Front Steering Gear & Link ([05.1983 - ] (8305- )AE82..5D..RHD..GL) Diagram Toyota COROLLA
- Year
- 1983 - 1987
- Sales region
- Europe
- Frame
- AE82
- grade
- GL
- body
- LB
- ENGINE
- 4AL
- TRANSMISSION
- MTM
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 05.1983
- To
- 04.1987
- Gear Shift Type
- 5F
- No.of Doors
- 5D
- Vehicle Model
- Corolla
- Driver's Position
- RHD
- Destination
- GEN
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44201
|
44201
44201-12080 Valve Sub-Assy, Power Steering ControlPOWER STEERING CONTROL [05.1983 - 04.1988] AE82..5D..RHD..GL |
44201-12080 |
US $294.11 |
||
|
44201C
|
44201C
90562-33001 Ring(For Power Steering Control Valve)[05.1983 - 09.1987] AE82..5D..RHD..GL |
90562-33001 |
US $2.18 |
||
| replacement | |||||
|
44201C
|
44201C
90560-33003 Spacer(For Power Steering Control Valve)[05.1983 - 09.1987] AE82..5D..RHD..GL |
90560-33003 |
US $1.92 |
||
|
44204
|
44204
44204-12070 Rack Sub-Assy, Power SteeringPOWER STEERING [05.1983 - 04.1988] AE82..5D..RHD..GL |
44204-12070 |
US $216.94 |
||
|
44204A
|
44204A
90562-34002 Ring(For Rack Steering Piston)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90562-34002 |
US $13.83 |
||
|
44205C
|
44205C
44205-12040 Bush Sub-Assy, Power Steering RackPOWER STEERING RACK [05.1983 - 07.1984] AE82..LHD..GEN; AE82..5D..RHD |
44205-12040 |
US $64.65 |
||
|
44205C
|
44205C
44205-12041 Bush Sub-Assy, Power Steering RackPOWER STEERING RACK [07.1984 - 04.1988] AE82..5D..RHD..GL |
44205-12041 |
US $71.64 |
||
|
44205D
|
44205D
90301-33004 Ring, O(For Cylinder End Stopper)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90301-33004 |
US $9.43 |
||
|
44205E
|
44205E
90311-24005 Seal, Oil(For Cylinder End Stopper)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90311-24005 |
US $2.91 |
||
|
44206
|
44206
44206-12060 Tube Sub-Assy, Power Steering CylinderPOWER STEERING CYLINDER [05.1983 - 04.1988] AE82..5D..RHD..GL |
44206-12060 |
US $116.48 |
||
|
44206A
|
44206A
90311-24002 Seal, Oil(For Power Steering Cylinder)[05.1983 - 11.1985] AE82..5D..RHD..GL |
90311-24002 |
US $10.63 |
||
| replacement | |||||
|
44206A
|
44206A
90311-24004 Seal, Oil(For Power Steering Cylinder)[05.1983 - 11.1985] AE82..5D..RHD..GL |
90311-24004 |
US $2.91 |
||
|
44206A
|
44206A
90311-24004 Seal, Oil(For Power Steering Cylinder)[11.1985 - 04.1988] AE82..5D..RHD..GL |
90311-24004 |
US $2.91 |
||
|
44206B
|
44206B
90214-47001 Washer, Claw(For Power Steering Cylinder)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90214-47001 |
US $4.08 |
||
|
44206C
|
44206C
90206-39001
Washer, Wave(For Power Steering Cylinder)
[05.1983 - 07.1984] AE82..LHD..GEN; AE82..5D..RHD |
90206-39001 |
— | ||
|
44206D
|
44206D
90179-45001 Nut(For Power Steering Cylinder Set)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90179-45001 |
US $25.77 |
||
|
44210
|
44210
44210-12080 Valve Assy, Power Steering ControlPOWER STEERING CONTROL [05.1983 - 04.1988] AE82..5D..RHD..GL |
44210-12080 |
US $563.47 |
||
| replacement | |||||
|
44210
|
44210
44210-12071 Valve Assy, Power Steering Control[05.1983 - 04.1988] AE82..5D..RHD..GL |
44210-12071 |
US $621.71 |
||
|
44210B
|
44210B
90410-07003 Seat, Union(For Power Steering Control Valve)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90410-07003 |
US $7.28 |
||
|
44210C
|
44210C
90301-42001 Ring, O(For Power Steering Control Valve)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90301-42001 |
US $8.15 |
||
|
44210D
|
44210D
96151-03200 Ring, Snap (For Shift Lever)[05.1983 - 04.1988] AE82..5D..RHD..GL |
96151-03200 |
US $2.24 |
||
|
44210E
|
44210E
90311-19005
Seal, Oil(For Power Steering Control Valve)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
90311-19005 |
— | ||
| replacement | |||||
|
44210E
|
44210E
90311-19010 Seal, Oil(For Power Steering Control Valve)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90311-19010 |
from US $3.84 |
||
|
44210F
|
44210F
90364-19005
