Back Door Lock & Handle ([08.1973 - 08.1978] (7308-7808)RT118,119) Diagram Toyota CORONA
- Year
- 1976 - 1978
- Sales region
- U.S.A.
- Frame
- RT119
- grade
- DLX
- body
- WG
- ENGINE
- 20R
- TRANSMISSION
- ATM
- Model
- CORONA
- From
- 05.1976
- To
- 08.1978
- Gear Shift Type
- 3HC
- No.of Doors
- 4D
- Vehicle Model
- Corona
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
67282
|
67282
67281-91256
Stopper, Back Door, No.1
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
67281-91256 |
— | ||
|
67284
|
67284
67283-21010
Stopper, Back Door, No.2
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
67283-21010 |
— | ||
|
67288
|
67288
67284-91603
Spacer, Back Door Side Stopper, Upper
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
67284-91603 |
— | ||
|
68812
|
68812
68813-21020 Protector, Back Door Hinge Arm[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD RH. |
68813-21020 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68813-21020-13
Protector, Back Door Hinge Arm
[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD RH. |
68813-21020-13 |
— | ||
|
68812
|
68812
68813-21020-03 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D RH.GRAY,GRAY |
68813-21020-03 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68813-21020-13
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D RH.GRAY,GRAY |
68813-21020-13 |
— | ||
|
68812
|
68812
68813-21020-05 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D RH.BEIGE,BEIGE |
68813-21020-05 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68813-21020-15
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D RH.BEIGE,BEIGE |
68813-21020-15 |
— | ||
|
68812
|
68812
68813-21020-13
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC RH.GRAY,GRAY |
68813-21020-13 |
— | ||
|
68812
|
68812
68813-21020-15
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC RH.BEIGE,BEIGE |
68813-21020-15 |
— | ||
|
68812
|
68812
68814-21020 Protector, Back Door Hinge Arm[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD LH. |
68814-21020 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21020-13
Protector, Back Door Hinge Arm
[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD LH. |
68814-21020-13 |
— | ||
|
68812
|
68812
68814-21020-03 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.GRAY,GRAY |
68814-21020-03 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21020-13
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.GRAY,GRAY |
68814-21020-13 |
— | ||
|
68812
|
68812
68814-21020-05 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.BEIGE,BEIGE |
68814-21020-05 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21020-15
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.BEIGE,BEIGE |
68814-21020-15 |
— | ||
|
68812
|
68812
68814-21020-13
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC LH.GRAY,GRAY |
68814-21020-13 |
— | ||
|
68812
|
68812
68814-21020-15
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC LH.BEIGE,BEIGE |
68814-21020-15 |
— | ||
|
68812
|
68812
68814-21030 Protector, Back Door Hinge Arm[03.1974 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD LH.FOR W/REAR WIPER |
68814-21030 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21030-13
Protector, Back Door Hinge Arm
[03.1974 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD LH.FOR W/REAR WIPER |
68814-21030-13 |
— | ||
|
68812
|
68812
68814-21030-03 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.FOR W/REAR WIPER,GRAY,GRAY |
68814-21030-03 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21030-13
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.FOR W/REAR WIPER,GRAY,GRAY |
68814-21030-13 |
— | ||
|
68812
|
68812
68814-21030-05 Protector, Back Door Hinge Arm[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.FOR W/REAR WIPER,BROWN,BEIGE |
