Front Spring & Shock Absorber ([08.1984 - ] (8408- )TWC) Diagram Toyota CHASER
- Year
- 1984 - 1988
- Sales region
- Japan
- Frame
- GX71
- grade
- AVT
- body
- HT
- ENGINE
- 1GGEU
- TRANSMISSION
- ATM
- From
- 08.1984
- To
- 08.1988
- Gear Shift Type
- 4FC
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48660
|
48660
48660-22060 Bar Assy, Strut, Rh[08.1984 - 04.1985] GX71,LX70,MX71,SX70,YX70 |
48660-22060 |
US $63.04 |
||
| replacement | |||||
|
48660
|
48660
48660-22070
Bar Assy, Strut, Rh
[08.1984 - 04.1985] GX71,LX70,MX71,SX70,YX70 |
48660-22070 |
— | ||
|
48660
|
48660
48660-22070
Bar Assy, Strut, Rh
[04.1985 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
48660-22070 |
— | ||
|
48670
|
48670
48670-22060 Bar Assy, Strut, Lh[08.1984 - 04.1985] GX71,LX70,MX71,SX70,YX70 |
48670-22060 |
US $63.04 |
||
| replacement | |||||
|
48670
|
48670
48670-22070
Bar Assy, Strut, Lh
[08.1984 - 04.1985] GX71,LX70,MX71,SX70,YX70 |
48670-22070 |
— | ||
|
48670
|
48670
48670-22070
Bar Assy, Strut, Lh
[04.1985 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
48670-22070 |
— | ||
|
48674A
|
48674A
90948-02079
Retainer, Cushion(For Strut Bar Cushion)
[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# T=3.8(FR) |
90948-02079 |
— | ||
|
48674A
|
48674A
90948-02080
Retainer, Cushion(For Strut Bar Cushion)
[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# T=3.2(RR) |
90948-02080 |
— | ||
|
48674D
|
48674D
90560-18006
Spacer(For Strut Bar Cushion)
[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
90560-18006 |
— | ||
|
48811
|
48811
48811-22230 Bar, Stabilizer, Front[08.1984 - 08.1988] GX71..TWC |
48811-22230 |
US $131.04 |
||
|
48815
|
48815
48815-22070 Bush, Front Stabilizer Bar, No.1[08.1984 - 08.1988] GX71,MX71..TBO,TWC,TWT |
48815-22070 |
US $9.90 |
||
| replacement | |||||
|
48815
|
48815
48815-22150 Bush, Front Stabilizer Bar, No.1[08.1984 - 08.1988] GX71,MX71..TBO,TWC,TWT |
48815-22150 |
from US $10.16 |
||
|
48817
|
48817
48817-22020 Cushion, Front Stabilizer[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
48817-22020 |
from US $2.67 |
||
|
48817A
|
48817A
90948-02032 Retainer, Cushion, No.1(For Front Stabilizer Bar)[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
90948-02032 |
from US $2.18 |
||
|
48817B
|
48817B
90948-02015 Retainer, Cushion, No.1(For Front Stabilizer Bar)[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
90948-02015 |
from US $0.96 |
||
|
48817D
|
48817D
48819-24010 Bolt(For Front Stabilizer)[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
48819-24010 |
US $9.14 |
||
|
48824
|
48824
48824-22060
Bracket, Stabilizer, Front
[08.1984 - 08.1988] GX71,LX70,MX71,SX70,YX7# |
48824-22060 |
— | ||
|
9017010022
|
9017010022
90170-10022 Nut(For Rear Spring U Bolt) |
90170-10022 |
from US $1.15 |
||
|
9017918007
|
9017918007
90179-18007 NUT |
90179-18007 |
US $4.02 |
||
|
9020110074
|
9020110074
90201-10074 New Genuine Part |
90201-10074 |
US $3.49 |
||
|
9020110287
|
9020110287
90201-10287 Washer(For Front Wheel Cylinder) |
90201-10287 |
US $3.05 |
||
|
9161640825
|
9161640825
91616-40825
Bolt(For Clutch Master Cylinder Setting)
|
91616-40825 |
— | ||
| replacement | |||||
|
9161640825
|
9161640825
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.11 |
||
|
9418210800
|
9418210800
94182-10800 Nut |
94182-10800 |
from US $1.38 |
||
