Clutch Pedal & Flexible Hose ([08.2000 - ] (0008- )MTM) Diagram Toyota COROLLA AXIO/ FIELDER
- Year
- 2000 - 2006
- Sales region
- Japan
- Frame
- NZE120
- grade
- X
- body
- SED
- ENGINE
- 2NZFE
- TRANSMISSION
- MTM
- Model
- COROLLA
- From
- 08.2000
- To
- 09.2006
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-12450
Pedal Sub-Assy, Clutch
[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM ｲﾗｽﾄ ｺﾒﾝﾄ ｻﾝｼﾖｳ |
31301-12450 |
— | ||
|
31301A
|
31301A
90507-14050 Spring(For Clutch Pedal)[08.2000 - 09.2002] CE121,NZE120,121..5F |
90507-14050 |
US $1.22 |
||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90541-06036 |
from US $0.94 |
||
| replacement | |||||
|
31301B
|
31301B
90541060361
CUSHION
[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90541060361 |
— | ||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90386-13015 |
from US $0.64 |
||
|
31301F
|
31301F
90101-10369 Bolt(For Clutch Pedal Stopper)[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90101-10369 |
from US $1.31 |
||
|
31321
|
31321
31321-52010 Pad, Brake Pedal[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
31321-52010 |
from US $1.99 |
||
|
31324
|
31324
90109-10167 Shaft, Clutch Pedal[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90109-10167 |
US $3.40 |
||
|
31453A
|
31453A
90249-08243 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM 長さ＝３０ |
90249-08243 |
US $2.80 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
90386-08002 |
from US $3.22 |
||
|
55107A
|
55107A
55107-12200 Support Sub-Assy, Clutch Pedal[08.2000 - 09.2002] CE121,NZE120,121,ZZE122,123..MTM |
55107-12200 |
US $45.43 |
||
|
91621J0814
|
91621J0814
91621-J0814 Bolt (For Transmission Control Cable Bracket) |
91621-J0814 |
from US $0.80 |
||
|
9017910088
|
9017910088
90179-10088 Nut |
90179-10088 |
from US $0.99 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9163560832
|
9163560832
91635-60832 New Genuine Part |
91635-60832 |
US $1.43 |
||
|
9412041000
|
9412041000
94120-41000 Nut(For Clutch Pedal Stopper) |
94120-41000 |
from US $0.76 |
||
| replacement | |||||
|
9412041000
|
9412041000
90170-A0002 Nut |
90170-A0002 |
US $2.33 |
||
