Rear Drum Brake Wheel Cylinder & Backing Plate ([06.2016 - ] (1606- )) Diagram Toyota CALYA
- Year
- 2016 - 2018
- Sales region
- General
- Frame
- B401
- grade
- E
- ENGINE
- 3NRVE
- TRANSMISSION
- MTM
- From
- 06.2016
- Gear Shift Type
- 5F
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04474
|
04474
04474-BZ070
Cylinder Kit, Rear Wheel
[06.2016 -] B401 |
04474-BZ070 |
— | ||
|
04495
|
04495
04495-BZ140
Shoe Kit, Rear Brake
[06.2016 -] B401 |
04495-BZ140 |
— | ||
|
04906
|
04906
04906-BZ090
Cup Kit, Rear Wheel Cylinder
[06.2016 -] B401 |
04906-BZ090 |
— | ||
|
47043
|
47043
47043-BZ120
Plate Sub-Assy, Brake Backing, Rear Rh
[06.2016 -] B401 |
47043-BZ120 |
— | ||
|
47044
|
47044
47044-BZ120
Plate Sub-Assy, Brake Backing, Rear Lh
[06.2016 -] B401 |
47044-BZ120 |
— | ||
|
47419R
|
47419R
47419-BZ020
Plug, Hole(For Rear Brake)
[06.2016 -] B401 |
47419-BZ020 |
— | ||
|
47430E
|
47430E
47459-BZ010
Spring, Tension(For Rear Brake Shoe Return)
[06.2016 -] B401 |
47459-BZ010 |
— | ||
|
47430K
|
47430K
47446-BZ030
Spring(For Rear Brake Shoe Hold Down, No.2)
[06.2016 -] B401 |
47446-BZ030 |
— | ||
|
47447G
|
47447G
47447-BZ060
Pin, Shoe Hold Down Spring(For Rear Brake)
[06.2016 -] B401 |
47447-BZ060 |
— | ||
|
47449B
|
47449B
47449-BZ030
Cup, Shoe Hold Down Spring(For Rear Brake)
[06.2016 -] B401 |
47449-BZ030 |
— | ||
|
47491B
|
47491B
47419-BZ010
Plug, Hole(For Rear Brake)
[06.2016 -] B401 |
47419-BZ010 |
— | ||
|
47547R
|
47547R
47547-BZ110 Plug, Bleeder(For Drum Brake, Rear)[06.2016 -] B401 |
47547-BZ110 |
US $7.13 |
||
|
47548R
|
47548R
47548-BZ080 Cap, Bleeder Plug(For Front Disc Brake)[06.2016 -] B401 |
47548-BZ080 |
US $4.12 |
||
|
47550
|
47550
47550-BZ070
Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
[06.2016 -] B401 |
47550-BZ070 |
— | ||
|
47556C
|
47556C
47555-BZ050
Spring, Adjuster Lock, Rh(For Rear Brake)
[06.2016 -] B401 |
47555-BZ050 |
— | ||
|
47556D
|
47556D
47555-BZ060
Spring, Adjuster Lock, Lh(For Rear Brake)
[06.2016 -] B401 |
47555-BZ060 |
— | ||
|
47559D
|
47559D
47559-BZ070
Spring, Rear Brake Automatic Adjust Lever Support, Rh
[06.2016 -] B401 |
47559-BZ070 |
— | ||
|
47559E
|
47559E
47559-BZ070
Spring, Rear Brake Automatic Adjust Lever Support, Rh
[06.2016 -] B401 |
47559-BZ070 |
— | ||
|
47570
|
47570
47550-BZ070
Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
[06.2016 -] B401 |
47550-BZ070 |
— | ||
|
47601
|
47601
47601-BZ050
Lever Sub-Assy, Parking Brake Shoe, Rh(For Rear Brake)
[06.2016 -] B401 |
47601-BZ050 |
— | ||
|
47601E
|
47601E
22498-BZ010
Ring, E(For Rear Brake)
[06.2016 -] B401 |
22498-BZ010 |
— | ||
|
47602
|
47602
47602-BZ050
Lever Sub-Assy, Parking Brake Shoe, Lh (For Rear Brake)
[06.2016 -] B401 |
47602-BZ050 |
— | ||
|
47643A
|
47643A
47643-BZ070
Lever, Rear Brake Automatic Adjust, Rh
[06.2016 -] B401 |
47643-BZ070 |
— | ||
|
47644A
|
47644A
47644-BZ060
Lever, Rear Brake Automatic Adjust, Lh
[06.2016 -] B401 |
47644-BZ060 |
— | ||
|
9004A10131
|
9004A10131
9004A-10131
New Genuine Part
|
9004A-10131 |
— |
