Windshield Wiper ([11.2001 - ] (0111- )UKP) Diagram Toyota COROLLA
- Year
- 2001 - 2004
- Sales region
- Europe
- Frame
- CDE120
- grade
- TERRA
- body
- HB
- ENGINE
- 1CDFTV
- TRANSMISSION
- MTM
- PRODUCT
- UKP
- Model
- COROLLA(NAP/SED/CP/HB/LB/WG)
- From
- 11.2001
- To
- 05.2004
- Gear Shift Type
- 5F
- No.of Doors
- 5D
- Vehicle Model
- Corolla HB
- Driver's Position
- RHD
- Fuel Induction
- DCR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
85110
|
85110
85110-02090
Motor Assy, Windshield Wiper
[11.2001 - 08.2002] CDE120,ZZE12#..UKP..RHD |
85110-02090 |
— | ||
|
85110
|
85110
85110-02140
Motor Assy, Windshield Wiper
[08.2002 - 05.2004] CDE120,ZZE12#..UKP..RHD DENSO |
85110-02140 |
— | ||
|
85150B
|
85150B
85150-02070
Link Assy, Wiper
[11.2001 - 08.2002] CDE120,ZZE12#..UKP..RHD |
85150-02070 |
— | ||
| replacement | |||||
|
85150B
|
85150B
85150-02071
Link Assy, Wiper
[11.2001 - 08.2002] CDE120,ZZE12#..UKP..RHD |
85150-02071 |
— | ||
|
85150B
|
85150B
85150-02120
Link Assy, Wiper
[08.2002 - 05.2004] CDE120,ZZE12#..UKP..RHD DENSO |
85150-02120 |
— | ||
|
85192
|
85192
85292-02010
Cover, Windshield Wiper Arm
[11.2001 - 05.2004] CDE120,ZZE12#..UKP |
85292-02010 |
— | ||
| replacement | |||||
|
85192
|
85192
85292-12020 Cover, Windshield Wiper Arm[11.2001 - 05.2004] CDE120,ZZE12#..UKP |
85292-12020 |
from US $1.52 |
||
|
85211B
|
85211B
85211-02100
Arm, Front Wiper, Rh
[11.2001 - 05.2004] CDE120,ZZE12#..UKP..RHD |
85211-02100 |
— | ||
|
85212A
|
85212A
85212-02100
Blade, Fr Wiper, Rh
[11.2001 - 05.2004] CDE120,ZZE12#..UKP..RHD |
85212-02100 |
— | ||
|
85221B
|
85221B
85221-02110
Arm, Front Wiper, Lh
[11.2001 - 05.2004] CDE120,ZZE12#..UKP..RHD |
85221-02110 |
— | ||
|
85222A
|
85222A
85222-05090
Blade, Fr Wiper, Rh
[11.2001 - 05.2004] CDE120,ZZE12#..UKP..RHD |
85222-05090 |
— | ||
|
9011906933
|
9011906933
90119-06933 New Genuine Part |
90119-06933 |
US $1.75 |
||
|
9017908113
|
9017908113
90179-08113 Nut (For Front Wiper Arm Setting) |
90179-08113 |
from US $1.92 |
||
