Steering Column & Shaft ([08.1984 - ] (8205-8301)AL21..GL,SE ; (8301-8408)GL,SE ; (840 8- )DLX,GL,SR) Diagram Toyota COROLLA
- Year
- 1984 - 1986
- Sales region
- Japan
- Frame
- AL21
- grade
- SR
- body
- SED
- ENGINE
- 3ASU
- TRANSMISSION
- MTM
- Model
- COROLLA 2
- From
- 08.1984
- To
- 04.1986
- Gear Shift Type
- 5F
- No.of Doors
- 5DS
- Vehicle Model
- Corolla 2
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44201
|
44201
44201-16010 Valve Sub-Assy, Power Steering Control[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44201-16010 |
US $298.48 |
||
|
44201C
|
44201C
90562-33001 Ring(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90562-33001 |
US $2.18 |
||
| replacement | |||||
|
44201C
|
44201C
90560-33003 Spacer(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90560-33003 |
from US $1.40 |
||
|
44204
|
44204
44204-16010 Rack Sub-Assy, Power Steering[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44204-16010 |
US $221.31 |
||
|
44204A
|
44204A
90562-34002 Ring(For Rack Steering Piston)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90562-34002 |
US $13.83 |
||
|
44205
|
44205
44205-16011 Stopper Sub-Assy, Cylinder End[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44205-16011 |
US $34.65 |
||
| replacement | |||||
|
44205
|
44205
44205-10020
Bush Sub-Assy, Power Steering Rack
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44205-10020 |
— | ||
|
44205A
|
44205A
90301-33004 Ring, O(For Cylinder End Stopper)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90301-33004 |
US $9.43 |
||
|
44205B
|
44205B
90311-24005 Seal, Oil(For Cylinder End Stopper)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90311-24005 |
US $2.91 |
||
|
44206
|
44206
44206-16010 Tube Sub-Assy, Power Steering Cylinder[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44206-16010 |
US $154.34 |
||
|
44206A
|
44206A
90311-24002 Seal, Oil(For Power Steering Cylinder)[08.1984 - 11.1985] AL2#..DLX,GL,SR |
90311-24002 |
US $10.63 |
||
| replacement | |||||
|
44206A
|
44206A
90311-24004 Seal, Oil(For Power Steering Cylinder)[08.1984 - 11.1985] AL2#..DLX,GL,SR |
90311-24004 |
US $2.91 |
||
|
44206A
|
44206A
90311-24004 Seal, Oil(For Power Steering Cylinder)[11.1985 - 04.1986] AL2#..DLX,GL,SR |
90311-24004 |
US $2.91 |
||
|
44206B
|
44206B
90214-47001 Washer, Claw(For Power Steering Cylinder)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90214-47001 |
US $4.08 |
||
|
44206D
|
44206D
90179-45001 Nut(For Power Steering Cylinder Set)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90179-45001 |
US $25.77 |
||
|
44210
|
44210
44210-16011 Valve Assy, Power Steering Control[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44210-16011 |
US $564.93 |
||
|
44210B
|
44210B
90410-07003 Seat, Union(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90410-07003 |
US $7.28 |
||
|
44210C
|
44210C
90301-42001 Ring, O(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90301-42001 |
US $8.15 |
||
|
44210D
|
44210D
96151-03200 Ring, Snap (For Shift Lever)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
96151-03200 |
US $2.24 |
||
|
44210E
|
44210E
90311-19005
Seal, Oil(For Power Steering Control Valve)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90311-19005 |
— | ||
| replacement | |||||
|
44210E
|
44210E
90311-19010 Seal, Oil(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90311-19010 |
from US $3.84 |
||
|
44210F
|
44210F
90364-19005
Bearing(For Power Steering Control Valve Upper)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90364-19005 |
— | ||
|
44211
|
44211
44211-16011 Housing, Control Valve[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44211-16011 |
US $142.69 |
||
| replacements | |||||
|
44211
|
44211
44211-16012 Housing, Control Valve[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44211-16012 |
US $141.23 |
||
|
44211
|
44211
90560-33003 Spacer(For Power Steering Control Valve)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90560-33003 |
