Rear Spring & Shock Absorber ([12.1995 - 05.1997] (9512-9705)ST) Diagram Toyota COASTER
- Year
- 1995 - 1997
- Sales region
- Japan
- Frame
- BB55
- grade
- LX
- Roof
- HRF
- ENGINE
- 15BF
- TRANSMISSION
- ATM
- COOLER
- WC
- Model
- COASTER
- From
- 12.1995
- To
- 05.1997
- Gear Shift Type
- 4FC
- Seating Capacity
- 29S
- Vehicle Model
- Coaster
- Fuel Induction
- DSL4
- Building Condition
- CBU
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48107A
|
48107A
48107-65010 Arm Sub-Assy, Anchor, Rh[12.1995 - 05.1997] BB55..ST |
48107-65010 |
US $60.63 |
||
|
48108A
|
48108A
48108-65010 Arm Sub-Assy, Anchor, Lh[12.1995 - 05.1997] BB55..ST |
48108-65010 |
US $60.63 |
||
|
48161A
|
48161A
48161-36160 Spring, Rear Torsion Bar, Rh[12.1995 - 05.1997] BB55..ST |
48161-36160 |
US $432.43 |
||
|
48162A
|
48162A
48162-36160 Spring, Rear Torsion Bar, Lh[12.1995 - 05.1997] BB55..ST |
48162-36160 |
US $432.43 |
||
|
48173E
|
48173E
48173-36010 Seat, Anchor Arm Adjuster[12.1995 - 05.1997] BB55..ST ＮＯ．１ |
48173-36010 |
US $8.44 |
||
|
48173E
|
48173E
48173-36020 Seat, Anchor Arm Adjuster[12.1995 - 05.1997] BB55..ST ＮＯ．２ |
48173-36020 |
US $10.05 |
||
|
48174C
|
48174C
48174-65010 Cover, Torsion Bar Dust[12.1995 - 05.1997] BB55..ST |
48174-65010 |
US $11.52 |
||
|
48530
|
48530
48530-36010 Absorber Assy, Shock, Rear Rh[12.1995 - 05.1997] BB55..ST マーク ４８５３０−３６０１０ |
48530-36010 |
US $115.02 |
||
|
48532
|
48532
48532-36050 Pin, Rear Shock Absorber Pivot[12.1995 - 05.1997] BB55..ST |
48532-36050 |
US $30.14 |
||
|
48533
|
48533
48533-36100 Pin, Rear Shock Absorber Lower Pivot, Rh[12.1995 - 05.1997] BB55..ST |
48533-36100 |
US $30.28 |
||
|
48533A
|
48533A
48533-36100 Pin, Rear Shock Absorber Lower Pivot, Rh[12.1995 - 05.1997] BB55..ST |
48533-36100 |
US $30.28 |
||
|
48540
|
48540
48530-36010 Absorber Assy, Shock, Rear Rh[12.1995 - 05.1997] BB55..ST マーク ４８５３０−３６０１０ |
48530-36010 |
US $115.02 |
||
|
48635A
|
48635A
48635-65010 Bush, Upper Arm, Rear[12.1995 - 05.1997] BB55..ST |
48635-65010 |
US $9.03 |
||
|
9010116032
|
9010116032
90101-16032 New Genuine Part |
90101-16032 |
US $3.20 |
||
|
9010116036
|
9010116036
90101-16036 New Genuine Part |
90101-16036 |
US $4.08 |
||
|
9010118006
|
9010118006
90101-18006 New Genuine Part |
90101-18006 |
US $11.53 |
||
|
9017016022
|
9017016022
90170-16022 New Genuine Part |
90170-16022 |
US $2.56 |
||
|
9017018009
|
9017018009
90170-18009 New Genuine Part |
90170-18009 |
US $2.91 |
||
|
9017916026
|
9017916026
90179-16026 New Genuine Part |
90179-16026 |
US $1.92 |
||
|
9034506014
|
9034506014
90345-06014 Plug (For Ball Joint) |
90345-06014 |
from US $1.76 |
