Heating & Air Conditioning - Cooler Piping ([06.1991 - ] (9106- )CE10#) Diagram Toyota COROLLA
- Year
- 1991 - 1995
- Sales region
- Japan
- Frame
- CE100
- grade
- DX
- body
- 4DS
- ENGINE
- 2C
- TRANSMISSION
- MTM
- Model
- COROLLA
- From
- 06.1991
- To
- 05.1995
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88453A
|
88453A
88453-12070
Fan, Cooling
[06.1991 -] CE10# |
88453-12070 |
— | ||
|
88454A
|
88454A
88454-12140
Shroud, Fan
[06.1991 -] CE10# |
88454-12140 |
— | ||
|
88460
|
88460
88460-12420 Condenser Assy, Cooler[06.1991 - 05.1993] CE10# |
88460-12420 |
US $438.26 |
||
|
88460
|
88460
88460-12450 Condenser Assy, Cooler[05.1993 - 05.1997] CE10# |
88460-12450 |
US $512.51 |
||
|
88467
|
88467
88467-12100 Cushion, Cooler Condenser, No.1[06.1991 -] AE10#,CE10#,EE10# |
88467-12100 |
US $4.54 |
||
|
88467A
|
88467A
88467-12110 Cushion, Cooler Condenser, No.2[06.1991 -] AE10#,CE10#,EE10# |
88467-12110 |
from US $4.37 |
||
|
88470
|
88470
88471-12020
Receiver & Dryer Assy, Cooler
[06.1991 - 05.1993] AE10#,CE10#,EE10# |
88471-12020 |
— | ||
| replacement | |||||
|
88470
|
88470
88471-12060 Receiver & Dryer Assy, Cooler[06.1991 - 05.1993] AE10#,CE10#,EE10# |
88471-12060 |
from US $51.98 |
||
|
88470
|
88470
88471-60010 Receiver & Dryer Assy, Cooler[05.1993 -] AE10#,CE10#,EE10# |
88471-60010 |
from US $87.54 |
||
|
88472
|
88472
88473-12080
Bracket, Receiver Tank, No.1
[06.1991 -] AE10#,CE10#,EE10# |
88473-12080 |
— | ||
|
88550
|
88550
88550-12130
Motor, Cooling Fan
[06.1991 - 12.1993] AE10#,CE10#,EE10# |
88550-12130 |
— | ||
|
88590
|
88590
88590-12220
Blower Assy, W/shroud
[06.1991 -] CE10# |
88590-12220 |
— | ||
|
88716A
|
88716A
88726-12360 Pipe, Cooler Refrigerant Liquid, A[06.1991 - 05.1993] AE10#,CE10#,EE10# |
88726-12360 |
US $56.64 |
||
|
88716A
|
88716A
88726-12410
Pipe, Cooler Refrigerant Liquid, A
[05.1993 -] AE10#,CE10#,EE10# |
88726-12410 |
— | ||
|
8889912290
|
8889912290
88899-12290
Cover, Evaporator
|
88899-12290 |
— | ||
|
9009904117
|
9009904117
90099-04117 Bolt, Radiator Side Support Plate |
90099-04117 |
US $0.70 |
||
|
9009904119
|
9009904119
90099-04119 BOLT WASHER HEAD |
90099-04119 |
from US $0.70 |
||
|
9009914044
|
9009914044
90099-14044 Ring, O(For Cooler Refrigerant Liquid Hose) |
90099-14044 |
US $0.70 |
||
|
9009914119
|
9009914119
90099-14119 Ring, O(For Cooler Refrigerant Liquid Pipe) |
90099-14119 |
from US $2.27 |
||
| replacement | |||||
|
9009914119
|
9009914119
90099-14119-TH O RING |
90099-14119-TH |
US $0.72 |
||
|
9011906334
|
9011906334
90119-06334 New Genuine Part |
90119-06334 |
US $1.92 |
||
|
9015960187
|
9015960187
90159-60187 SCREW |
90159-60187 |
from US $0.96 |
||
|
9165160616
|
9165160616
91651-60616 BOLT |
91651-60616 |
from US $0.47 |
||
|
9338556025
|
9338556025
93385-56025 New Genuine Part |
93385-56025 |
US $0.44 |
||
