Roof Panel & Back Window Glass ([05.1988 - ] ﾑ-ﾝ ﾙ-ﾌ (8805- )) Diagram Toyota COROLLA
- Year
- 1988 - 1990
- Sales region
- Japan
- Frame
- NL30
- grade
- ZX
- body
- SED
- ENGINE
- 1NT
- TRANSMISSION
- ATM
- Model
- COROLLA 2
- From
- 05.1988
- To
- 09.1990
- Gear Shift Type
- 4FC
- No.of Doors
- 5DS
- Vehicle Model
- Corolla 2
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
63102A
|
63102A
63102-16020 Panel Sub-Assy, Windshield Header[05.1988 - 09.1990] EL3#,NL30 |
63102-16020 |
US $56.78 |
||
|
63105A
|
63105A
63105-16050 Frame Sub-Assy, Back Door Opening[05.1988 - 09.1990] EL3#,NL30..5DS |
63105-16050 |
US $106.29 |
||
|
63111
|
63111
63111-16150 Panel, Roof[05.1988 - 09.1990] EL3#,NL30..5DS |
63111-16150 |
US $474.66 |
||
|
9015940193
|
9015940193
90159-40193 New Genuine Part |
90159-40193 |
US $1.60 |
||
|
9015960219
|
9015960219
90159-60219
New Genuine Part
|
90159-60219 |
— | ||
|
9016250007
|
9016250007
90162-50007
New Genuine Part
|
90162-50007 |
— | ||
|
9016840027
|
9016840027
90168-40027 New Genuine Part |
90168-40027 |
from US $1.28 |
||
|
9017906070
|
9017906070
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
|
90179-06070 |
— | ||
| replacement | |||||
|
9017906070
|
9017906070
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.59 |
||
|
9017906115
|
9017906115
90179-06115 Nut (For Rear Wiper Arm Setting) |
90179-06115 |
from US $1.92 |
||
|
9018905043
|
9018905043
90189-05043 Clip, Rear Door Service Hole |
90189-05043 |
US $1.60 |
||
|
9033330002
|
9033330002
90333-30002 Cover, Front Floor Hole |
90333-30002 |
from US $1.12 |
||
|
9046714001
|
9046714001
90467-14001 Clip Or Clamp(For Ventilation Hose) |
90467-14001 |
from US $0.76 |
||
| replacement | |||||
|
9046714001
|
9046714001
90466-T0026
Clip Or Clamp(For Ventilation Hose)
|
90466-T0026 |
— | ||
|
9046805017
|
9046805017
90468-05017 Clip, Roof Side Rail Garnish |
90468-05017 |
from US $1.01 |
||
|
9046816009
|
9046816009
90468-16009 Clip(For Ventilation Hose No.2) |
90468-16009 |
US $1.31 |
||
