Rear Spring & Shock Absorber ([10.1986 - ] (8610- )ST165) Diagram Toyota CELICA
- Year
- 1986 - 1987
- Sales region
- Japan
- Frame
- ST165
- grade
- GT4
- body
- LB
- ENGINE
- 3SGTE
- TRANSMISSION
- MTM
- From
- 10.1986
- To
- 08.1987
- Gear Shift Type
- 5F
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42304
|
42304
42304-20030 Carrier Sub-Assy, Rear Axle, Rh[10.1986 - 08.1987] ST165 |
42304-20030 |
US $257.71 |
||
| replacement | |||||
|
42304
|
42304
42304-20280
Carrier Sub-Assy, Rear Axle, Rh
[10.1986 - 08.1987] ST165 |
42304-20280 |
— | ||
|
42304A
|
42304A
90105-15001 Bolt (For Rear Axle Carrier)[10.1986 - 08.1987] ST165 |
90105-15001 |
from US $3.65 |
||
|
42304B
|
42304B
90179-15001 Nut (For Rear Axle Carrier)[10.1986 - 08.1987] ST165 |
90179-15001 |
from US $3.14 |
||
|
42305
|
42305
42305-20030 Carrier Sub-Assy, Rear Axle, Lh[10.1986 - 08.1987] ST165 |
42305-20030 |
US $257.71 |
||
| replacement | |||||
|
42305
|
42305
42305-20280
Carrier Sub-Assy, Rear Axle, Lh
[10.1986 - 08.1987] ST165 |
42305-20280 |
— | ||
|
48194A
|
48194A
48194-32020
Cam, Camber Adjust, Rh
[10.1986 - 08.1987] ST165 |
48194-32020 |
— | ||
|
48198R
|
48198R
48198-32020
Cam, Camber Adjust, Lh
[10.1986 - 08.1987] ST165 |
48198-32020 |
— | ||
|
48231
|
48231
48231-20540 Spring, Coil, Rear[10.1986 - 08.1987] ST165 |
48231-20540 |
US $123.76 |
||
|
48257A
|
48257A
48258-16010 Insulator, Rear Coil Spring, Lower[10.1986 - 08.1987] ST165 |
48258-16010 |
US $11.68 |
||
|
48257B
|
48257B
48257-32030
Insulator, Rear Coil Spring
[10.1986 - 08.1987] ST165 |
48257-32030 |
— | ||
|
48341
|
48341
48341-20100 Bumper, Rear Spring[10.1986 - 08.1987] ST165 |
48341-20100 |
US $20.24 |
||
|
48409
|
48409
48409-20030
Cam Sub-Assy, Rear Suspension Toe Adjust
[10.1986 - 08.1987] ST165 |
48409-20030 |
— | ||
|
48452R
|
48452R
48452-20010 Plate, Rear Suspension Toe Adjust, No.2[10.1986 - 08.1987] ST165 |
48452-20010 |
US $17.94 |
||
|
48530
|
48530
48530-20170 Absorber Assy, Shock, Rear Rh[10.1986 - 08.1987] ST165 |
48530-20170 |
US $317.41 |
||
| replacements | |||||
|
48530
|
48530
48530-20171 Absorber Assy, Shock, Rear Rh[10.1986 - 08.1987] ST165 |
48530-20171 |
US $315.95 |
||
|
48530
|
48530
90561-15006 New Genuine Part[10.1986 - 08.1987] ST165 |
90561-15006 |
US $7.13 |
||
|
48540
|
48540
48540-20170 Absorber Assy, Shock, Rear Lh[10.1986 - 08.1987] ST165 |
48540-20170 |
US $313.04 |
||
| replacements | |||||
|
48540
|
48540
48540-20171
Absorber Assy, Shock, Rear Lh
[10.1986 - 08.1987] ST165 |
48540-20171 |
— | ||
|
48540
|
48540
90561-15006 New Genuine Part[10.1986 - 08.1987] ST165 |
90561-15006 |
US $7.13 |
||
|
48703C
|
48703C
90170-14006 Nut[01.1987 - 08.1987] ST165 |
90170-14006 |
from US $1.92 |
||
|
48703C
|
48703C
90179-14031 Nut(For Rear Suspension Arm)[10.1986 - 01.1987] ST165 |
90179-14031 |
US $3.64 |
||
|
48703D
|
48703D
90209-13005 Washer(For Rear Suspension Arm)[10.1986 - 08.1987] ST165 |
