Switch & Relay & Computer ([09.2006 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0609- )ZRE14#) Diagram Toyota COROLLA AXIO/ FIELDER
- Year
- 2010 - 2012
- Sales region
- Japan
- Frame
- ZRE144
- grade
- LXL
- body
- SED
- ENGINE
- 2ZRFAE
- TRANSMISSION
- ATM
- Model
- COROLLA AXIO
- From
- 05.2010
- To
- 04.2012
- Gear Shift Type
- CVFC
- Vehicle Model
- Corolla Axio
- Fuel Induction
- HTWVM
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[10.2008 -] NZE14#,ZRE14# |
83530-28020 |
US $29.94 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [10.2008 -] NZE14#,ZRE14# |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[10.2008 -] NZE14#,ZRE14# |
83530-0E010 |
from US $51.25 |
||
|
84540
|
84540
84540-52070 Switch Assy, Neutral Start[10.2008 - 04.2012] NZE14#,ZRE14#..CVFC |
84540-52070 |
from US $112.48 |
||
|
89465
|
89465
89465-12850 Sensor, Oxygen[10.2008 - 04.2012] ZRE144 |
89465-12850 |
US $142.80 |
||
|
89467B
|
89467B
89467-68020 Sensor, OxygenAIR FUEL RATIO [03.2009 -] ZRE144 |
89467-68020 |
US $228.96 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[10.2008 -] NZE14#,ZRE14# |
89615-20090 |
from US $36.02 |
||
|
8271520C40
|
8271520C40
82715-20C40
Bracket,wiring Harness Clamp
|
82715-20C40 |
— | ||
|
8271520C50
|
8271520C50
82715-20C50
Bracket,wiring Harness Clamp
|
82715-20C50 |
— | ||
|
8271542710
|
8271542710
82715-42710 Bracket,wiring Harness Clamp |
82715-42710 |
US $2.80 |
||
|
9155180835
|
9155180835
91551-80835 Bolt (For Front Oil Pump Setting) |
91551-80835 |
from US $0.84 |
||
|
9155381014
|
9155381014
91553-81014 New Genuine Part |
91553-81014 |
US $1.31 |
||
|
9165140620
|
9165140620
91651-40620 BOLT |
91651-40620 |
US $1.12 |
||
