Throttle Link & Valve Lever (Atm) ([02.1987 - ] (8702- )ATM..D) Diagram Toyota COROLLA
- Year
- 1987 - 1988
- Sales region
- U.S.A.
- Frame
- AE82
- grade
- D
- ENGINE
- 4ALC
- TRANSMISSION
- ATM
- Model
- COROLLA FX
- From
- 02.1987
- To
- 08.1988
- Vehicle Model
- Corolla FX
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35505
|
35505
35505-20010 Lever Sub-Assy, Manual Valve[01.1988 - 08.1988] AE82..ATM..D |
35505-20010 |
US $25.63 |
||
| replacement | |||||
|
35505
|
35505
35505-32040 Lever Sub-Assy, Manual Valve[01.1988 - 08.1988] AE82..ATM..D |
35505-32040 |
US $25.19 |
||
|
35505
|
35505
35505-32011 Lever Sub-Assy, Manual Valve[02.1987 - 01.1988] AE82..ATM..D |
35505-32011 |
US $25.33 |
||
| replacement | |||||
|
35505
|
35505
35505-32040 Lever Sub-Assy, Manual Valve[02.1987 - 01.1988] AE82..ATM..D |
35505-32040 |
US $25.19 |
||
|
35506
|
35506
35561-32010 Shaft Sub-Assy, Manual Valve Lever[02.1987 - 08.1988] AE82..ATM..D |
35561-32010 |
US $28.54 |
||
|
35506C
|
35506C
90254-04011 Pin, Slotted Spring (For Transfer Manual Valve Lever)[09.1986 - 08.1988] AE82..ATM |
90254-04011 |
US $1.40 |
||
|
35506F
|
35506F
90311-12002 Oil Seal, Type T[09.1986 - 08.1988] AE82..ATM |
90311-12002 |
from US $4.29 |
||
|
35506H
|
35506H
90560-20006 Spacer (For Manual Valve Lever)[09.1986 - 08.1988] AE82..ATM |
90560-20006 |
from US $2.77 |
||
|
35506J
|
35506J
90524-09001 Spring, Retainer (For Manual Valve Lever Shaft)[02.1987 - 08.1988] AE82..ATM..D |
90524-09001 |
US $1.89 |
||
|
35556
|
35556
35556-32010 Shaft, Parking Lock Pawl[02.1987 - 08.1988] AE82..ATM..D |
35556-32010 |
US $8.15 |
||
|
35557
|
35557
35557-32020 Pawl, Parking Lock[02.1987 - 08.1988] AE82..ATM..D |
35557-32020 |
US $37.71 |
||
|
35557A
|
35557A
90508-26047 Spring, Torsion (For Parking Lock Pawl)[02.1987 - 08.1988] AE82..ATM..D |
90508-26047 |
US $3.20 |
||
|
35585
|
35585
35501-32010 Rod Sub-Assy, Parking Lock[02.1987 - 08.1988] AE82..ATM..D |
35501-32010 |
US $27.23 |
||
|
35595
|
35595
35595-32010 Bracket, Parking Lock Pawl[02.1987 - 08.1988] AE82..ATM..D |
35595-32010 |
US $9.90 |
||
|
9161160614
|
9161160614
91611-60614
Screw Or Bolt(For Valve Rocker Shaft Lock)
|
91611-60614 |
— | ||
| replacement | |||||
|
9161160614
|
9161160614
91611-B0614 Bolt (For Rear Differential Breather Plug Oil Deflector) |
91611-B0614 |
US $1.76 |
||
|
9411050800
|
9411050800
94110-50800 Nut(For Repair Actuator Set) |
94110-50800 |
US $1.28 |
||
|
9451200800
|
9451200800
94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-00800 |
from US $0.76 |
||
