Cylinder Block ([08.2000 - ] (0008- )1CDFTV) Diagram Toyota COROLLA
- Year
- 2000 - 2001
- Sales region
- Europe
- Frame
- CDE110
- grade
- TERRA
- body
- HB
- ENGINE
- 1CDFTV
- TRANSMISSION
- MTM
- PRODUCT
- JPP
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 08.2000
- To
- 07.2001
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla HB/LB
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11401
|
11401
11401-29665 Block Sub-Assy, CylinderCYLINDER [08.2000 - 09.2001] 1CDFTV..CDE110 |
11401-29665 |
US $3,276 |
||
|
11401C
|
11401C
16353-27010 Flange(For Water By-Pass)[08.2000 - 09.2001] 1CDFTV..CDE110 |
16353-27010 |
US $23.59 |
||
| replacement | |||||
|
11401C
|
11401C
16353-27011 Flange(For Water By-Pass)[08.2000 - 09.2001] 1CDFTV..CDE110 |
16353-27011 |
US $23.15 |
||
|
11415
|
11415
90910-09075 Cock Sub-Assy, Water Drain(For Cylinder Block)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90910-09075 |
US $20.46 |
||
| replacement | |||||
|
11415
|
11415
90910-09129 Cock Sub-Assy, Water Drain(For Cylinder Block)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90910-09129 |
from US $5.92 |
||
|
11415A
|
11415A
90910-09087 Plug, Water Drain Cock(For Cylinder Block)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90910-09087 |
from US $3.68 |
||
|
11416
|
11416
90910-02135 Bolt(For Crankshaft Bearing Cap Set)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90910-02135 |
US $3.64 |
||
|
11421
|
11421
90116-06164 Bolt, Stud(For Oil Pan)STUD(FOR OIL PAN) [08.2000 - 09.2001] 1CDFTV..CDE110 |
90116-06164 |
US $1.60 |
||
|
11431A
|
11431A
96411-63500 Plug, Tight[08.2000 - 09.2001] 1CDFTV..CDE110 |
96411-63500 |
from US $3.20 |
||
|
11431B
|
11431B
96411-63000 Plug, Tight[08.2000 - 09.2001] 1CDFTV..CDE110 |
96411-63000 |
from US $3.36 |
||
|
11431C
|
11431C
96411-41800 Plug, Tight, No.1[08.2000 - 09.2001] 1CDFTV..CDE110 |
96411-41800 |
from US $1.72 |
||
|
11434C
|
11434C
90253-14004 Pin, Straight (For Cylinder Head Set)[08.2000 - 09.2001] 1CDFTV..CDE110 L=20,OD=14 |
90253-14004 |
from US $5.05 |
||
|
11434D
|
11434D
90250-06068 Pin, Straight[08.2000 - 09.2001] 1CDFTV..CDE110 L=11,OD=6 |
90250-06068 |
from US $1.05 |
||
|
11434G
|
11434G
90250-10113 Pin, Straight(For Timing Gear Cover Set)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90250-10113 |
from US $1.03 |
||
|
11434R
|
11434R
90250-06003 Pin, Straight[08.2000 - 09.2001] 1CDFTV..CDE110 |
90250-06003 |
US $1.44 |
||
|
11448
|
11448
11448-64010 Orifice, Cylinder Block Oil[08.2000 - 09.2001] 1CDFTV..CDE110 |
11448-64010 |
US $2.91 |
||
|
11452
|
11452
11452-27020 Guide, Oil Level GageOIL LEVEL GAGE [08.2000 - 09.2001] 1CDFTV..CDE110 |
11452-27020 |
US $31.16 |
||
|
12101
|
12101
12111-27010 Pan Sub-Assy, OilOIL [08.2000 - 09.2001] 1CDFTV..CDE110 |
12111-27010 |
US $768.77 |
||
|
12101A
|
12101A
90341-12026
Plug, Drain
[08.2000 - 09.2001] 1CDFTV..CDE110 |
90341-12026 |
— | ||
| replacement | |||||
|
12101A
|
12101A
90341-12012 Plug(For Oil Pan Drain)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90341-12012 |