Bearing(For Power Steering Control Valve Upper)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
90364-19005 |
— | ||
|
44211
|
44211
44211-12080 Housing, Control ValveCONTROL VALVE [05.1983 - 09.1987] AE82..5D..RHD..GL |
44211-12080 |
US $133.95 |
||
|
44222A
|
44222A
45222-16020
Cover, Dust(For Power Steering Gear)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
45222-16020 |
— | ||
|
44252B
|
44252B
90363-12006
Bearing(For Power Steering Control Valve Lower)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
90363-12006 |
— | ||
|
44253
|
44253
44203-12090 Housing, Power Steering RackPOWER STEERING RACK [05.1983 - 04.1988] AE82..5D..RHD..GL |
44203-12090 |
US $624.62 |
||
|
44253A
|
44253A
90310-23004 Seal, Oil(For Power Steering Rack Housing)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90310-23004 |
US $4.95 |
||
|
44253B
|
44253B
90301-33004 Ring, O(For Cylinder End Stopper)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90301-33004 |
US $9.43 |
||
|
44253C
|
44253C
90256-04002 Pin(For Power Steering Rack Housing)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90256-04002 |
US $2.62 |
||
|
44253D
|
44253D
44283-16010 Cap, Power Steering Rack Housing[05.1983 - 04.1988] AE82..5D..RHD..GL |
44283-16010 |
US $13.69 |
||
|
44275
|
44275
44275-16010 Nut, Cylinder End Stopper[05.1983 - 04.1988] AE82..5D..RHD..GL |
44275-16010 |
US $29.85 |
||
|
44418A
|
44418A
44418-12080 Tube, Steering Right Turn PressureSTEERING RIGHT TURN PRESSURE [05.1983 - 04.1988] AE82..5D..RHD..GL |
44418-12080 |
US $26.94 |
||
|
44418C
|
44418C
90301-05005 Ring, O(For Steering Turn Pressure Tube)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90301-05005 |
US $2.04 |
||
|
44419A
|
44419A
44419-12080 Tube, Steering Left Turn PressureSTEERING LEFT TURN PRESSURE [05.1983 - 07.1988] AE82..5D..RHD..GL |
44419-12080 |
US $29.85 |
||
|
44503E
|
44503E
45503-19055 End Sub-Assy, Steering Rack(For Power Steering)[05.1983 - 09.1984] CE80;AE82..GL..GEN |
45503-19055 |
US $110.66 |
||
|
44503E
|
44503E
45503-19056 End Sub-Assy, Steering Rack(For Power Steering)[09.1984 - 05.1985] CE80;AE82..GL..GEN |
45503-19056 |
US $117.94 |
||
|
44503F
|
44503F
90214-14002 Washer, Claw(For Power Steering Rack End)[05.1983 - 05.1985] CE80;AE82..GL..GEN |
90214-14002 |
from US $1.33 |
||
|
44523G
|
44523G
45523-16040
Guide, Rack(For Power Steering)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
45523-16040 |
— | ||
|
44523H
|
44523H
90501-20045 Spring(For Power Steering Rack Guide)[05.1983 - 01.1985] AE82..LHD..GL..GEN; AE82..5D..RHD..GL |
90501-20045 |
US $3.35 |
||
|
44523H
|
44523H
90501-26042 Spring(For Power Steering Rack Guide)[01.1985 - 04.1988] AE82..5D..RHD..GL |
90501-26042 |
US $2.04 |
||
|
44524A
|
44524A
45524-16030
Cap, Rack Guide Spring(For Power Steering)
[05.1983 - 04.1988] AE82..5D..RHD..GL |
45524-16030 |
— | ||
| replacement | |||||
|
44524A
|
44524A
45524-33010
Cap, Steering Rack Guide Spring
[05.1983 - 04.1988] AE82..5D..RHD..GL |
45524-33010 |
— | ||
|
44524B
|
44524B
90179-36002 Nut(For Power Steering Pinion Cap)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90179-36002 |
US $4.89 |
||
|
44535B
|
44535B
45535-16020 Boot, Steering Rack No.1(For Power Steering)[05.1983 - 04.1988] AE82..5D..RHD..GL |
45535-16020 |
US $31.16 |
||
|
44535C
|
44535C
90949-01027 Clamp(For Power Steering Rack Boot)[05.1983 - 04.1988] AE82..5D..RHD..GL |
90949-01027 |
US $11.36 |
||
|
44535D
|
44535D
90467-18003 Clip Or Clamp(For Ventilation Hose)[05.1983 - 05.1985] CE80;AE82..GL..GEN |
90467-18003 |
from US $1.92 |
||
|
44536B
|
44536B
45535-16020 Boot, Steering Rack No.1(For Power Steering)[05.1983 - 04.1988] AE82..5D..RHD..GL |
45535-16020 |
US $31.16 |
||
|
9017910048
|
9017910048
90179-10048 Nut, Lock(For Power Steering Control Valve) |
90179-10048 |
US $4.19 |
||
|
9161160825
|
9161160825
91611-60825
Bolt(For Head To Camshaft Bearing Cap)
|
91611-60825 |
— | ||
| replacement | |||||
|
9161160825
|
9161160825
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.13 |
||
