Switch & Relay & Computer ([02.2008 - 02.2009] ENGINE & TRANSMISSION (0802-0902)ZZE150) Diagram Toyota COROLLA
- Year
- 2008 - 2009
- Sales region
- Europe
- Frame
- ZZE150
- grade
- D
- ENGINE
- 4ZZFE
- TRANSMISSION
- MTM
- Model
- COROLLA (S.AFRICA)
- From
- 02.2008
- To
- 02.2009
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla
- Driver's Position
- LHD
- Fuel Induction
- HTWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-05010
Switch Assy, Oil Pressure (For Engine)
[02.2008 - 02.2009] ZRE151,ZZE150 VALEO |
83530-05010 |
— | ||
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[02.2008 - 02.2009] ZRE151,ZZE150 DENSO |
83530-28020 |
from US $29.33 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [02.2008 - 02.2009] ZRE151,ZZE150 DENSO |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[02.2008 - 02.2009] ZRE151,ZZE150 DENSO |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [02.2008 - 02.2009] ZRE151,ZZE150 YAZAKI |
83530-60020 |
from US $25.21 |
||
|
84210
|
84210
84210-52010 Switch Assy, Back-Up Lamp[02.2008 - 02.2009] NDE150,ZRE151,ZZE150..5F |
84210-52010 |
from US $22.80 |
||
|
89465
|
89465
89465-02140
Sensor, Oxygen
[02.2008 - 02.2009] ZZE150 |
89465-02140 |
— | ||
|
89465A
|
89465A
89465-02270
Sensor, Oxygen No.2
[02.2008 - 02.2009] ZZE150 |
89465-02270 |
— | ||
|
89615
|
89615
89615-02010
Sensor, Knock Control
[02.2008 - 02.2009] ZZE150 |
89615-02010 |
— | ||
|
827152B340
|
827152B340
82715-2B340 Bracket,wiring Harness Clamp |
82715-2B340 |
US $4.22 |
||
|
8271512L30
|
8271512L30
82715-12L30
Bracket,wiring Harness Clamp
|
82715-12L30 |
— | ||
|
8271552A40
|
8271552A40
82715-52A40
Bracket,wiring Harness Clamp
|
82715-52A40 |
— | ||
|
8271502500
|
8271502500
82715-02500 Bracket,wiring Harness Clamp |
82715-02500 |
US $7.28 |
||
|
8271502510
|
8271502510
82715-02510 Bracket,wiring Harness Clamp |
82715-02510 |
US $7.28 |
||
|
9011906922
|
9011906922
90119-06922 Bolt |
90119-06922 |
US $1.46 |
||
| replacement | |||||
|
9011906922
|
9011906922
91621-J0612 BOLT W-WASHER |
91621-J0612 |
from US $0.70 |
||
|
9012608046
|
9012608046
90126-08046 New Genuine Part |
90126-08046 |
US $3.52 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.84 |
||
|
9043018008
|
9043018008
90430-18008 Gasket |
90430-18008 |
from US $0.92 |
||
| replacement | |||||
|
9043018008
|
9043018008
90430-T0021
Gasket(For Manual Transmission Filler Plug)
|
90430-T0021 |
— | ||
|
9161160822
|
9161160822
91611-60822 Bolt |
91611-60822 |
from US $2.48 |
||
|
9167180612
|
9167180612
91671-80612 Bolt |
91671-80612 |
from US $0.68 |
||
