Steering Column & Shaft ([03.1973 - ] (7303- )) Diagram Toyota CENTURY
- Year
- 1977 - 1978
- Sales region
- Japan
- Frame
- VG30
- ENGINE
- 4VU
- TRANSMISSION
- ATM
- From
- 01.1977
- To
- 11.1978
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44101
|
44101
45240-40020
Worm Sub-Assy, Steering
[03.1969 - 09.1982] VG2#,3# |
45240-40020 |
— | ||
|
44101A
|
44101A
90311-17062
Seal, Type T Oil(For Steering Worm)
[03.1969 - 09.1982] VG2#,3# |
90311-17062 |
— | ||
| replacement | |||||
|
44101A
|
44101A
90311-17092
Seal, Oil(For Steering Worm)
[03.1969 - 09.1982] VG2#,3# |
90311-17092 |
— | ||
|
44101B
|
44101B
90369-41011
Bearing(For Steering Worm)
[03.1969 - 09.1982] VG2#,3# |
90369-41011 |
— | ||
|
44107
|
44107
45311-40030
Housing Sub-Assy, Power Steering Gear
[05.1975 - 09.1982] VG21,3# |
45311-40030 |
— | ||
|
44107A
|
44107A
90364-28022
Bearing, Needle Roller(For Power Steering Gear Housing)
[03.1969 - 09.1982] VG2#,3# |
90364-28022 |
— | ||
|
44107F
|
44107F
90430-10035 Gasket(For Water Hole)[03.1969 - 09.1982] VG2#,3# |
90430-10035 |
from US $1.05 |
||
| replacement | |||||
|
44107F
|
44107F
9008943009
Gasket V P Oil Inlet
[03.1969 - 09.1982] VG2#,3# |
9008943009 |
— | ||
|
44107G
|
44107G
90113-06036
Bolt, Stud(For Power Steering Gear Housing)
[03.1969 - 09.1982] VG2#,3# D=6.0,P=1.0 |
90113-06036 |
— | ||
|
44107G
|
44107G
90113-12037
Bolt, Stud(For Power Steering Gear Housing)
[03.1969 - 09.1982] VG2#,3# D=12,P=1.25 |
90113-12037 |
— | ||
|
44107H
|
44107H
90345-52019
Plug(For Power Steering Gear Housing)
[08.1969 - 09.1982] VG2#,3# |
90345-52019 |
— | ||
|
44108
|
44108
45321-40010
Cover Sub-Assy, Side
[03.1969 - 09.1982] VG2#,3# |
45321-40010 |
— | ||
|
44108B
|
44108B
45322-40010
Gasket(For Side Cover)
[03.1969 - 09.1982] VG2#,3# |
45322-40010 |
— | ||
|
44110
|
44110
45310-40050
Gear Assy, Power Steering
[05.1975 - 09.1982] VG21,3# |
45310-40050 |
— | ||
|
44111
|
44111
45351-40020
Shaft, Cross
[03.1969 - 09.1982] VG2#,3# |
45351-40020 |
— | ||
|
44111A
|
44111A
94125-42000 Nut, Hexagon(For Cross Shaft To Pitman Arm Setting)[08.1969 - 09.1982] VG2#,3# |
94125-42000 |
US $2.33 |
||
|
44111C
|
44111C
90313-28007
Seal, Oil(For Cross Shaft)
[03.1969 - 09.1982] VG2#,3# |
90313-28007 |
— | ||
|
44141
|
44141
45242-40020
Plug, Adjuster
[05.1975 - 09.1982] VG21,3# |
45242-40020 |
— | ||
|
44141A
|
44141A
90301-58154
Ring, O(For Adjuster Plug)
[05.1975 - 09.1982] VG21,3# |
90301-58154 |
— | ||
|
44142
|
44142
45243-30040
Nut, Lock
[07.1971 - 09.1982] VG2#,3# |
45243-30040 |
— | ||
|
44210
|
44210
44210-40020 Valve Assy, Power Steering Control[05.1975 - 09.1982] VG21,3# |
44210-40020 |
US $562.02 |
||
|
44210A
|
44210A
90170-20147 Nut, Hexagon(For Cross Shaft To Pitman Arm Setting)[03.1973 - 09.1982] VG21,3# |
90170-20147 |
US $4.96 |
||
|
44251
|
44251
45411-40010
Arm, Pitman
[11.1967 - 09.1982] VG2#,3# |
45411-40010 |
— | ||
|
44252
|
44252
45352-40010
Washer, Cross Shaft Thrust
[03.1969 - 09.1982] VG2#,3# T=1.515-1.535 |
45352-40010 |
— | ||
|
44252
|
44252
45353-40010
Washer, Cross Shaft Thrust
[03.1969 - 09.1982] VG2#,3# T=1.545-1.565 |
45353-40010 |
— | ||
|
44252
|
44252
45354-40010
Washer, Cross Shaft Thrust
[03.1969 - 09.1982] VG2#,3# T=1.575-1.595 |
45354-40010 |
— | ||
|
44252
|
44252
45355-40010
Washer, Cross Shaft Thrust
[03.1969 - 09.1982] VG2#,3# T=1.605-1.625 |
45355-40010 |
— | ||
|
44252
|
44252
45356-40010
Washer, Cross Shaft Thrust
[03.1969 - 09.1982] VG2#,3# T=1.635-1.655 |
45356-40010 |
— | ||
|
44257
|
44257
45357-40020
Screw, Cross Shaft Adjusting
[03.1969 - 09.1982] VG2#,3# |
45357-40020 |
— | ||
|
9010110222
|
9010110222
90101-10222
New Genuine Part
|
90101-10222 |
— | ||
|
9010112280
|
9010112280
90101-12280
New Genuine Part
|
90101-12280 |
— | ||
|
9010112292
|
9010112292
90101-12292
New Genuine Part
|
90101-12292 |
— | ||
|
9017610007
|
9017610007
90176-10007
New Genuine Part
|
90176-10007 |
— | ||
|
9021012020
|
9021012020
90210-12020
New Genuine Part
|
90210-12020 |
— | ||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $2.08 |
||
|
9411551200
|
9411551200
94115-51200 Nut(For Backing Plate To Steering Knuckle Setting) |
94115-51200 |
US $2.72 |
||
|
9412041000
|
9412041000
94120-41000 Nut(For Clutch Pedal Stopper) |
94120-41000 |
from US $0.80 |
||
| replacement | |||||
|
9412041000
|
9412041000
90170-A0002 Nut |
90170-A0002 |
US $2.33 |
||
|
9412541200
|
9412541200
94125-41200 Nut, Steering Wheel Set |
94125-41200 |
from US $1.22 |
||
|
9451101000
|
9451101000
94511-01000 Washer(For Rear Drive Shaft) |
94511-01000 |
US $1.76 |
||
|
9451201200
|
9451201200
94512-01200 Washer |
94512-01200 |
from US $0.76 |
||
|
9451202000
|
9451202000
94512-02000 New Genuine Part |
94512-02000 |
US $3.68 |
||