from US $2.56 |
||
|
12101B
|
12101B
90430-12031 Gasket (For Oil Pan Drain Plug)[08.2000 - 09.2001] 1CDFTV..CDE110 |
90430-12031 |
from US $0.88 |
||
|
12102A
|
12102A
12102-27010 Pan Sub-Assy, Oil, No.2OIL, NO.2 [08.2000 - 09.2001] 1CDFTV..CDE110 |
12102-27010 |
US $243.15 |
||
|
12156
|
12156
12156-27010 Insulator, Oil PanOIL PAN [08.2000 - 09.2001] 1CDFTV..CDE110 |
12156-27010 |
US $27.66 |
||
|
15301
|
15301
15301-27020 Gage Sub-Assy, Oil LevelOIL LEVEL [08.2000 - 09.2001] 1CDFTV..CDE110 |
15301-27020 |
US $16.16 |
||
|
15605
|
15605
15703-27010 Valve Sub-Assy, Oil Check[08.2000 - 09.2001] 1CDFTV..CDE110 |
15703-27010 |
US $28.65 |
||
|
15708
|
15708
15790-27010 Nozzle Sub-Assy, Oil, No.1OIL, NO.1 [08.2000 - 09.2001] 1CDFTV..CDE110 |
15790-27010 |
US $27.37 |
||
| replacements | |||||
|
15708
|
15708
15790-27020
Nozzle Sub-Assy, Oil, No.1
[08.2000 - 09.2001] 1CDFTV..CDE110 |
15790-27020 |
— | ||
|
15708
|
15708
90110-06034
New Genuine Part
[08.2000 - 09.2001] 1CDFTV..CDE110 |
90110-06034 |
— | ||
|
9017906036
|
9017906036
90179-06036
Nut, Cap(For Cylinder Head Cover)
|
90179-06036 |
— | ||
| replacement | |||||
|
9017906036
|
9017906036
90179-06299 Nut, Wire Adjusting, No.1 |
90179-06299 |
from US $0.72 |
||
|
9025311021
|
9025311021
90253-11021 Pin, Ring |
90253-11021 |
from US $1.50 |
||
|
9043014235
|
9043014235
90430-14235 Gasket, W/head Taper Screw Plug |
90430-14235 |
US $3.68 |
||
|
9151160612
|
9151160612
91511-60612 BOLT |
91511-60612 |
US $1.76 |
||
|
9151160825
|
9151160825
91511-60825
Bolt (For Transfer Stiffener Plate)
|
91511-60825 |
— | ||
| replacement | |||||
|
9151160825
|
9151160825
91511-B0825 Bolt (For Transfer Stiffener Plate) |
91511-B0825 |
from US $1.07 |
||
|
9151160830
|
9151160830
91511-60830
Bolt Or Ring, Exhaust Pipe Front (For Front)
|
91511-60830 |
— | ||
| replacement | |||||
|
9151160830
|
9151160830
91511-B0830 Bolt Or Ring, Exhaust Pipe Front (For Front) |
91511-B0830 |
from US $1.01 |
||
|
9151160850
|
9151160850
91511-60850
Bolt
|
91511-60850 |
— | ||
| replacement | |||||
|
9151160850
|
9151160850
91511-B0850 Bolt |
91511-B0850 |
from US $1.62 |
||
|
9151261040
|
9151261040
91512-61040 New Genuine Part |
91512-61040 |
US $2.80 |
||
|
9151380635
|
9151380635
91513-80635 New Genuine Part |
91513-80635 |
US $1.60 |
||
| replacement | |||||
|
9151380635
|
9151380635
91511-C0630 New Genuine Part |
91511-C0630 |
US $0.52 |
||
|
9162160816
|
9162160816
91621-60816
New Genuine Part
|
91621-60816 |
— | ||
| replacement | |||||
|
9162160816
|
9162160816
91621-B0816 BOLT WWASHER |
91621-B0816 |
from US $0.90 |
||
|
9163160622
|
9163160622
91631-60622 Screw |
91631-60622 |
US $1.12 |
||
|
9164380622
|
9164380622
91643-80622 New Genuine Part |
91643-80622 |
US $1.46 |
||
|
9164580620
|
9164580620
91645-80620 New Genuine Part |
91645-80620 |
US $1.46 |
||
| replacement | |||||
|
9164580620
|
9164580620
91641-80616 BOLT W-WASHER |
91641-80616 |
from US $0.84 |
||
|
9674119010
|
9674119010
96741-19010 Ring, O(For Oil Level Gage Guide) |
96741-19010 |
from US $2.32 |
||
