Front Axle Housing & Differential ([10.1989 - ] E59F (8910- )CE95) Diagram Toyota COROLLA
- Year
- 1989 - 1991
- Sales region
- Japan
- Frame
- CE95
- grade
- TX
- body
- 4D
- ENGINE
- 2C
- TRANSMISSION
- MTM
- Model
- COROLLA
- From
- 10.1989
- To
- 06.1991
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31105D
|
31105D
90311-30006
Seal, Oil, No.1(For Front Transaxle Case)
[10.1987 - 05.1990] AE95,CE95..5F |
90311-30006 |
— | ||
| replacement | |||||
|
31105D
|
31105D
90311-30017 Seal, Oil, No.1(For Front Transaxle Case)OIL, NO.1(FOR FRONT TRANSAXLE CASE) [10.1987 - 05.1990] AE95,CE95..5F |
90311-30017 |
from US $4.64 |
||
|
31115C
|
31115C
31115-20020 Case, Transaxle[10.1989 - 06.1991] CE95 |
31115-20020 |
US $484.85 |
||
| replacements | |||||
|
31115C
|
31115C
31115-33013 Case, Front Transaxle(Mtm)[10.1989 - 06.1991] CE95 |
31115-33013 |
US $538.72 |
||
|
31115C
|
31115C
31121-20010
Cover, Clutch Housing, No.1
[10.1989 - 06.1991] CE95 |
31121-20010 |
— | ||
|
31116H
|
31116H
91511-41020 Bolt(For Front Transaxle Case Cover)[10.1989 - 06.1991] CE95 |
91511-41020 |
US $2.62 |
||
| replacement | |||||
|
31116H
|
31116H
91622-B1025 Bolt(For Front Transaxle Case Cover)[10.1989 - 06.1991] CE95 |
91622-B1025 |
US $2.72 |
||
|
31116P
|
31116P
31116-12020 Cover, Transaxle Case[10.1989 - 06.1991] CE95 |
31116-12020 |
US $5.68 |
||
|
33143C
|
33143C
33143-12010
Baffle, Front Differential Oil
[10.1987 - 06.1991] AE95,CE95..5F |
33143-12010 |
— | ||
|
33449
|
33449
33449-20010 Magnet, Transmission[10.1987 - 06.1991] AE95,CE95..5F |
33449-20010 |
US $5.97 |
||
|
33481
|
33481
33481-12080 Gear, Speedometer Drive (Mtm)[10.1989 - 06.1991] CE95 |
33481-12080 |
US $54.02 |
||
|
41221
|
41221
41221-12260 Gear, Front Differential Ring[10.1987 - 06.1991] AE95,CE95..5F |
41221-12260 |
US $182 |
||
|
41222B
|
41222B
90105-12150 Bolt (For Rear Differential Ring Gear Set)[10.1987 - 06.1991] AE95,CE95..5F |
90105-12150 |
US $4.16 |
||
|
41302F
|
41302F
41302-12030 Case Sub-Assy, Front Differential[10.1989 - 06.1991] AE95,CE95..5F |
41302-12030 |
US $247.52 |
||
|
41305
|
41305
41305-12020 Gear Sub-Assy, Differential Side[10.1989 - 06.1991] CE95 |
41305-12020 |
US $109.20 |
||
|
41306F
|
41306F
41306-32010 Shaft Sub-Assy, Differential Side Gear Inter[10.1989 - 06.1991] CE95 |
41306-32010 |
US $136.86 |
||
|
41306G
|
41306G
90521-26004 Ring, Hole Snap (For Front Differential Side Gear Shaft)[10.1987 - 06.1991] AE95,CE95 |
90521-26004 |
from US $1.60 |
||
|
41310
|
41310
41310-12080 Case Assy, Differential[10.1989 - 06.1991] CE95 |
41310-12080 |
US $285.38 |
||
| replacement | |||||
|
41310
|
41310
41310-42H03 Case Assy, Differential[10.1989 - 06.1991] CE95 |
41310-42H03 |
US $356.72 |
||
|
41311C
|
41311C
90564-76001 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．００，マーク ０ |
90564-76001 |
US $4.02 |
||
|
41311C
|
41311C
90564-76002 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．０５，マーク １ |
90564-76002 |
US $4.08 |
||
|
41311C
|
41311C
90564-76003 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．１０，マーク ２ |
90564-76003 |
US $4.08 |
||
|
41311C
|
41311C
90564-76004 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．１５，マーク ３ |
90564-76004 |
US $4.08 |
||
|
41311C
|
41311C
