Clutch Pedal & Flexible Hose ([08.1993 - ] (9308- )UKP..LHD..MTM) Diagram Toyota CARINA
- Year
- 1996 - 1997
- Sales region
- Europe
- Frame
- AT191
- grade
- XL
- body
- LB
- ENGINE
- 7AFE
- TRANSMISSION
- MTM
- PRODUCT
- UKP
- Model
- CARINA E (UKP)
- From
- 01.1996
- To
- 10.1997
- Vehicle Model
- Carina E
- Driver's Position
- LHD
- Fuel Induction
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31418
|
31418
90080-93008
Hose, Clutch
[08.1993 - 10.1997] AT19#,CT190,ST191..UKP..MTM |
90080-93008 |
— | ||
|
31481
|
31481
31481-05040
Tube, Clutch Master Cylinder To Flexible Hose
[08.1993 - 10.1997] AT19#,CT190,ST191..UKP..LHD..MTM |
31481-05040 |
— | ||
|
31482
|
31482
31482-05020
Tube, Clutch Release Cylinder To Flexible Hose
[12.1992 - 10.1997] AT19#..UKP..MTM |
31482-05020 |
— | ||
|
31484A
|
31484A
31484-20540 Bracket, Flexible Hose, No.1(For Clutch)[08.1993 - 10.1997] AT19#,CT190,ST191..UKP..MTM |
31484-20540 |
US $10.19 |
||
|
31484C
|
31484C
31484-12110 Bracket, Clutch Tube, No.1[12.1992 - 10.1997] AT19#..UKP..MTM |
31484-12110 |
US $3.32 |
||
|
31485
|
31485
31484-20531 Bracket, Flexible Hose, No.2(For Clutch)[08.1993 - 10.1997] AT19#..UKP..MTM |
31484-20531 |
US $10.48 |
||
|
91611A0816
|
91611A0816
91611-A0816 New Genuine Part |
91611-A0816 |
US $1.60 |
||
|
91651B0616
|
91651B0616
91651-B0616 BOLT WWASHER |
91651-B0616 |
from US $0.86 |
||
|
9011908650
|
9011908650
90119-08650 New Genuine Part |
90119-08650 |
US $2.56 |
||
|
9046106055
|
9046106055
90461-06055 Clamp, Brake Tube, No.1 |
90461-06055 |
US $3.14 |
||
|
9046110750
|
9046110750
90461-10750 Clamp, No.2(For Parking Brake Cable) |
90461-10750 |
US $2.88 |
||
|
9046808034
|
9046808034
90468-08034 CLIP |
90468-08034 |
from US $1.09 |
