Front Axle Housing & Differential ([08.2000 - ] E351 (0008- )CE121..5F) Diagram Toyota COROLLA AXIO/ FIELDER
- Year
- 2000 - 2004
- Sales region
- Japan
- Frame
- CE121
- grade
- G
- body
- SED
- ENGINE
- 3CE
- TRANSMISSION
- MTM
- Model
- COROLLA
- From
- 08.2000
- To
- 04.2004
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31105D
|
31105D
90311-30006
Seal, Oil, No.1(For Front Transaxle Case)
[08.2000 - 09.2002] CE121..5F |
90311-30006 |
— | ||
| replacement | |||||
|
31105D
|
31105D
90311-30017 Seal, Oil, No.1(For Front Transaxle Case)OIL, NO.1(FOR FRONT TRANSAXLE CASE) [08.2000 - 09.2002] CE121..5F |
90311-30017 |
from US $4.64 |
||
|
31115C
|
31115C
31115-28010 Case, Front Transaxle(Mtm)[08.2000 - 07.2001] CE121..5F |
31115-28010 |
US $538.72 |
||
| replacement | |||||
|
31115C
|
31115C
31115-20061 Case, Front Transaxle(Mtm)FRONT TRANSAXLE(MTM) [08.2000 - 07.2001] CE121..5F |
31115-20061 |
US $538.72 |
||
|
31115C
|
31115C
31115-28011 Case, Front Transaxle(Mtm)[07.2001 - 09.2002] CE121..5F |
31115-28011 |
US $538.72 |
||
| replacement | |||||
|
31115C
|
31115C
31115-20061 Case, Front Transaxle(Mtm)FRONT TRANSAXLE(MTM) [07.2001 - 09.2002] CE121..5F |
31115-20061 |
US $538.72 |
||
|
31116H
|
31116H
91511-41020 Bolt(For Front Transaxle Case Cover)[08.2000 - 09.2001] CE121..5F |
91511-41020 |
US $2.62 |
||
| replacement | |||||
|
31116H
|
31116H
91622-B1025 Bolt(For Front Transaxle Case Cover)[08.2000 - 09.2001] CE121..5F |
91622-B1025 |
US $2.72 |
||
|
31116H
|
31116H
91622-61025 Bolt(For Front Transaxle Case Cover)[09.2001 - 09.2002] CE121..5F |
91622-61025 |
US $2.33 |
||
| replacement | |||||
|
31116H
|
31116H
91622-B1025 Bolt(For Front Transaxle Case Cover)[09.2001 - 09.2002] CE121..5F |
91622-B1025 |
US $2.72 |
||
|
31116H
|
31116H
91622-B1025 Bolt(For Front Transaxle Case Cover)[09.2002 - 04.2004] CE121..5F |
91622-B1025 |
US $2.72 |
||
|
31116P
|
31116P
31116-12020 Cover, Transaxle Case[08.2000 - 09.2002] CE121..5F |
31116-12020 |
US $5.68 |
||
|
33143C
|
33143C
33143-28010 Baffle, Front Differential Oil[08.2000 - 09.2002] CE121..5F |
33143-28010 |
US $2.97 |
||
|
33449
|
33449
33449-20010 Magnet, Transmission[08.2000 - 09.2002] CE121..5F |
33449-20010 |
US $5.97 |
||
|
33481
|
33481
33481-20150
Gear, Speedometer Drive (Mtm)
[08.2000 - 09.2002] CE121..5F 歯数＝３２ |
33481-20150 |
— | ||
|
41221
|
41221
41221-28080 Gear, Front Differential Ring[08.2000 - 09.2002] CE121..5F |
41221-28080 |
US $182 |
||
| replacement | |||||
|
41221
|
41221
41221-20390
Gear, Front Differential Ring
[08.2000 - 09.2002] CE121..5F |
41221-20390 |
— | ||
|
41222B
|
41222B
90105-12319 Bolt (For Front Differential Ring Gear Set)[08.2000 - 09.2002] CE121..5F |
90105-12319 |
US $1.76 |
||
|
41301L
|
41301L
41301-28070 Case Sub-Assy, Front Differential, No.1[08.2000 - 09.2002] CE121..5F |
41301-28070 |
US $410.59 |
||
|
41311C
|
41311C
90564-56055 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．００，マーク ０ |
90564-56055 |
US $3.35 |
||
|
41311C
|
41311C
90564-56056 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．０５，マーク １ |
90564-56056 |
US $3.35 |
||
|
41311C
|
41311C
90564-56057 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．１０，マーク ２ |
90564-56057 |
US $3.35 |
||
|
41311C
|
41311C
90564-56058 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．１５，マーク ３ |
90564-56058 |
US $3.35 |
||
|
41311C
|
41311C
90564-56059 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．２０，マーク ４ |
90564-56059 |
US $4.37 |