from US $1.40 |
||
|
44222A
|
44222A
45222-16020
Cover, Dust(For Power Steering Gear)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45222-16020 |
— | ||
|
44252B
|
44252B
90363-12006
Bearing(For Power Steering Control Valve Lower)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90363-12006 |
— | ||
|
44253
|
44253
44203-16010 Housing, Power Steering Rack[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44203-16010 |
US $209.66 |
||
|
44253A
|
44253A
90310-23004 Seal, Oil(For Power Steering Rack Housing)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90310-23004 |
US $4.95 |
||
|
44253B
|
44253B
90301-33004 Ring, O(For Cylinder End Stopper)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90301-33004 |
US $9.43 |
||
|
44253C
|
44253C
90256-04002 Pin(For Power Steering Rack Housing)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90256-04002 |
US $2.62 |
||
|
44253D
|
44253D
44283-16010 Cap, Power Steering Rack Housing[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44283-16010 |
US $13.69 |
||
|
44256
|
44256
44275-16010 Nut, Cylinder End Stopper[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44275-16010 |
US $29.85 |
||
|
44418A
|
44418A
44418-16010 Tube, Steering Right Turn Pressure[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44418-16010 |
US $35.53 |
||
|
44418C
|
44418C
90301-05005 Ring, O(For Steering Turn Pressure Tube)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90301-05005 |
US $2.04 |
||
|
44419A
|
44419A
44419-16010 Tube, Steering Left Turn Pressure[08.1984 - 04.1986] AL2#..DLX,GL,SR |
44419-16010 |
US $27.23 |
||
|
44503E
|
44503E
45503-19025 End Sub-Assy, Steering Rack(For Power Steering)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45503-19025 |
US $78.44 |
||
|
44503F
|
44503F
90214-14002 Washer, Claw(For Power Steering Rack End)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90214-14002 |
from US $1.33 |
||
|
44523G
|
44523G
45523-16040
Guide, Rack(For Power Steering)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45523-16040 |
— | ||
|
44523H
|
44523H
90501-20045 Spring(For Power Steering Rack Guide)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90501-20045 |
US $3.35 |
||
|
44524A
|
44524A
45524-16030
Cap, Rack Guide Spring(For Power Steering)
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45524-16030 |
— | ||
| replacement | |||||
|
44524A
|
44524A
45524-33010
Cap, Steering Rack Guide Spring
[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45524-33010 |
— | ||
|
44524B
|
44524B
90179-36002 Nut(For Power Steering Pinion Cap)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90179-36002 |
US $4.89 |
||
|
44535B
|
44535B
45535-16020 Boot, Steering Rack No.1(For Power Steering)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45535-16020 |
US $31.16 |
||
|
44535C
|
44535C
90949-01027 Clamp(For Power Steering Rack Boot)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90949-01027 |
US $11.36 |
||
|
44535D
|
44535D
90467-18003 Clip Or Clamp(For Ventilation Hose)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
90467-18003 |
from US $1.92 |
||
|
44536B
|
44536B
45535-16020 Boot, Steering Rack No.1(For Power Steering)[08.1984 - 04.1986] AL2#..DLX,GL,SR |
45535-16020 |
US $31.16 |
||
|
9010508043
|
9010508043
90105-08043 Bolt(for Head To Camshaft Bearing Cap) |
90105-08043 |
US $1.89 |
||
| replacement | |||||
|
9010508043
|
9010508043
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.93 |
||
|
9010508044
|
9010508044
90105-08044
New Genuine Part
|
90105-08044 |
— | ||
|
9017910048
|
9017910048
90179-10048 Nut, Lock(For Power Steering Control Valve) |
90179-10048 |
US $4.19 |
||
|
9161160825
|
9161160825
91611-60825
Bolt(For Head To Camshaft Bearing Cap)
|
91611-60825 |
— | ||
| replacement | |||||
|
9161160825
|
9161160825
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.93 |
||
|
9161160855
|
9161160855
91611-60855 Bolt(For Rocker Support Set) |
91611-60855 |
US $1.60 |
||
