Ignition Coil & Spark Plug ([10.1992 - ] (9210- )2LTE) Diagram Toyota CHASER
- Year
- 1992 - 1996
- Sales region
- Japan
- Frame
- LX90
- grade
- XL
- ENGINE
- 2LTE
- TRANSMISSION
- ATM
- From
- 10.1992
- To
- 09.1996
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
19850
|
19850
19850-54110 Plug Assy, Glow[10.1992 - 09.1996] 2LTE..LX90 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54110 |
US $90.27 |
||
| replacement | |||||
|
19850
|
19850
19850-54130 Plug Assy, Glow[10.1992 - 09.1996] 2LTE..LX90 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54130 |
US $57.37 |
||
|
19856
|
19856
90179-04019 Nut, Connecting(For Glow Plug)[10.1992 - 08.1995] 2LTE..LX90 |
90179-04019 |
US $2.15 |
||
|
19856
|
19856
90179-04030 Nut, Connecting(For Glow Plug)[08.1995 - 09.1996] 2LTE..LX90 |
90179-04030 |
US $1.08 |
||
|
19856A
|
19856A
90189-04024 Grommet, Screw(For Glow Plug)[08.1995 - 09.1996] 2LTE..LX90 |
90189-04024 |
from US $0.68 |
||
|
19871
|
19871
19871-54040 Connector, Glow Plug No.1[10.1992 - 09.1996] 2LTE..LX90 |
19871-54040 |
US $28.39 |
||