||
|
41311C
|
41311C
90564-56060 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．２５，マーク ５ |
90564-56060 |
US $4.37 |
||
|
41311C
|
41311C
90564-56061 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．３０，マーク ６ |
90564-56061 |
US $4.37 |
||
|
41311C
|
41311C
90564-56062 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．３５，マーク ７ |
90564-56062 |
US $4.37 |
||
|
41311C
|
41311C
90564-56063 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．４０，マーク ８ |
90564-56063 |
US $4.37 |
||
|
41311C
|
41311C
90564-56064 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．４５，マーク ９ |
90564-56064 |
US $4.37 |
||
|
41311C
|
41311C
90564-56065 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．５０，マーク Ａ |
90564-56065 |
US $4.37 |
||
|
41311C
|
41311C
90564-56066 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．５５，マーク Ｂ |
90564-56066 |
US $4.37 |
||
|
41311C
|
41311C
90564-56067 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．６０，マーク Ｃ |
90564-56067 |
US $4.37 |
||
|
41311C
|
41311C
90564-56068 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．６５，マーク Ｄ |
90564-56068 |
US $4.37 |
||
|
41311C
|
41311C
90564-56069 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．７０，マーク Ｅ |
90564-56069 |
US $4.37 |
||
|
41311C
|
41311C
90564-56070 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．７５，マーク Ｆ |
90564-56070 |
US $4.37 |
||
|
41311C
|
41311C
90564-56071 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．８０，マーク Ｇ |
90564-56071 |
US $4.37 |
||
|
41311C
|
41311C
90564-56072 Shim (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F 厚さ＝２．８５，マーク Ｈ |
90564-56072 |
US $4.37 |
||
|
41311E
|
41311E
90366-57001 Bearing(For Rear Differential Case)[08.2000 - 09.2002] CE121..5F |
90366-57001 |
from US $44.23 |
||
|
41311F
|
41311F
90366-50072 Bearing, Tapered Roller (For Front Differential Case Rear)[08.2000 - 09.2002] CE121..5F |
90366-50072 |
US $43.32 |
||
|
41331F
|
41331F
41331-28020 Gear, Front Differential Side[08.2000 - 09.2002] CE121..5F |
41331-28020 |
US $55.04 |
||
| replacement | |||||
|
41331F
|
41331F
41331-28040 Gear, Front Differential Side[08.2000 - 09.2002] CE121..5F |
41331-28040 |
US $50.52 |
||
|
41341F
|
41341F
41341-28010 Pinion, Front Differential[08.2000 - 09.2002] CE121..5F |
41341-28010 |
US $31.30 |
||
| replacement | |||||
|
41341F
|
41341F
41341-28030 Pinion, Front Differential[08.2000 - 09.2002] CE121..5F |
41341-28030 |
US $28.68 |
||
|
41342A
|
41342A
90250-06058 Pin, Straight(For Timing Gear Case)[08.2000 - 09.2002] ZZE122..5F; ZZE122..4FC;CE121,NZE121,124,ZZE123,124 |
90250-06058 |
from US $2.09 |
||
|
41342F
|
41342F
41342-28010 Shaft, Front Differential Pinion, No.1[08.2000 - 09.2002] CE121..5F |
41342-28010 |
US $19.51 |
||
|
41351F
|
41351F
41351-30060 Washer, Rear Differential Pinion Thrust[08.2000 - 09.2002] CE121..5F |
41351-30060 |
from US $2.16 |
||
|
41361F
|
41361F
41361-28230 Washer, Front Differential Side Gear Thrust, No.1[08.2000 - 09.2002] CE121..5F 厚さ＝１．０，マーク １ |
41361-28230 |
US $2.62 |
||
|
41361F
|
41361F
41361-28240 Washer, Front Differential Side Gear Thrust, No.1[08.2000 - 09.2002] CE121..5F 厚さ＝１．１，マーク ２ |
41361-28240 |
US $2.62 |
||
|
41361F
|
41361F
41361-28250 Washer, Front Differential Side Gear Thrust, No.1[08.2000 - 09.2002] CE121..5F 厚さ＝１．２，マーク ３ |
41361-28250 |
US $2.62 |
||
|
41361F
|
41361F
41361-28260 Washer, Front Differential Side Gear Thrust, No.1[08.2000 - 09.2002] CE121..5F 厚さ＝１．３，マーク ４ |
41361-28260 |
US $2.62 |
||