90564-76005 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．２０，マーク ４ |
90564-76005 |
US $5.53 |
||
|
41311C
|
41311C
90564-76006 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．２５，マーク ５ |
90564-76006 |
US $5.53 |
||
|
41311C
|
41311C
90564-76007 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．３０，マーク ６ |
90564-76007 |
US $5.53 |
||
|
41311C
|
41311C
90564-76008 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．３５，マーク ７ |
90564-76008 |
US $5.53 |
||
|
41311C
|
41311C
90564-76009 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．４０，マーク ８ |
90564-76009 |
US $5.53 |
||
|
41311C
|
41311C
90564-76010 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．４５，マーク ９ |
90564-76010 |
US $5.53 |
||
|
41311C
|
41311C
90564-76011 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．５０，マーク Ａ |
90564-76011 |
US $5.53 |
||
|
41311C
|
41311C
90564-76012 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．５５，マーク Ｂ |
90564-76012 |
US $5.53 |
||
|
41311C
|
41311C
90564-76013 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．６０，マーク Ｃ |
90564-76013 |
US $5.53 |
||
|
41311C
|
41311C
90564-76014 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．６５，マーク Ｄ |
90564-76014 |
US $5.53 |
||
|
41311C
|
41311C
90564-76015 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．７０，マーク Ｅ |
90564-76015 |
US $5.53 |
||
|
41311C
|
41311C
90564-76016 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．７５，マーク Ｆ |
90564-76016 |
US $5.53 |
||
|
41311C
|
41311C
90564-76017 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．８０，マーク Ｇ |
90564-76017 |
US $5.53 |
||
|
41311C
|
41311C
90564-76018 Shim(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝２．８５，マーク Ｈ |
90564-76018 |
US $5.53 |
||
|
41311E
|
41311E
90366-57001 Bearing(For Rear Differential Case)[10.1987 - 06.1991] AE95,CE95..5F |
90366-57001 |
US $44.23 |
||
|
41311F
|
41311F
90366-50014 Bearing(For Rear Differential Case)[10.1987 - 06.1991] AE95,CE95..5F |
90366-50014 |
US $36.78 |
||
|
41331F
|
41331F
41331-12030
Gear, Center Differential Side
[10.1987 - 06.1991] AE95,CE95 |
41331-12030 |
— | ||
|
41341F
|
41341F
41341-20011 Pinion, Rear Differential[10.1987 - 06.1991] AE95,CE95..5F |
41341-20011 |
US $109.58 |
||
|
41341G
|
41341G
41341-12040
Pinion, Center Differential
[10.1989 - 06.1991] AE95,CE95..5F |
41341-12040 |
— | ||
|
41342D
|
41342D
41342-12120 Shaft, Center Differential Pinion[10.1989 - 06.1991] AE95,CE95..5F |
41342-12120 |
US $12.38 |
||
|
41342F
|
41342F
41342-12040 Shaft, Center Differential Pinion[10.1987 - 06.1991] AE95,CE95..5F |
41342-12040 |
US $16.60 |
||
|
41342G
|
41342G
41342-12050 Shaft, Front Differential Pinion, No.2[10.1987 - 06.1991] AE95,CE95..5F |
41342-12050 |
US $7.86 |
||
|
41342H
|
41342H
90520-99007 Ring, Shaft Snap(For Pinion Shaft Spacer)[10.1989 - 06.1991] AE95,CE95..5F |
90520-99007 |
US $4.80 |
||
|
41342J
|
41342J
90560-99002 Spacer (For Center Differential Pinion Shaft)[10.1989 - 06.1991] AE95,CE95..5F |
90560-99002 |
US $10.48 |
||
|
41342K
|
41342K
90520-94001 Ring, Shaft Snap(For Pinion Shaft Spacer)[10.1987 - 06.1991] AE95,CE95..5F |
90520-94001 |
US $4.08 |
||
|
41342L
|
41342L
90560-97001
Spacer (For Transfer Output Shaft)
[10.1987 - 06.1991] AE95,CE95..5F |
90560-97001 |