90209-13005 |
US $8.80 |
||
|
48703E
|
48703E
90119-12083 Bolt(For Front Suspension Lower Arm)[10.1986 - 08.1987] ST165 ＊１２−１．２５ＰＸ８０−２５,BODY SIDE,RR |
90119-12083 |
US $6.40 |
||
|
48703E
|
48703E
90119-12126 Bolt(For Rear Suspension Arm)[10.1986 - 08.1987] ST165 ＊１２−１．２５ＰＸ９４−３５,BODY SIDE,FR |
90119-12126 |
from US $3.39 |
||
|
48703E
|
48703E
90119-14024 Bolt(For Rear Suspension Arm)[10.1986 - 08.1987] ST165 ＊１４−１．５０ＰＸ７３−６７,CARRIER SIDE |
90119-14024 |
US $5.24 |
||
|
48710A
|
48710A
48710-20070
Arm Assy, Rear Suspension, No.1 Rh
[10.1986 - 08.1987] ST165 |
48710-20070 |
— | ||
|
48720A
|
48720A
48710-20070
Arm Assy, Rear Suspension, No.1 Rh
[10.1986 - 08.1987] ST165 |
48710-20070 |
— | ||
|
48730A
|
48730A
48730-20020
Arm Assy, Rear Suspension, No.2
[10.1986 - 08.1987] ST165 |
48730-20020 |
— | ||
|
48750
|
48750
48750-20040 Support Assy, Rear Suspension[10.1986 - 08.1987] ST165 |
48750-20040 |
US $75.71 |
||
|
48750G
|
48750G
90179-08111 Nut(For Rear Suspension Support)[04.1986 - 08.1987] AT160,ST16# |
90179-08111 |
US $1.44 |
||
|
48753
|
48753
48753-16010
Cover, Rear Suspension Support
[10.1986 - 08.1987] ST165 |
48753-16010 |
— | ||
|
48780A
|
48780A
48780-20030
Rod Assy, Strut, Rear
[10.1986 - 08.1987] ST165 |
48780-20030 |
— | ||
|
48780B
|
48780B
90105-12082 Bolt(For Strut Rod)[08.1986 - 01.1987] AT160,ST16# |
90105-12082 |
US $6.08 |
||
|
48780B
|
48780B
90119-12131 Bolt(For Strut Rod)[01.1987 - 08.1987] AT160,ST16# |
90119-12131 |
from US $3.57 |
||
| replacement | |||||
|
48780B
|
48780B
90080-11133 Bolt(For Strut Rod)[01.1987 - 08.1987] AT160,ST16# |
90080-11133 |
US $10.95 |
||
|
48780C
|
48780C
90179-12062 Nut(For Rear Suspension Arm)[08.1986 - 08.1987] AT160,ST16# CARRIER SIDE |
90179-12062 |
from US $2.54 |
||
|
48780C
|
48780C
90179-12063 Nut(For Rear Suspension Arm)[08.1986 - 08.1987] AT160,ST16# BODY SIDE |
90179-12063 |
from US $1.95 |
||
|
48805
|
48805
48812-20200 Bar Sub-Assy, Rear Stabilizer[10.1986 - 08.1987] ST165 |
48812-20200 |
US $123.76 |
||
|
48815R
|
48815R
48818-20110 Bush, Stabilizer(For Rear)[10.1986 - 08.1987] ST165 |
48818-20110 |
US $8.15 |
||
| replacement | |||||
|
48815R
|
48815R
48818-12170 Bush, Stabilizer, Rear[10.1986 - 08.1987] ST165 |
48818-12170 |
from US $10 |
||
|
48824R
|
48824R
48832-20030 Bracket, Stabilizer(For Rear)[10.1986 - 08.1987] ST165 |
48832-20030 |
from US $3.84 |
||
|
48830
|
48830
48830-20010 Link Assy, Rear Stabilizer[08.1985 - 08.1987] AT160,ST16# |
48830-20010 |
from US $64.33 |
||
|
48830A
|
48830A
90179-10054 Nut, No.1 (For Center Support Bearing)[08.1985 - 08.1987] AT160,ST16# |
90179-10054 |
from US $0.37 |
||
|
9161560820
|
9161560820
91615-60820
Bolt (For Transmission Control Cable Bracket)
|
91615-60820 |
— | ||
| replacement | |||||
|
9161560820
|
9161560820
91611-B0816 Bolt |
91611-B0816 |
from US $1.09 |
||
|
9418211400
|
9418211400
94182-11400 Nut(For Idler Arm Support) |
94182-11400 |
US $4.96 |
||
