Throttle Link & Valve Lever (Atm) ([10.1981 - ] (8110- )MX61 ; (8208- )SX60..4FC) Diagram Toyota CHASER
- Year
- 1981 - 1984
- Sales region
- Japan
- Frame
- MX61
- grade
- AVT
- body
- HT
- ENGINE
- MTEU
- TRANSMISSION
- ATM
- From
- 10.1981
- To
- 07.1984
- Gear Shift Type
- 4FC
- Fuel Induction
- TBO
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35520
|
35520
35520-24030 Cable Assy, Throttle[10.1981 - 07.1984] MX61 |
35520-24030 |
US $117.94 |
||
|
35520B
|
35520B
90301-09004
Ring, O(For Throttle Cable)
[05.1983 - 07.1984] GX61,LX6#,MX61,SX60..4FC |
90301-09004 |
— | ||
|
35520B
|
35520B
90301-09063 Ring, O(For Throttle Cable)[09.1980 - 05.1983] GX6#,LX6#,MX61,RX60,SX60,TX60..ATM |
90301-09063 |
US $2.91 |
||
| replacement | |||||
|
35520B
|
35520B
90301-09004
Ring, O(For Throttle Cable)
[09.1980 - 05.1983] GX6#,LX6#,MX61,RX60,SX60,TX60..ATM |
90301-09004 |
— | ||
|
35523
|
35523
35523-30030 Clamp, Throttle Cable[08.1983 - 07.1984] MX61 |
35523-30030 |
US $9.76 |
||
|
35527
|
35527
35527-24020
Insulator, Throttle Cable Heat
[10.1981 - 08.1983] MX61 |
35527-24020 |
— | ||
|
9046106052
|
9046106052
90461-06052 New Genuine Part |
90461-06052 |
US $4.37 |
||
|
9046106966
|
9046106966
90461-06966
New Genuine Part
|
90461-06966 |
— | ||
|
9111150812
|
9111150812
91111-50812 Bolt (for Transmission Control Cable Bracket) |
91111-50812 |
US $3.06 |
||
| replacement | |||||
|
9111150812
|
9111150812
91611-60814 Bolt |
91611-60814 |
from US $0.80 |
||
|
9161140610
|
9161140610
91611-40610
Bolt(For Dust Cover To Steering Knuckle Arm Setting)
|
91611-40610 |
— | ||
| replacement | |||||
|
9161140610
|
9161140610
91611-B0610 Bolt (For Transfer Oil Receiver No.1) |
91611-B0610 |
US $1.12 |
||
|
9161140812
|
9161140812
91611-40812
Bolt(for Drive Plate & Torque Converter Setting)
|
91611-40812 |
— | ||
| replacement | |||||
|
9161140812
|
9161140812
91611-B0812 Bolt |
91611-B0812 |
from US $0.76 |
||
|
9165140610
|
9165140610
91651-40610 RIVET |
91651-40610 |
US $2.56 |
||
|
9451100800
|
9451100800
94511-00800 WASHERSPRING |
94511-00800 |
from US $1.60 |
||