— | ||
|
41351F
|
41351F
41351-12010 Washer, Rear Differential Pinion Thrust[10.1987 - 06.1991] AE95,CE95..5F |
41351-12010 |
US $2.80 |
||
|
41351G
|
41351G
41351-12060
Washer, Center Differential Pinion Thrust
[10.1989 - 06.1991] AE95,CE95..5F |
41351-12060 |
— | ||
|
41361E
|
41361E
41362-20020 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝０．８０，マーク Ｏ |
41362-20020 |
US $5.68 |
||
|
41361E
|
41361E
41362-20030 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝０．８５，マーク １ |
41362-20030 |
US $5.68 |
||
|
41361E
|
41361E
41362-20040 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝０．９０，マーク ２ |
41362-20040 |
US $5.68 |
||
|
41361E
|
41361E
41362-20050 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝０．９５，マーク ３ |
41362-20050 |
US $5.68 |
||
|
41361E
|
41361E
41362-20060 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．００，マーク ４ |
41362-20060 |
US $5.68 |
||
|
41361E
|
41361E
41362-20070 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．０５，マーク ５ |
41362-20070 |
US $5.68 |
||
|
41361E
|
41361E
41362-20080 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１０，マーク ６ |
41362-20080 |
US $5.68 |
||
|
41361E
|
41361E
41362-20090 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１５，マーク ７ |
41362-20090 |
US $5.68 |
||
|
41361E
|
41361E
41362-20100 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２０，マーク ８ |
41362-20100 |
US $5.68 |
||
|
41361E
|
41361E
41362-20110 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２５，マーク ９ |
41362-20110 |
US $5.68 |
||
|
41361E
|
41361E
41362-20120 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．３０，マーク Ａ |
41362-20120 |
US $5.68 |
||
|
41361E
|
41361E
41362-20130 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．３５，マーク Ｂ |
41362-20130 |
US $5.68 |
||
|
41361E
|
41361E
41362-20140 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．４０，マーク Ｃ |
41362-20140 |
US $5.68 |
||
|
41361F
|
41361F
41361-12330 Washer, Center Differential Side Gear Thrust, No.2[10.1987 - 06.1991] AE95,CE95..5F;AE95..4FC..EFI 厚さ＝０．９５，マーク Ａ |
41361-12330 |
US $2.91 |
||
|
41361F
|
41361F
41361-12340 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．００，マーク Ｂ |
41361-12340 |
US $2.91 |
||
|
41361F
|
41361F
41361-12350 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．０５，マーク Ｃ |
41361-12350 |
US $2.91 |
||
|
41361F
|
41361F
41361-12360 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１０，マーク Ｄ |
41361-12360 |
US $2.91 |
||
|
41361F
|
41361F
41361-12370
Washer, Center Differential Side Gear Thrust, No.1
[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１５，マーク Ｅ |
41361-12370 |
— | ||
|
41361F
|
41361F
41361-12380 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２０，マーク Ｆ |
41361-12380 |
US $2.91 |
||
|
41361F
|
41361F
41361-12390 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２５，マーク Ｇ |
41361-12390 |
US $2.91 |
||
|
41361F
|
41361F
41361-12400 Washer, Center Differential Side Gear Thrust, No.2[10.1987 - 06.1991] AE95,CE95 厚さ＝１．３０，マーク Ｈ |
41361-12400 |
US $2.91 |
||
|
41361F
|
41361F
41361-12410 Washer, Center Differential Side Gear Thrust, No.2[10.1987 - 06.1991] AE95,CE95 厚さ＝１．３５，マーク Ｊ |
41361-12410 |
US $2.91 |
||
|
41361F
|
41361F
41361-12420 Washer, Center Differential Side Gear Thrust, No.2[10.1987 - 06.1991] AE95,CE95 厚さ＝１．４０，マーク Ｋ |
