Front Axle Housing & Differential ([07.2007 - ] EA60,EA61 (0707- )ADE150) Diagram Toyota COROLLA
- Year
- 2007 - 2014
- Sales region
- General
- Frame
- ADE150
- ENGINE
- 1ADFTV
- TRANSMISSION
- MTM
- DESTINATION
- SA
- Model
- COROLLA (S.AFRICA)
- From
- 07.2007
- To
- 01.2014
- Gear Shift Type
- 6F
- Vehicle Model
- Corolla
- Model Mark
- E
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31105D
|
31105D
90311-30017 Seal, Oil, No.1(For Front Transaxle Case)OIL, NO.1(FOR FRONT TRANSAXLE CASE) [07.2007 - 03.2009] ADE150 |
90311-30017 |
from US $4.64 |
||
|
31105H
|
31105H
90311-40030 Seal, Oil, No.2(For Transaxle Case)OIL(FOR FRONT TRANSAXLE CASE COVER) [07.2007 - 03.2009] ADE150 RH |
90311-40030 |
US $4.51 |
||
| replacement | |||||
|
31105H
|
31105H
90311-40036 Seal, Oil, No.2(For Transaxle Case)[07.2007 - 03.2009] ADE150 RH |
90311-40036 |
from US $4.96 |
||
|
31105H
|
31105H
90311-40036 Seal, Oil, No.2(For Transaxle Case)[02.2011 - 01.2014] ADE150 RH; ZRE153..6F |
90311-40036 |
from US $4.96 |
||
|
31105H
|
31105H
90311-50032
Seal, Oil(For Transmission Case)
[07.2007 - 03.2009] ADE150 LH |
90311-50032 |
— | ||
| replacement | |||||
|
31105H
|
31105H
90311-50046 Seal, Oil(For Transmission Case)[07.2007 - 03.2009] ADE150 LH |
90311-50046 |
from US $8.64 |
||
|
31105H
|
31105H
90311-50046 Seal, Oil(For Transmission Case)[01.2011 - 01.2014] ADE150 LH |
90311-50046 |
from US $8.64 |
||
|
31115C
|
31115C
31115-20080
Case, Front Transaxle(Mtm)
[07.2007 - 03.2009] ADE150 |
31115-20080 |
— | ||
| replacement | |||||
|
31115C
|
31115C
31115-20081
Case, Front Transaxle(Mtm)
[07.2007 - 03.2009] ADE150 |
31115-20081 |
— | ||
|
31115C
|
31115C
31115-20081
Case, Front Transaxle(Mtm)
[12.2011 - 01.2014] ADE150 |
31115-20081 |
— | ||
|
31115F
|
31115F
90105-12354 Bolt(For Front Transaxle Case)[07.2007 - 03.2009] ADE150 |
90105-12354 |
US $2.48 |
||
|
31115G
|
31115G
90430-13004 Gasket(For Front Transaxle Case)[07.2007 - 03.2009] ADE150 |
90430-13004 |
US $1.12 |
||
|
33449
|
33449
33449-60010 Magnet, Transmission[07.2007 - 03.2009] ADE150 |
33449-60010 |
from US $4.37 |
||
|
41221
|
41221
41221-20410 Gear, Front Differential RingFRONT DIFFERENTIAL RING [07.2007 - 03.2009] ADE150 |
41221-20410 |
US $128.13 |
||
|
41222B
|
41222B
90105-12319 Bolt (For Front Differential Ring Gear Set)[07.2007 - 03.2009] ADE150 |
90105-12319 |
US $1.76 |
||
|
41301L
|
41301L
41301-20250 Case Sub-Assy, Front Differential, No.1FRONT DIFFERENTIAL, NO.1 [07.2007 - 03.2009] ADE150 |
41301-20250 |
US $448.45 |
||
|
41311C
|
41311C
90564-56073
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.00,MARK 0 |
90564-56073 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56109
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.00,MARK 0 |
90564-56109 |
— | ||
|
41311C
|
41311C
90564-56074 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.05,MARK 1 |
90564-56074 |
US $5.53 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56110
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.05,MARK 1 |
90564-56110 |
— | ||
|
41311C
|
41311C
90564-56075 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.10,MARK 2 |
90564-56075 |
US $5.53 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56111
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.10,MARK 2 |
90564-56111 |
— | ||
|
41311C
|
41311C
90564-56076 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.15,MARK 3 |
90564-56076 |
US $5.53 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56112
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.15,MARK 3 |
90564-56112 |
— | ||
|
41311C
|
41311C
90564-56077
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.20,MARK 4 |
90564-56077 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56113
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.20,MARK 4 |
90564-56113 |
— | ||
|
41311C
|
41311C
90564-56078
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.25,MARK 5 |
90564-56078 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56114
