Manifold ([05.1995 - 07.1999] (9505-9907)1HDFT) Diagram Toyota COASTER
- Year
- 1997 - 1999
- Sales region
- Japan
- Frame
- HDB51
- grade
- EX
- Roof
- HRF
- ENGINE
- 1HDFT
- TRANSMISSION
- MTM
- COOLER
- WC
- Model
- COASTER
- From
- 05.1997
- To
- 07.1999
- Gear Shift Type
- 6F
- Seating Capacity
- 29S
- Vehicle Model
- Coaster
- Fuel Induction
- TD4
- Building Condition
- CBU
- Rear Tire
- WT
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-17020
Gasket Kit, Turbocharger
[05.1995 - 07.1999] 1HDFT..HDB5# |
04175-17020 |
— | ||
|
04176
|
04176
04176-58011 Seal Kit, Turbocharger[01.1993 - 07.1999] 1HD#..HDB5# |
04176-58011 |
US $9.26 |
||
|
16347
|
16347
16347-42020 Gasket, Water By-Pass[01.1993 - 07.1999] 1HD#..HDB5# |
16347-42020 |
from US $2.85 |
||
|
17021
|
17021
17021-58010 Housing Sub-Assy, Bearing[01.1993 - 07.1999] 1HD#..HDB5# |
17021-58010 |
US $1,761.76 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[01.1993 - 07.1999] 1HD#..HDB5# |
90116-08158 |
from US $1.76 |
||
|
17021B
|
17021B
90116-06048 Bolt, Stud(For Oil Pan)[01.1993 - 07.1999] 1HD#..HDB5# |
90116-06048 |
from US $0.72 |
||
|
17021C
|
17021C
90521-99023 Ring, Hole Snap(For Bearing Housing)[01.1993 - 07.1999] 1HD#..HDB5# |
90521-99023 |
US $5.77 |
||
|
17025A
|
17025A
90116-10125 Bolt, Stud(For Turbine Housing)[01.1993 - 07.1999] 1HD#..HDB5# |
90116-10125 |
from US $1.48 |
||
|
17201
|
17201
17201-17030
Turbocharger Sub-Assy
[05.1995 - 07.1999] 1HDFT..HDB5# |
17201-17030 |
— | ||
|
17224
|
17224
17224-17010 Housing, Compressor[12.1994 - 07.1999] 1HD#..HDB5# |
17224-17010 |
US $257.71 |
||
|
17224A
|
17224A
90404-51041 Union(For Compressor Housing)[01.1993 - 07.1999] 1HD#..HDB5# |
90404-51041 |
US $3.67 |
||
|
17229
|
17229
17229-58010 Band, V[01.1993 - 07.1999] 1HD#..HDB5# |
17229-58010 |
US $35.12 |
||
|
17230A
|
17230A
17230-19015 Repair Actuaor Assy, W/bracket[05.1995 - 07.1999] 1HDFT..HDB5# |
17230-19015 |
US $519.79 |
||
|
17230B
|
17230B
90201-08081 Washer, Plate(For Repair Actuator Set)[05.1995 - 07.1999] 1HDFT..HDB5# 厚さ＝０．５ |
90201-08081 |
US $2.24 |
||
|
17230B
|
17230B
90201-08082 Washer, Plate(For Repair Actuator Set)[05.1995 - 07.1999] 1HDFT..HDB5# 厚さ＝１．０ |
90201-08082 |
US $1.60 |
||
|
17230B
|
17230B
90201-08086 Washer, Plate(For Repair Actuator Set)[05.1995 - 07.1999] 1HDFT..HDB5# 厚さ＝２．０ |
90201-08086 |
US $1.46 |
||
|
17230B
|
17230B
90201-08087 Washer, Plate(For Repair Actuator Set)[05.1995 - 07.1999] 1HDFT..HDB5# 厚さ＝３．０ |
90201-08087 |
US $1.89 |
||
|
17239
|
17239
17239-58010 Clamp, V, No.2[01.1993 - 07.1999] 1HD#..HDB5# |
17239-58010 |
US $30.93 |
||
|
17294
|
17294
17294-17010 Hose, Actuator[01.1993 - 07.1999] 1HD#..HDB5# |
17294-17010 |
US $25.68 |
||
|
17294A
|
17294A
96132-41100 Clamp Or Clip(For Radiator Reserve Tank Hose)[01.1993 - 07.1999] 1HD#..HDB5# |
96132-41100 |
US $1.92 |
||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[01.1993 - 07.1999] 1HD#..HDB5# |
96132-51100 |
from US $1.74 |
||
|
17296
|
17296
17296-28010 Plate, Bearing Housing, Side[01.1993 - 07.1999] 1HD#..HDB5# |
17296-28010 |
US $9.44 |
||
|
91631B0614
|
91631B0614
91631-B0614 BOLT WWASHER |
91631-B0614 |
from US $0.88 |
||
|
91651B0820
|
91651B0820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $1.11 |
||
| replacement | |||||
|
91651B0820
|
91651B0820
90080-11347 New Genuine Part |
90080-11347 |
US $2.48 |
||
|
9017908012
|
9017908012
90179-08012 NUT |
90179-08012 |
US $3.68 |
||
|
9025403013
|
9025403013
90254-03013 New Genuine Part |
90254-03013 |
US $0.70 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.28 |
||
|
9162160822
|
9162160822
91621-60822 Bolt, W/washer(For Repair Actuator Set) |
91621-60822 |
US $1.44 |
||