41361-12420 |
US $2.91 |
||
|
41361G
|
41361G
90208-36001 Washer, Conical Spring(For Differential Case)[10.1987 - 06.1991] AE95,CE95..5F 左側 |
90208-36001 |
US $3.32 |
||
|
41361G
|
41361G
90208-48001 Washer, Conical Spring(For Center Differential Side Gear)[10.1989 - 06.1991] CE95 右側 |
90208-48001 |
US $7.28 |
||
|
41362A
|
41362A
41362-20280 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝０．８０，マーク ＶＡ |
41362-20280 |
US $5.24 |
||
|
41362A
|
41362A
41362-20290 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝０．８５，マーク ＶＢ |
41362-20290 |
US $5.24 |
||
|
41362A
|
41362A
41362-20300 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝０．９０，マーク ＶＣ |
41362-20300 |
US $5.24 |
||
|
41362A
|
41362A
41362-20310 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝０．９５，マーク ＶＤ |
41362-20310 |
US $5.24 |
||
|
41362A
|
41362A
41362-20320 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．００，マーク ＶＥ |
41362-20320 |
US $5.24 |
||
|
41362A
|
41362A
41362-20330 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．０５，マーク ＶＦ |
41362-20330 |
US $3.06 |
||
|
41362A
|
41362A
41362-20340 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．１０，マーク ＶＧ |
41362-20340 |
US $3.79 |
||
|
41362A
|
41362A
41362-20350 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．０５，マーク ＶＨ |
41362-20350 |
US $3.79 |
||
|
41362A
|
41362A
41362-20360 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．２０，マーク ＶＪ |
41362-20360 |
US $3.79 |
||
|
41362A
|
41362A
41362-20370 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．２５，マーク ＶＫ |
41362-20370 |
US $3.79 |
||
|
41362A
|
41362A
41362-20380 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．３０，マーク ＶＬ |
41362-20380 |
US $3.79 |
||
|
41362A
|
41362A
41362-20390 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．３５，マーク ＶＭ |
41362-20390 |
US $3.79 |
||
|
41362A
|
41362A
41362-20400 Washer, Center Differential Side Gear Thrust, No.2[10.1989 - 08.1990] CE95 厚さ＝１．４０，マーク ＶＮ |
41362-20400 |
US $3.79 |
||
|
41362F
|
41362F
41361-12340 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．００，マーク Ｂ |
41361-12340 |
US $2.91 |
||
|
41362F
|
41362F
41361-12350 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．０５，マーク Ｃ |
41361-12350 |
US $2.91 |
||
|
41362F
|
41362F
41361-12360 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１０，マーク Ｄ |
41361-12360 |
US $2.91 |
||
|
41362F
|
41362F
41361-12370
Washer, Center Differential Side Gear Thrust, No.1
[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．１５，マーク Ｅ |
41361-12370 |
— | ||
|
41362F
|
41362F
41361-12380 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２０，マーク Ｆ |
41361-12380 |
US $2.91 |
||
|
41362F
|
41362F
41361-12390 Washer, Center Differential Side Gear Thrust, No.1[10.1987 - 06.1991] AE95,CE95..5F 厚さ＝１．２５，マーク Ｇ |
41361-12390 |
US $2.91 |
||
|
41375A
|
41375A
41375-12020 Holder, Front Differential Pinion Shaft[10.1987 - 06.1991] AE95,CE95..5F |
41375-12020 |
US $41.06 |
||
|
41375B
|
41375B
41375-12050 Holder, Center Differential Pinion Shaft[10.1989 - 06.1991] AE95,CE95..5F |
41375-12050 |
US $22.86 |
||
| replacement | |||||
|
41375B
|
41375B
41375-12051 Holder, Center Differential Pinion Shaft[10.1989 - 06.1991] AE95,CE95..5F |
41375-12051 |
US $22.71 |
||