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.25,MARK 5 |
90564-56114 |
— | ||
|
41311C
|
41311C
90564-56079
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.30,MARK 6 |
90564-56079 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56115
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.30,MARK 6 |
90564-56115 |
— | ||
|
41311C
|
41311C
90564-56080
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.35,MARK 7 |
90564-56080 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56116
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.35,MARK 7 |
90564-56116 |
— | ||
|
41311C
|
41311C
90564-56081
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.40,MARK 8 |
90564-56081 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56117
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.40,MARK 8 |
90564-56117 |
— | ||
|
41311C
|
41311C
90564-56082
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.45,MARK 9 |
90564-56082 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56118
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.45,MARK 9 |
90564-56118 |
— | ||
|
41311C
|
41311C
90564-56083
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.50,MARK A |
90564-56083 |
— | ||
| replacement | |||||
|
41311C
|
41311C
90564-56119
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.50,MARK A |
90564-56119 |
— | ||
|
41311C
|
41311C
90564-56084 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.55,MARK B |
90564-56084 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56120
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.55,MARK B |
90564-56120 |
— | ||
|
41311C
|
41311C
90564-56085 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.60,MARK C |
90564-56085 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56121
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.60,MARK C |
90564-56121 |
— | ||
|
41311C
|
41311C
90564-56086 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.65,MARK D |
90564-56086 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56122
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.65,MARK D |
90564-56122 |
— | ||
|
41311C
|
41311C
90564-56087 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.70,MARK E |
90564-56087 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56123
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.70,MARK E |
90564-56123 |
— | ||
|
41311C
|
41311C
90564-56088 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.75,MARK F |
90564-56088 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56124
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.75,MARK F |
90564-56124 |
— | ||
|
41311C
|
41311C
90564-56089 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.80,MARK G |
90564-56089 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56125
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.80,MARK G |
90564-56125 |
— | ||
|
41311C
|
41311C
90564-56090 Shim (For Front Differential Case Rear)[07.2007 - 03.2009] ADE150 T=2.85,MARK H |
90564-56090 |
US $6.55 |
||
| replacement | |||||
|
41311C
|
41311C
90564-56126
Shim (For Front Differential Case Rear)
[07.2007 - 03.2009] ADE150 T=2.85,MARK H |
90564-56126 |
— | ||
|
41311C
|
41311C
90564-56109
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.00,MARK 0 |
90564-56109 |
— | ||
|
41311C
|
41311C
90564-56110
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.05,MARK 1 |
90564-56110 |
— | ||
|
41311C
|
41311C
90564-56111
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.10,MARK 2 |
90564-56111 |
— | ||
|
41311C
|
41311C
90564-56112
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.15,MARK 3 |
90564-56112 |
— | ||
|
41311C
|
41311C
90564-56113
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.20,MARK 4 |
90564-56113 |
— | ||
|
41311C
|
41311C
90564-56114
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.25,MARK 5 |
90564-56114 |
— | ||
|
41311C
|
41311C
90564-56115
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.30,MARK 6 |
90564-56115 |
— | ||
|
41311C
|
41311C
90564-56116
