Clutch Pedal & Flexible Hose ([12.1981 - ] (8112- )MA61,RA65..RHD..5F) Diagram Toyota CELICA
- Year
- 1984 - 1985
- Sales region
- Europe
- Frame
- RA65
- grade
- ST
- body
- CP
- ENGINE
- 22REC
- TRANSMISSION
- MTM
- From
- 08.1984
- To
- 07.1985
- Gear Shift Type
- 5F
- Driver's Position
- RHD
- Destination
- ARL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31058
|
31058
31058-24010
Plate Sub-Assy, Over Center
[12.1981 - 12.1985] MA61,RA65..RHD..5F |
31058-24010 |
— | ||
|
31058A
|
31058A
90386-13192 Bush(For Over Center Plate)[12.1981 - 12.1985] MA61,RA65..5F |
90386-13192 |
from US $1.76 |
||
|
31058B
|
31058B
90101-10072
Bolt(For Over Center Plate)
[12.1981 - 12.1985] MA61,RA65..5F |
90101-10072 |
— | ||
|
31058C
|
31058C
90387-10038
Collar(For Over Center Plate)
[12.1981 - 12.1985] MA61,RA65..5F |
90387-10038 |
— | ||
|
31301
|
31301
31301-24030
Pedal Sub-Assy, Clutch
[02.1983 - 12.1985] MA61,RA65..RHD..5F |
31301-24030 |
— | ||
|
31301A
|
31301A
90507-20005
Spring(For Clutch Pedal)
[12.1981 - 12.1985] MA61,RA65..RHD..5F |
90507-20005 |
— | ||
|
31301B
|
31301B
90541-07010
Cushion, No.1(For Clutch Pedal)
[12.1981 - 12.1985] MA61,RA65..5F |
90541-07010 |
— | ||
|
31301C
|
31301C
90386-13192 Bush(For Over Center Plate)[08.1981 - 12.1985] AA63,MA61,RA6#,SA63,TA60..5F |
90386-13192 |
from US $1.76 |
||
|
31301F
|
31301F
90101-10105
Bolt(For Clutch Pedal Stopper)
[08.1983 - 12.1985] MA61,RA65..5F |
90101-10105 |
— | ||
|
31301J
|
31301J
90170-10114 Nut, Exhaust Pipe Set Stud Bolt[04.1982 - 12.1985] MA61,RA65..5F |
90170-10114 |
US $1.40 |
||
|
31305
|
31305
55107-14100
Bracket Sub-Assy, Clutch Pedal
[08.1983 - 12.1985] MA61,RA65..RHD..5F |
55107-14100 |
— | ||
|
31321
|
31321
31321-14020 Pad, Clutch Pedal[08.1981 - 12.1985] AA63,MA61,RA6#,SA63,TA60..5F |
31321-14020 |
from US $3.20 |
||
| replacement | |||||
|
31321
|
31321
31321YE010
PAD PEDAL
[08.1981 - 12.1985] AA63,MA61,RA6#,SA63,TA60..5F |
31321YE010 |
— | ||
|
31324
|
31324
90101-10039 Shaft, Clutch Pedal[08.1981 - 12.1985] AA63,MA61,RA6#,SA63,TA60..5F |
90101-10039 |
US $2.56 |
||
|
31324A
|
31324A
90387-10021 Collar, Clutch Pedal Shaft[08.1981 - 12.1985] AA63,MA61,RA6#,SA63..RHD..5F |
90387-10021 |
US $7.28 |
||
|
31356C
|
31356C
90386-08014
Bush(For Over Center Adjusting Rod)
[08.1983 - 12.1985] MA61,RA65..5F |
90386-08014 |
— | ||
|
31356E
|
31356E
90506-09024 Spring(For Over Center Adjusting Rod)[12.1981 - 12.1985] MA61,RA65..RHD..5F |
90506-09024 |
US $8.30 |
||
|
31357
|
31357
31357-24030
Plate, Clutch Pedal Over Center, No.2
[02.1983 - 12.1985] MA61,RA65..RHD..5F |
31357-24030 |
— | ||
|
31358
|
31358
31358-14010 Cap, Over Center Spring[08.1983 - 12.1985] MA61,RA65..RHD..5F |
31358-14010 |
US $13.40 |
||
|
31453A
|
31453A
90240-08006 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[07.1982 - 12.1985] AA63,MA61,RA6#,SA63,TA60..5F L=23.5,L=23.5 |
90240-08006 |
from US $1.85 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[08.1981 - 12.1985] AA63,MA61,RA6#,SA63..RHD..5F |
90386-08002 |
from US $3.84 |
||
|
9017008003
|
9017008003
90170-08003
New Genuine Part
|
90170-08003 |
— | ||
|
9017008006
|
9017008006
90170-08006 New Genuine Part |
90170-08006 |
US $1.22 |
||
|
9020608001
|
9020608001
90206-08001 WASHER |
90206-08001 |
US $1.92 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9165540820
|
9165540820
91655-40820
New Genuine Part
|
91655-40820 |
— | ||
| replacement | |||||
|
9165540820
|
9165540820
91653-40820 BOLT, W/WASHER |
91653-40820 |
US $1.76 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.88 |
||
|
9411071000
|
9411071000
94110-71000 Nut(For Backing Plate To Rear Axle Housing Setting) |
94110-71000 |
US $2.72 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.76 |
||
|
9454100800
|
9454100800
94541-00800 New Genuine Part |
94541-00800 |
US $1.60 |
||
|
9461110800
|
9461110800
94611-10800 Washer, Plate (For Transmission Control Cable) |
94611-10800 |
from US $0.88 |
||
|
9461111001
|
9461111001
94611-11001 Plate, Rear Seat Back Stopper |
94611-11001 |
US $1.28 |
||
|
9616000600
|
9616000600
96160-00600 Ring, E(For Clutch Pedal Pawl) |
96160-00600 |
from US $0.86 |
||
