Heating & Air Conditioning - Cooler Piping ([08.1977 - ] (7708- )BC) Diagram Toyota COASTER
- Year
- 1979 - 1982
- Sales region
- Europe
- Frame
- BB10
- grade
- BC
- Roof
- HRF
- ENGINE
- 2B
- DESTINATION
- GEN
- Model
- COASTER
- From
- 11.1979
- To
- 04.1982
- Gear Shift Type
- 5F
- Seating Capacity
- 21S
- Vehicle Model
- Coaster
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88367
|
88367
88454-36061
Shroud, Cooler Blower Fan
[02.1978 - 04.1982] BB10,RB11,13..BC |
88454-36061 |
— | ||
|
88450
|
88450
88450-36030
Condenser Assy, W/receiver
[08.1977 - 04.1982] BB10..BC |
88450-36030 |
— | ||
|
88453
|
88453
88453-36030
Fan, Cooling (For Condenser)
[08.1977 - 04.1982] BB10,RB11,13..BC |
88453-36030 |
— | ||
|
88460
|
88460
88340-36050
Condenser Assy, Cooler
[08.1977 - 04.1982] BB10,RB11,13..BC |
88340-36050 |
— | ||
|
88470
|
88470
88471-30260 Receiver & Dryer Assy, CoolerCOOLER [08.1977 - 04.1982] BB10,RB11,13..BC |
88471-30260 |
US $161.62 |
||
|
88550
|
88550
88550-36070
Motor Assy, Blower (For Condenser)
[08.1977 - 04.1982] BB10..BC |
88550-36070 |
— | ||
|
88716A
|
88716A
88716-36081
Pipe, Cooler Refrigerant Liquid, A
[02.1978 - 04.1982] BB10,RB11,13..BC |
88716-36081 |
— | ||
|
88716B
|
88716B
88716-36091
Pipe, Cooler Refrigerant Liquid, B
[02.1978 - 04.1982] BB10,RB11,13..BC |
88716-36091 |
— | ||
|
9017908096
|
9017908096
90179-08096 NUT |
90179-08096 |
from US $1.46 |
||
| replacement | |||||
|
9017908096
|
9017908096
90080-18061 New Genuine Part |
90080-18061 |
US $4.47 |
||
|
9163161025
|
9163161025
91631-61025
New Genuine Part
|
91631-61025 |
— | ||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $2.08 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.76 |
||