68814-21030-05 |
US $10.19 |
||
| replacement | |||||
|
68812
|
68812
68814-21030-15
Protector, Back Door Hinge Arm
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D LH.FOR W/REAR WIPER,BROWN,BEIGE |
68814-21030-15 |
— | ||
|
68812
|
68812
68814-21030-13
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC LH.FOR W/REAR WIPER,GRAY,GRAY |
68814-21030-13 |
— | ||
|
68812
|
68812
68814-21030-15
Protector, Back Door Hinge Arm
[01.1977 - 08.1978] RT119..3HC LH.FOR W/REAR WIPER,BEIGE,BEIGE |
68814-21030-15 |
— | ||
|
68830
|
68830
68810-21020
Hinge Assy, Back Door, Rh
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
68810-21020 |
— | ||
|
68830A
|
68830A
68841-21020 Cover, Back Door Hinge, Rh[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD |
68841-21020 |
US $38 |
||
| replacement | |||||
|
68830A
|
68830A
68841-21020-03
Cover, Back Door Hinge, Rh
[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD |
68841-21020-03 |
— | ||
|
68830A
|
68830A
68841-21020-03
Cover, Back Door Hinge, Rh
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D GRAY,GRAY |
68841-21020-03 |
— | ||
|
68830A
|
68830A
68841-21020-05
Cover, Back Door Hinge, Rh
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D BEIGE,BEIGE |
68841-21020-05 |
— | ||
|
68830A
|
68830A
68841-21020-13
Cover, Back Door Hinge, Rh
[01.1977 - 08.1978] RT119..3HC GRAY,GRAY |
68841-21020-13 |
— | ||
|
68830A
|
68830A
68841-21020-15
Cover, Back Door Hinge, Rh
[01.1977 - 08.1978] RT119..3HC BEIGE,BEIGE |
68841-21020-15 |
— | ||
|
68830B
|
68830B
90467-08114-11 Clip, Rear Floor Mat Set[01.1977 - 08.1978] RT119..3HC BLACK,BLACK |
90467-08114-11 |
US $3.20 |
||
| replacement | |||||
|
68830B
|
68830B
90467-08114-20
Clip (For Center Pillar Garnish Panel, Upper)
[01.1977 - 08.1978] RT119..3HC BLACK,BLACK |
90467-08114-20 |
— | ||
|
68830B
|
68830B
90467-08114-13 Clip, Rear Floor Carpet SetREAR FLOOR MAT SET [08.1973 - 01.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD GRAY,GRAY |
90467-08114-13 |
US $3.20 |
||
| replacement | |||||
|
68830B
|
68830B
90467-08114-20
Clip (For Center Pillar Garnish Panel, Upper)
[08.1973 - 01.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD GRAY,GRAY |
90467-08114-20 |
— | ||
|
68830B
|
68830B
90467-08114-25
Clip, Rear Floor Carpet Set
[01.1977 - 08.1978] RT119..3HC BEIGE,BEIGE |
90467-08114-25 |
— | ||
| replacement | |||||
|
68830B
|
68830B
90467-08114-20
Clip (For Center Pillar Garnish Panel, Upper)
[01.1977 - 08.1978] RT119..3HC BEIGE,BEIGE |
90467-08114-20 |
— | ||
|
68830B
|
68830B
90467-08114-53 Clip (For Center Pillar Garnish Panel, Upper)REAR FLOOR CARPET SET [01.1977 - 08.1978] RT119..3HC GRAY,GRAY |
90467-08114-53 |
US $3.20 |
||
| replacement | |||||
|
68830B
|
68830B
90467-08114-20
Clip (For Center Pillar Garnish Panel, Upper)
[01.1977 - 08.1978] RT119..3HC GRAY,GRAY |
90467-08114-20 |
— | ||
|
68834
|
68834
68807-21010
Bar, Back Door Torsion, Rh
[08.1973 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
68807-21010 |
— | ||
| replacement | |||||
|
68834
|
68834
68833-21010
Bar, Back Door Torsion, Rh
[08.1973 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
68833-21010 |
— | ||
|
68834
|
68834
68807-21020 Bar, Back Door Torsion, RhBACK DOOR TORSION, RH [03.1974 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD FOR W/REAR WIPER |
68807-21020 |
US $40.62 |
||
| replacement | |||||
|
68834
|
68834
68833-21010
Bar, Back Door Torsion, Rh
[03.1974 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD FOR W/REAR WIPER |
68833-21010 |
— | ||
|
68834
|
68834
68833-21010
Bar, Back Door Torsion, Rh
[11.1976 - 08.1978] RT119..3HC |
68833-21010 |
— | ||
|
68835
|
68835
68834-21010
Bar, Back Door Torsion, Lh
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
68834-21010 |
