Interior Lamp ([04.1997 - ] (9704- )WG) Diagram Toyota COROLLA
- Year
- 1997 - 1998
- Sales region
- General
- Frame
- AE111
- grade
- XLI
- body
- WG
- ENGINE
- 4AFE
- TRANSMISSION
- MTM
- DESTINATION
- GEN
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 04.1997
- To
- 08.1998
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla SED/WG
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81205B
|
81205B
90981-11018 Bulb, Position Indicator Lamp[04.1997 - 11.2004] AE110..TH;AE111..MA;AE111..WG..5F;AE111..LHD..WG..4FC;AE112..XLI..(BZ,GCC,GEN,IDN) ;AE111,EE111..SED..(GL,GLI,STD,XL,XLI);AE110,112,CE110,EE110..GL,GLI,SEG,STD,XL 12V 1.2W W/O SOCKET |
90981-11018 |
from US $2.24 |
||
|
81240
|
81240
81240-12060-B6 Lamp Assy, Room, No.1[04.1997 - 10.1999] EE110..LHD..3FC;AE111..LHD..SED..GEN;CE110,EE110..5F..XL..GEN;AE111..RHD..SED..(XL ,XLI)..GEN MD.CHARCOAL,TRIM10,14; EE110..GCC;AE111..RHD..WG;AE111..GCC,TUR,VEN;EE110..(GL,STD)..GEN;AE112,EE111..ARL ,GCC,GEN,VEN;AE110,111..RHD..(GL,GL |
81240-12060-B6 |
US $42.52 |
||
| replacement | |||||
|
81240
|
81240
81240-12060-P0 Lamp Assy, Room, No.1[04.1997 - 10.1999] EE110..LHD..3FC;AE111..LHD..SED..GEN;CE110,EE110..5F..XL..GEN;AE111..RHD..SED..(XL ,XLI)..GEN MD.CHARCOAL,TRIM10,14; EE110..GCC;AE111..RHD..WG;AE111..GCC,TUR,VEN;EE110..(GL,STD)..GEN;AE112,EE111..ARL ,GCC,GEN,VEN;AE110,111..RHD..(GL,GL |
81240-12060-P0 |
from US $28.04 |
||
|
81240B
|
81240B
90981-14011 Bulb, Room Lamp, No.1[04.1997 - 12.1998] AE110..TH;AE111..MA;AE110..GLI;AE112,CE110,EE11#;AE111..GL,GLI,XL,XLI 12V 8W |
90981-14011 |
from US $1.91 |
||
|
81241
|
81241
81241-12020 Lens, Room Lamp, No.1[04.1997 - 12.1998] AE110..TH;AE111..MA;AE110..GLI;AE112,CE110,EE11#;AE111..GL,GLI,XL,XLI |
81241-12020 |
from US $4.97 |
||
|
81260A
|
81260A
81260-13010-B2 Lamp Assy, Map[04.1997 - 10.1999] AE111,112,EE110..WG W(MOON ROOF),MD.CHARCOAL,TRIM1# |
81260-13010-B2 |
US $214.03 |
||
|
81260A
|
81260A
81260-13020-B1 Lamp Assy, Map[08.1997 - 10.1999] AE111,112,EE110..WG MD. CHARCOAL,TRIM1# |
81260-13020-B1 |
US $215.49 |
||
| replacement | |||||
|
81260A
|
81260A
81260-13020-B0 Lamp Assy, Map[08.1997 - 10.1999] AE111,112,EE110..WG MD. CHARCOAL,TRIM1# |
81260-13020-B0 |
US $215.49 |
||
|
81260A
|
81260A
81260-16061-B1 Lamp Assy, Map[04.1997 - 08.1997] AE111..RHD..WG;AE112,EE110..WG MD.CHARCOAL,TRIM1#; AE111,112,EE110..WG MD.CHARCOAL,TRIM1# |
81260-16061-B1 |
US $215.49 |
||
| replacement | |||||
|
81260A
|
81260A
81260-16061-B3 Lamp Assy, Map[04.1997 - 08.1997] AE111..RHD..WG;AE112,EE110..WG MD.CHARCOAL,TRIM1#; AE111,112,EE110..WG MD.CHARCOAL,TRIM1# |
81260-16061-B3 |
US $156.96 |
||
|
81260C
|
81260C
90981-12005 Bulb, Room Lamp, No.1[04.1997 - 10.1999] AE111..RHD..WG;AE112,EE110..WG 12V 8W; AE111,112,EE110..WG 12V 8W |
90981-12005 |
from US $2.24 |
||
|
81260C
|
81260C
90981-12014 Bulb, Room Lamp, No.1[04.1997 - 10.1999] AE110,CE110,EE110..(GL,GLI,XL)..(GCC,GEN);AE111,112,EE111..(GL,GLI,XL,XLI)..(ARL,G CC,GEN) 12V 10W,W(MOON ROOF) |
90981-12014 |
from US $2.72 |
||
|
81261
|
81261
81261-13010-B1 Lens And Cover, Map Lamp[04.1997 - 10.1999] AE111,112,EE110..WG W(MOON ROOF),MD. CHARCOAL,TRIM1# |
81261-13010-B1 |
US $33.49 |
||
|
81261
|
81261
81261-16060 Lens And Cover, Map Lamp[04.1997 - 10.1999] AE111..RHD..WG;AE112,EE110..WG; AE111,112,EE110..WG |
81261-16060 |
US $18.79 |
||
|
9016445005
|
9016445005
90164-45005 SCREW |
90164-45005 |
US $1.92 |
||
|
9354054016
|
9354054016
93540-54016 SCREW |
93540-54016 |
from US $0.78 |
||
