Roof Panel & Back Window Glass ([02.1988 - ] (8802- )AE95..WG) Diagram Toyota COROLLA
- Year
- 1988 - 1990
- Sales region
- Europe
- Frame
- AE95
- grade
- DX
- body
- WG
- ENGINE
- 4AFE
- TRANSMISSION
- ATM
- PRODUCT
- JPP
- DESTINATION
- USA
- Model
- COROLLA (JPP)
- From
- 02.1988
- To
- 09.1990
- Gear Shift Type
- 4FC
- Vehicle Model
- Corolla
- Fuel Induction
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
63201H
|
63201H
63201-12150
Panel Sub-Assy, Slide Roof
[02.1988 - 09.1990] AE95..WG |
63201-12150 |
— | ||
|
63203F
|
63203F
63203-12140 Housing Sub-Assy, Sliding Roof[02.1988 - 09.1990] AE95..WG |
63203-12140 |
US $567.84 |
||
|
63207
|
63207
63207-12080 Rail Sub-Assy, Sliding Roof Guide, RhSLIDING ROOF GUIDE, RH [02.1988 - 05.1990] AE95..WG |
63207-12080 |
US $133.95 |
||
|
63207
|
63207
63207-12081 Rail Sub-Assy, Sliding Roof Guide, Rh[05.1990 - 09.1990] AE95..WG |
63207-12081 |
US $132.50 |
||
|
63208
|
63208
63208-12080 Rail Sub-Assy, Sliding Roof Guide, LhSLIDING ROOF GUIDE, LH [02.1988 - 05.1990] AE95..WG |
63208-12080 |
US $133.95 |
||
|
63208
|
63208
63208-12081 Rail Sub-Assy, Sliding Roof Guide, Lh[05.1990 - 09.1990] AE95..WG |
63208-12081 |
US $132.50 |
||
|
63209
|
63209
63209-12060 Panel Sub-Assy, Roof Wind Deflector[02.1988 - 09.1990] AE95..WG |
63209-12060 |
US $329.06 |
||
|
63218A
|
63218A
63249-12130 Hose(For Sliding Roof Or Removable Roof Drain)[02.1988 - 09.1990] AE95..WG FR |
63249-12130 |
US $21.69 |
||
|
63218A
|
63218A
63249-12140 Hose(For Sliding Roof Or Removable Roof Drain)[02.1988 - 09.1990] AE95..WG RR |
63249-12140 |
US $17.33 |
||
|
63221
|
63221
63221-12060 Casing, Sliding Roof Cable Guide[02.1988 - 09.1990] AE95..WG |
63221-12060 |
US $241.70 |
||
|
63223
|
63223
63223-12070 Cable, Sliding Roof Drive, Rh[02.1988 - 05.1990] AE95..WG |
63223-12070 |
US $149.97 |
||
|
63223
|
63223
63223-12071
Cable, Sliding Roof Drive, Rh
[05.1990 - 09.1990] AE95..WG |
63223-12071 |
— | ||
| replacement | |||||
|
63223
|
63223
63223-12072
Cable, Sliding Roof Drive, Rh
[05.1990 - 09.1990] AE95..WG |
63223-12072 |
— | ||
|
63224
|
63224
63224-12060 Cable, Sliding Roof Drive, Lh[02.1988 - 05.1990] AE95..WG |
63224-12060 |
US $149.97 |
||
|
63224
|
63224
63224-12061
Cable, Sliding Roof Drive, Lh
[05.1990 - 09.1990] AE95..WG |
63224-12061 |
— | ||
| replacement | |||||
|
63224
|
63224
63224-12062
Cable, Sliding Roof Drive, Lh
[05.1990 - 09.1990] AE95..WG |
63224-12062 |
— | ||
|
63251J
|
63251J
63251-12080
Weatherstrip, Sliding Roof
[02.1988 - 09.1990] AE95..WG |
63251-12080 |
— | ||
|
63255
|
63255
63255-12070 Cover, Sliding Roof Guide Rail, Rh[02.1988 - 09.1990] AE95..WG |
63255-12070 |
US $23.44 |
||
|
63260A
|
63260A
63260-12040
Gear Sub-Assy, Sliding Roof Drive
[08.1987 - 08.1989] AE95;AE92..SED |
63260-12040 |
— | ||
| replacement | |||||
|
63260A
|
63260A
63260-12041
Gear Sub-Assy, Sliding Roof Drive
[08.1987 - 08.1989] AE95;AE92..SED |
63260-12041 |
— | ||
|
63261C
|
63261C
63261-12040 Shoe, Sliding Roof, Front RhSLIDING ROOF, FRONT RH [02.1988 - 05.1990] AE95..WG |
63261-12040 |
US $9.46 |
||
|
63261C
|
63261C