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.35,MARK 7 |
90564-56116 |
— | ||
|
41311C
|
41311C
90564-56117
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.40,MARK 8 |
90564-56117 |
— | ||
|
41311C
|
41311C
90564-56118
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.45,MARK 9 |
90564-56118 |
— | ||
|
41311C
|
41311C
90564-56119
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.50,MARK A |
90564-56119 |
— | ||
|
41311C
|
41311C
90564-56120
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.55,MARK B |
90564-56120 |
— | ||
|
41311C
|
41311C
90564-56121
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.60,MARK C |
90564-56121 |
— | ||
|
41311C
|
41311C
90564-56122
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.65,MARK D |
90564-56122 |
— | ||
|
41311C
|
41311C
90564-56123
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.70,MARK E |
90564-56123 |
— | ||
|
41311C
|
41311C
90564-56124
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.75,MARK F |
90564-56124 |
— | ||
|
41311C
|
41311C
90564-56125
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.80,MARK G |
90564-56125 |
— | ||
|
41311C
|
41311C
90564-56126
Shim (For Front Differential Case Rear)
[07.2010 - 01.2014] ADE150 T=2.85,MARK H |
90564-56126 |
— | ||
|
41311E
|
41311E
90366-50100
Bearing, Tapered Roller (For Front Differential Case Front)
[07.2007 - 03.2009] ADE150 |
90366-50100 |
— | ||
|
41311F
|
41311F
90366-50103
Bearing, Tapered Roller (For Front Differential Case Front)
[07.2007 - 03.2009] ADE150 |
90366-50103 |
— | ||
|
41331F
|
41331F
41331-42040
Gear, Front Differential Side
[07.2007 - 03.2009] ADE150 |
41331-42040 |
— | ||
|
41341F
|
41341F
41341-35050 Pinion, Differential[07.2007 - 03.2009] ADE150 |
41341-35050 |
US $29.79 |
||
|
41342A
|
41342A
90250-06058 Pin, Straight(For Timing Gear Case)[07.2007 - 03.2009] ADE150 |
90250-06058 |
US $2.56 |
||
|
41342F
|
41342F
41342-20070 Shaft, Front Differential Pinion, No.1FRONT DIFFERENTIAL PINION, NO.1 [07.2007 - 03.2009] ADE150 |
41342-20070 |
US $21.11 |
||
|
41351F
|
41351F
41351-20050 Washer, Front Differential Pinion ThrustFRONT DIFFERENTIAL PINION THRUST [07.2007 - 03.2009] ADE150 |
41351-20050 |
US $1.60 |
||
|
41361F
|
41361F
41361-20240 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.25 |
41361-20240 |
US $0.44 |
||
|
41361F
|
41361F
41361-20310 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.30 |
41361-20310 |
US $0.44 |
||
|
41361F
|
41361F
41361-20320 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.35 |
41361-20320 |
US $0.44 |
||
|
41361F
|
41361F
41361-20330 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.40 |
41361-20330 |
US $0.44 |
||
|
41361F
|
41361F
41361-20340 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.45 |
41361-20340 |
US $0.44 |
||
|
41361F
|
41361F
41361-20350 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.50 |
41361-20350 |
US $0.44 |
||
|
41361F
|
41361F
41361-20360 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.55 |
41361-20360 |
US $0.44 |
||
|
41361F
|
41361F
41361-20370 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.60 |
41361-20370 |
US $0.58 |
||
|
41361F
|
41361F
41361-20380 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.65 |
41361-20380 |
US $0.58 |
||
|
41361F
|
41361F
41361-20390 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.70 |
41361-20390 |
US $0.58 |
||
|
41361F
|
41361F
41361-20400 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.75 |
41361-20400 |
US $0.58 |
||
|
41361F
|
41361F
41361-20410 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.80 |
41361-20410 |
US $0.58 |
||
|
41361F
|
41361F
41361-20420 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.85 |
41361-20420 |
US $0.58 |
||
|
41361F
|
41361F
41361-20430 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.90 |
41361-20430 |
US $3.79 |
||
|
41361F
|
41361F
41361-20440 Washer, Front Differential Side Gear Thrust, No.1FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1 [07.2007 - 03.2009] ADE150 T=1.95 |
41361-20440 |
US $3.93 |
||
