Fuel Injection System ([10.1983 - ] (8310- )1S#,3SGELU) Diagram Toyota CORONA
- Year
- 1985 - 1987
- Sales region
- Japan
- Frame
- ST162
- grade
- GT
- body
- 4D
- ENGINE
- 3SGELU
- TRANSMISSION
- MTM
- Model
- CORONA
- From
- 08.1985
- To
- 11.1987
- Gear Shift Type
- 5F
- Vehicle Model
- Corona
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
23091
|
23091
23091-74040 Tube Sub-Assy, Fuel Pump[08.1985 - 11.1987] 1SELU,3SGELU..ST16# |
23091-74040 |
US $94.64 |
||
|
23206A
|
23206A
23206-74100 Bracket, Fuel Pump[08.1985 - 11.1987] 1SELU,3SGELU..ST16# |
23206-74100 |
US $107.74 |
||
|
23206B
|
23206B
77169-20020 Gasket, Fuel Pump Bracket[08.1985 - 11.1987] 1SELU,3SGELU..ST16# |
77169-20020 |
US $11.50 |
||
|
23217A
|
23217A
23217-16030 Filter, Fuel Pump[08.1985 - 11.1987] 1SELU,3SGELU..ST16# DENSO |
23217-16030 |
US $9.44 |
||
|
23217A
|
23217A
23217-16042 Filter, Fuel Pump[08.1985 - 09.1985] 1SELU,3SGELU..ST16# AISAN |
23217-16042 |
US $11.18 |
||
|
23217A
|
23217A
23217-16043 Filter, Fuel Pump[09.1985 - 11.1987] 1SELU,3SGELU..ST16# AISAN |
23217-16043 |
US $8 |
||
|
23220P
|
23220P
23220-16082 Pump Assy, Fuel[09.1985 - 02.1986] 1SELU,3SGELU..ST16# AISAN |
23220-16082 |
US $515.42 |
||
| replacement | |||||
|
23220P
|
23220P
23220-16430 Pump Assy, FuelFUEL [09.1985 - 02.1986] 1SELU,3SGELU..ST16# AISAN |
23220-16430 |
US $501.45 |
||
|
23220P
|
23220P
23220-16083 Pump Assy, Fuel[02.1986 - 08.1986] 1SELU,3SGELU..ST16# AISAN |
23220-16083 |
US $567.84 |
||
| replacement | |||||
|
23220P
|
23220P
23220-16430 Pump Assy, FuelFUEL [02.1986 - 08.1986] 1SELU,3SGELU..ST16# AISAN |
23220-16430 |
US $501.45 |
||
|
23220P
|
23220P
23220-16084
Pump Assy, Fuel
[08.1986 - 11.1987] 1SELU,3SGELU..ST16# AISAN |
23220-16084 |
— | ||
| replacement | |||||
|
23220P
|
23220P
23220-16430 Pump Assy, FuelFUEL [08.1986 - 11.1987] 1SELU,3SGELU..ST16# AISAN |
23220-16430 |
US $501.45 |
||
|
23220P
|
23220P
23220-16190 Pump Assy, Fuel[08.1986 - 11.1987] 1S#,3SGELU..ST150,16# DENSO |
23220-16190 |
US $534.80 |
||
|
23220P
|
23220P
23220-19015
Pump Assy, Fuel
[06.1985 - 08.1986] 1S#,3SGELU..ST150,16# DENSO |
23220-19015 |
— | ||
| replacements | |||||
|
23220P
|
23220P
23220-16190 Pump Assy, Fuel[06.1985 - 08.1986] 1S#,3SGELU..ST150,16# DENSO |
23220-16190 |
US $534.80 |
||
|
23220P
|
23220P
23249-43080 Rubber, Cushion(For Fuel Pump)[06.1985 - 08.1986] 1S#,3SGELU..ST150,16# DENSO |
23249-43080 |
from US $23.41 |
||
|
23229
|
23229
23229-16010 Clip(For Fuel Pump Filter)[10.1983 - 11.1987] 1S#,3SGELU..ST150,16# |
23229-16010 |
from US $0.84 |
||
| replacement | |||||
|
23229
|
23229
23219-03010 Clip(For Fuel Pump Filter)[10.1983 - 11.1987] 1S#,3SGELU..ST150,16# |
23219-03010 |
US $2.55 |
||
|
23233
|
23233
23239-16010 Hose, Fuel Pump[08.1985 - 11.1987] 1SELU,3SGELU..ST16# |
23239-16010 |
from US $1.87 |
||
|
23233B
|
23233B
90467-13001
Clamp Or Clip, Hose(For Water By-Pass Hose)
[10.1983 - 11.1987] 1S#,3SGELU..ST150,16# |
90467-13001 |
— | ||
| replacement | |||||
|
23233B
|
23233B
96135-51300 Clamp, Hose[10.1983 - 11.1987] 1S#,3SGELU..ST150,16# |
96135-51300 |
from US $1.92 |
||
|
23249
|
23249
23249-16010
Rubber, Cushion(For Fuel Pump)
[06.1985 - 09.1985] 1S#,3SGELU..ST150,16# AISAN |
23249-16010 |
— | ||
|
23249
|
23249
23249-43080 Rubber, Cushion(For Fuel Pump)[06.1985 - 09.1985] 1S#,3SGELU..ST150,16# DENSO |
23249-43080 |
from US $23.41 |
||
|
9015950157
|
9015950157
90159-50157 SCREW WWASHER |
90159-50157 |
from US $1.92 |
||
|
9046206015
|
9046206015
90462-06015 New Genuine Part |
90462-06015 |
US $6.99 |
||
|
9165540820
|
9165540820
91655-40820
New Genuine Part
|
91655-40820 |
— | ||
| replacement | |||||
|
9165540820
|
9165540820
91653-40820 BOLT, W/WASHER |
91653-40820 |
US $1.76 |
||
|
9411540400
|
9411540400
94115-40400
NUT
|
94115-40400 |
— | ||
| replacement | |||||
|
9411540400
|
9411540400
90076-01001 NUT |
90076-01001 |
US $2.08 |
||
|
9411540500
|
9411540500
94115-40500 Nut(For Lpg Filter Stud Bolt Set) |
94115-40500 |
US $1.76 |
||
|
9451100400
|
9451100400
94511-00400 WASHERSPRING |
94511-00400 |
US $3.20 |
||
|
9451100500
|
9451100500
94511-00500 Washer, Cover Set, No.2 |
94511-00500 |
from US $0.24 |
||