63261-12041 Shoe, Sliding Roof, Front RhSLIDING ROOF, FRONT RH [05.1990 - 09.1990] AE95..WG |
63261-12041 |
US $18.05 |
||
|
63262
|
63262
63262-12040 Shoe, Sliding Roof, Front LhSLIDING ROOF, FRONT LH [02.1988 - 05.1990] AE95..WG |
63262-12040 |
US $9.46 |
||
|
63262
|
63262
63262-12041 Shoe, Sliding Roof, Front LhSLIDING ROOF, FRONT LH [05.1990 - 09.1990] AE95..WG |
63262-12041 |
US $18.05 |
||
|
63265B
|
63265B
63265-20010 Gear, Sliding Roof Drive[11.1989 - 06.1992] AE95;AE92..SED..(DX,LE) |
63265-20010 |
US $22.71 |
||
|
63267
|
63267
63267-12020 Protector, Sliding Roof Weatherstrip[02.1988 - 09.1990] AE95..WG |
63267-12020 |
US $5.24 |
||
|
63269
|
63269
63269-20010 Retainer, Sliding Roof Weatherstrip[08.1987 - 06.1992] AE95;AE92..SED..(DX,LE) |
63269-20010 |
US $9.17 |
||
|
63277C
|
63277C
63277-24010 Shim, Sliding Roof Rail[08.1987 - 08.1989] AE95;AE92..SED T=1.0,RR |
63277-24010 |
US $10.19 |
||
|
63277C
|
63277C
63277-30020 Shim, Sliding Roof Rail[02.1988 - 08.1989] AE95..WG T=1.0,FR |
63277-30020 |
US $2.91 |
||
|
63277C
|
63277C
63277-32010 Shim, Sliding Roof Rail[02.1988 - 08.1989] AE95..WG T=2.0,FR |
63277-32010 |
US $3.93 |
||
|
63277C
|
63277C
63277-32020 Shim, Sliding Roof Rail[02.1988 - 08.1989] AE95..WG T=2.0,RR |
63277-32020 |
US $15 |
||
|
63279C
|
63279C
63279-20010 Retainer, Sliding Roof Weatherstrip[02.1988 - 09.1990] AE95..WG |
63279-20010 |
US $9.17 |
||
|
63279D
|
63279D
63279-32010 Bracket, Housing To Rail, No.3[05.1990 - 06.1992] AE95;AE92..SED..(DX,LE) |
63279-32010 |
US $7.43 |
||
|
63699A
|
63699A
63699-12040
Seal, Sliding Roof Guide Rail
[02.1988 - 09.1990] AE95..WG |
63699-12040 |
— | ||
|
9015360004
|
9015360004
90153-60004
New Genuine Part
|
90153-60004 |
— | ||
|
9015940193
|
9015940193
90159-40193 New Genuine Part |
90159-40193 |
US $1.60 |
||
|
9015960219
|
9015960219
90159-60219
New Genuine Part
|
90159-60219 |
— | ||
|
9015960348
|
9015960348
90159-60348
New Genuine Part
|
90159-60348 |
— | ||
|
9016250007
|
9016250007
90162-50007
New Genuine Part
|
90162-50007 |
— | ||
|
9016840046
|
9016840046
90168-40046 New Genuine Part |
90168-40046 |
US $1.75 |
||
|
9016840090
|
9016840090
90168-40090
New Genuine Part
|
90168-40090 |
— | ||
|
9017906167
|
9017906167
90179-06167 Direct |
90179-06167 |
US $1.60 |
||
| replacement | |||||
|
9017906167
|
9017906167
90179-06274 Nut |
90179-06274 |
from US $0.74 |
||
|
9018905043
|
9018905043
90189-05043 Clip, Rear Door Service Hole |
90189-05043 |
US $1.60 |
||
|
9033315002
|
9033315002
90333-15002 PLUG |
90333-15002 |
from US $1.44 |
||
|
9033320001
|
9033320001
90333-20001 PLUG |
90333-20001 |
from US $1.12 |
||
|
9033330002
|
9033330002
90333-30002 Cover, Front Floor Hole |
90333-30002 |
from US $1.12 |
||
|
9046713103
|
9046713103
90467-13103 Clip Or Clamp(For Ventilation Hose) |
90467-13103 |
from US $1.76 |
||
|
9046816009
|
9046816009
90468-16009 Clip(For Ventilation Hose No.2) |
90468-16009 |
US $1.31 |
||
|
9054105018
|
9054105018
90541-05018 Cushion(For Fuel Inlet Box Cover) |
90541-05018 |
from US $1.89 |
||
|
9616000400
|
9616000400
96160-00400 Ring, E(For Release Arm) |
96160-00400 |
US $1.05 |
||