— | ||
|
68835
|
68835
68834-21020 Bar, Back Door Torsion, LhBACK DOOR TORSION, LH [03.1974 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD FOR W/REAR WIPER |
68834-21020 |
US $33.20 |
||
| replacement | |||||
|
68835
|
68835
68834-21010
Bar, Back Door Torsion, Lh
[03.1974 - 11.1976] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD FOR W/REAR WIPER |
68834-21010 |
— | ||
|
68840
|
68840
68820-21020
Hinge Assy, Back Door, Lh
[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
68820-21020 |
— | ||
|
68840
|
68840
68820-21040
Hinge Assy, Back Door, Lh
[03.1974 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD FOR W/REAR WIPER |
68820-21040 |
— | ||
|
68840A
|
68840A
68842-21020 Cover, Back Door Hinge, Lh[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD |
68842-21020 |
US $37.42 |
||
| replacement | |||||
|
68840A
|
68840A
68842-21020-03
Cover, Back Door Hinge, Lh
[08.1973 - 09.1975] RT118..4F;RT105..3FC..4D;RT104..3FC..STD |
68842-21020-03 |
— | ||
|
68840A
|
68840A
68842-21020-03
Cover, Back Door Hinge, Lh
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D GRAY,GRAY |
68842-21020-03 |
— | ||
|
68840A
|
68840A
68842-21020-05
Cover, Back Door Hinge, Lh
[09.1975 - 01.1977] RT119..3HC;RT105..3FC..4D BEIGE,BEIGE |
68842-21020-05 |
— | ||
|
68840A
|
68840A
68842-21020-13
Cover, Back Door Hinge, Lh
[01.1977 - 08.1978] RT119..3HC GRAY,GRAY |
68842-21020-13 |
— | ||
|
68840A
|
68840A
68842-21020-15
Cover, Back Door Hinge, Lh
[01.1977 - 08.1978] RT119..3HC BEIGE,BEIGE |
68842-21020-15 |
— | ||
|
69350
|
69350
69350-21010
Lock Assy, Back Door
[08.1973 - 10.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
69350-21010 |
— | ||
|
69350
|
69350
69350-21020 Lock Assy, Back DoorBACK DOOR [10.1977 - 08.1978] RT119..3HC |
69350-21020 |
US $69.01 |
||
|
69449
|
69449
64949-21020 Adjuster, Back Door Lock Control Link[08.1973 - 08.1978] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
64949-21020 |
US $8.74 |
||
|
69490
|
69490
69430-15010 Striker Assy, Back Door LockBACK DOOR LOCK [10.1977 - 08.1978] RT119..3HC |
69430-15010 |
US $19.22 |
||
|
69490
|
69490
69451-21010
Striker Assy, Back Door Lock
[08.1973 - 10.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD |
69451-21010 |
— | ||
|
69490B
|
69490B
90541-06002
Cushion(For Back Door Lock Striker)
[10.1977 - 08.1978] RT119..3HC |
90541-06002 |
— | ||
| replacement | |||||
|
69490B
|
69490B
90541-06019 Cushion(For Back Door Lock Striker)[10.1977 - 08.1978] RT119..3HC |
90541-06019 |
US $2.88 |
||
|
69494
|
69494
69469-91256
Shim, Back Door Lock Striker
[08.1973 - 10.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD T=1.0 |
69469-91256 |
— | ||
|
69494
|
69494
69469-91257
Shim, Back Door Lock Striker
[08.1973 - 10.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD T=2.0 |
69469-91257 |
— | ||
| replacement | |||||
|
69494
|
69494
69469-91256
Shim, Back Door Lock Striker
[08.1973 - 10.1977] RT118..4F;RT119..3HC;RT105..3FC..4D;RT104..3FC..STD T=2.0 |
69469-91256 |
— | ||
|
69768
|
69768
69768-21010 Snap, Rod(For Door Lock)BACK DOOR LOCK CONTROL LINK [08.1977 - 08.1978] RT119..3HC |
69768-21010 |
US $5.53 |
||
|
9165140820
|
9165140820
91651-40820 Bolt |
91651-40820 |
from US $1.06 |
||
|
9166140616
|
9166140616
91661-40616 New Genuine Part |
91661-40616 |
US $1.28 |
||
|
9166160620
|
9166160620
91661-60620 New Genuine Part |
91661-60620 |
US $2.18 |
||
|
9323925010
|
9323925010
93239-25010 SCREW |
93239-25010 |
from US $0.76 |
||
|
9354015020
|
9354015020
93540-15020 Screw |
93540-15020 |
from US $1.60 |
||
|
9461410600
|
9461410600
94614-10600
Washer (For Primary Regulator Valve)
|
94614-10600 |
— | ||
| replacement | |||||
|
9461410600
|
9461410600
94613-10601 Washer (For Primary Regulator Valve) |
94613-10601 |
US $1.12 |
||
