Heating & Air Conditioning - Cooler Piping ([08.1987 - ] (8708- )) Diagram Toyota COROLLA
- Year
- 1988 - 1989
- Sales region
- U.S.A.
- Frame
- AE92
- grade
- DX
- body
- SED
- ENGINE
- 4AF
- TRANSMISSION
- ATM
- PRODUCT
- NAP
- DESTINATION
- USA
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 09.1988
- To
- 09.1989
- Gear Shift Type
- 3FC
- Vehicle Model
- Corolla
- Fuel Induction
- CBR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88453A
|
88453A
88453-01020
Fan, Cooling
[09.1988 - 02.1992] AE92..USA |
88453-01020 |
— | ||
|
88454A
|
88454A
88454-01020
Shroud, Fan
[09.1988 - 02.1992] AE92..USA |
88454-01020 |
— | ||
|
88550
|
88550
88550-01020
Motor Assy, Blower (For Condenser)
[09.1988 - 02.1992] AE92..USA |
88550-01020 |
— | ||
|
88590
|
88590
88590-01030
Blower Assy, W/shroud
[09.1988 - 02.1992] AE92..USA |
88590-01030 |
— | ||
|
88596C
|
88596C
88723-01010
Plate, Caution, No.2
[09.1988 - 07.1989] AE92..USA |
88723-01010 |
— | ||
| replacement | |||||
|
88596C
|
88596C
88723-01030
Plate, Caution, No.2
[09.1988 - 07.1989] AE92..USA |
88723-01030 |
— | ||
|
88596C
|
88596C
88723-01020
Plate, Caution, No.2
[07.1989 - 03.1990] AE92..USA |
88723-01020 |
— | ||
| replacement | |||||
|
88596C
|
88596C
88723-01030
Plate, Caution, No.2
[07.1989 - 03.1990] AE92..USA |
88723-01030 |
— | ||
|
8846714070
|
8846714070
88467-14070
Insulator (For Power Take-Off Cable Bracket)
|
88467-14070 |
— | ||
|
8846720040
|
8846720040
88467-20040
Insulator, Cooler Condenser Mounting
|
88467-20040 |
— | ||
|
8846730270
|
8846730270
88467-30270 Cushion, Cooler Condenser, No.1 |
88467-30270 |
from US $1.75 |
||
|
8868801070
|
8868801070
88688-01070
Bracket, Cooler Diaphragm
|
88688-01070 |
— | ||
| replacement | |||||
|
8868801070
|
8868801070
88688-12580
Bracket, Cooler Diaphragm
|
88688-12580 |
— | ||
|
8868812580
|
8868812580
88688-12580
Bracket, Cooler Diaphragm
|
88688-12580 |
— | ||
|
8868812780
|
8868812780
88688-12780
Bracket, Cooler Diaphragm
|
88688-12780 |
— | ||
|
8889201020
|
8889201020
88892-01020
Bracket, Cooler Evaporator Mounting
|
88892-01020 |
— | ||
|
8889212180
|
8889212180
88892-12180
Net, Fan Shroud
|
88892-12180 |
— | ||
|
9009904376
|
9009904376
90099-04376
New Genuine Part
|
90099-04376 |
— | ||
|
9011906100
|
9011906100
90119-06100 BOLT |
90119-06100 |
from US $1.11 |
||
|
9011906336
|
9011906336
90119-06336 SCREW |
90119-06336 |
US $1.43 |
||
|
9015960128
|
9015960128
90159-60128 New Genuine Part |
90159-60128 |
US $2.15 |
||
|
9017906032
|
9017906032
90179-06032
Direct
|
90179-06032 |
— | ||
| replacement | |||||
|
9017906032
|
9017906032
90179-06274 Nut |
90179-06274 |
from US $0.70 |
||
