock Absorber)[07.1994 - 02.1995] CT190,ST19# |
90387-15027 |
US $4.32 |
||
|
48780A
|
48780A
48780-20080 Rod Assy, Strut, Rear[11.1992 - 01.1996] CT190,ST190,191 |
48780-20080 |
US $91.73 |
||
|
48780B
|
48780B
90119-12131 Bolt(For Strut Rod)[11.1992 - 02.1995] CT190,ST19# |
90119-12131 |
from US $3.84 |
||
| replacement | |||||
|
48780B
|
48780B
90080-11133 Bolt(For Strut Rod)[11.1992 - 02.1995] CT190,ST19# |
90080-11133 |
US $10.95 |
||
|
48780C
|
48780C
90179-12062 Nut(For Rear Suspension Arm)[11.1992 - 07.1994] CT190,ST19# ｷﾔﾘｱ ｻｲﾄﾞ |
90179-12062 |
from US $2.54 |
||
|
48780C
|
48780C
90179-12091 Nut(For Front Suspension Lower Arm)[07.1994 - 08.1997] AT191,CT190,ST19# ｷﾔﾘｱ ｻｲﾄﾞ |
90179-12091 |
from US $1.23 |
||
|
48780C
|
48780C
90179-12114 Nut(For Strut Rod)[11.1992 - 08.1997] AT191,CT190,ST19# ボデー側 |
90179-12114 |
US $2.91 |
||
|
48812
|
48812
48812-05030
Bar, Stabilizer, Rear
[08.1994 - 01.1996] CT190,ST190,191 （Ｌ） |
48812-05030 |
— | ||
|
48812
|
48812
48812-20550 Bar, Stabilizer, Rear[11.1992 - 02.1994] CT190,ST190 |
48812-20550 |
US $110.66 |
||
|
48812
|
48812
48812-20700 Bar, Stabilizer, Rear[02.1994 - 01.1996] CT190,ST190,191 （Ｊ） |
48812-20700 |
US $115.02 |
||
|
48818
|
48818
48818-20260 Bush, Stabilizer, Rear[02.1994 - 01.1996] CT190,ST190,191 |
48818-20260 |
from US $10.76 |
||
|
48818
|
48818
48818-20280 Bush, Stabilizer, Rear[11.1992 - 02.1994] CT190,ST190 |
48818-20280 |
from US $10.82 |
||
|
48830
|
48830
48830-32010
Link Assy, Rear Stabilizer
[11.1992 - 01.1996] CT190,ST190,191 |
48830-32010 |
— | ||
| replacement | |||||
|
48830
|
48830
48830-20010 Link Assy, Rear Stabilizer[11.1992 - 01.1996] CT190,ST190,191 |
48830-20010 |
US $79.92 |
||
|
48830A
|
48830A
90179-10054 Nut, No.1 (For Center Support Bearing)[11.1992 - 02.1995] CT190,ST19# |
90179-10054 |
from US $0.37 |
||
|
48832A
|
48832A
48832-20080
Bracket, Rear Stabilizer Bar, No.1
[11.1992 - 01.1996] CT190,ST190,191 |
48832-20080 |
— | ||
|
91611B0816
|
91611B0816
91611-B0816 Bolt |
91611-B0816 |
from US $1.09 |
||
|
9046400480
|
9046400480
90464-00480 New Genuine Part |
90464-00480 |
US $5.12 |
||
|
9095001453
|
9095001453
90950-01453 New Genuine Part |
90950-01453 |
US $1.46 |
||
