Back Door Lock & Handle ([02.1992 - ] (9202- )LB) Diagram Toyota CORONA
- Year
- 1992 - 1996
- Sales region
- Japan
- Frame
- ST190
- grade
- TYPE1
- body
- LB
- ENGINE
- 4SFE
- TRANSMISSION
- MTM
- Model
- CORONA
- From
- 02.1992
- To
- 01.1996
- Vehicle Model
- Corona
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
68606
|
68606
64606-20080
Lever Sub-Assy, Luggage Door Lock Open
[02.1992 - 08.1995] ST190,191..LB |
64606-20080 |
— | ||
| replacement | |||||
|
68606
|
68606
64606-20081
Lever Sub-Assy, Luggage Door Lock Open
[02.1992 - 08.1995] ST190,191..LB |
64606-20081 |
— | ||
|
68606
|
68606
64606-20081
Lever Sub-Assy, Luggage Door Lock Open
[08.1995 - 01.1996] ST190,191..LB |
64606-20081 |
— | ||
|
68607
|
68607
64607-20800
Cable Sub-Assy, Back Door Lock Control
[02.1992 - 01.1996] ST190,191..LB |
64607-20800 |
— | ||
|
68801D
|
68801D
68801-20070 Hinge Sub-Assy, Back Door, Rh[02.1992 - 01.1996] ST190,191..LB |
68801-20070 |
US $28.39 |
||
|
68802C
|
68802C
68801-20070 Hinge Sub-Assy, Back Door, Rh[02.1992 - 01.1996] ST190,191..LB |
68801-20070 |
US $28.39 |
||
|
68838
|
68838
68838-20060
Pad, Back Door Hinge, No.1
[02.1992 - 01.1996] ST190,191..LB |
68838-20060 |
— | ||
|
68945
|
68945
68945-20040 Bracket, Back Door Damper Stay, Upper Rh[02.1992 - 01.1996] ST190,191..LB |
68945-20040 |
US $8.30 |
||
|
68946
|
68946
68946-20010 Bracket, Back Door Damper Stay, Upper Lh[02.1992 - 01.1996] ST190,191..LB |
68946-20010 |
US $8.30 |
||
|
68950C
|
68950C
68950-80019 Stay Assy, Back Door, Rh[02.1992 - 01.1996] ST190,191..LB |
68950-80019 |
US $171.81 |
||
|
68950C
|
68950C
68950-80020 Stay Assy, Back Door, Rh[02.1992 - 01.1996] ST190,191..LB ｱﾘ(ﾘﾔ ｽﾎﾟｲﾗ) |
68950-80020 |
US $171.81 |
||
|
68960
|
68960
68960-29845 Stay Assy, Back Door, Lh[02.1992 - 01.1996] ST190,191..LB |
68960-29845 |
US $171.81 |
||
|
68960
|
68960
68960-29855 Stay Assy, Back Door, Lh[02.1992 - 01.1996] ST190,191..LB ｱﾘ(ﾘﾔ ｽﾎﾟｲﾗ) |
68960-29855 |
US $171.81 |
||
|
69350
|
69350
69350-20070 Lock Assy, Back Door[02.1992 - 01.1996] ST190,191..LB |
69350-20070 |
US $78.62 |
||
|
69377C
|
69377C
69759-20040 Snap, Auxiliary Catch Release Lever Control Link[02.1992 - 01.1996] ST190,191..LB |
69759-20040 |
US $4.32 |
||
|
69430C
|
69430C
69430-20130
Striker Assy, Back Door Lock
[02.1992 - 01.1996] ST190,191..LB |
69430-20130 |
— | ||
|
9010506184
|
9010506184
90105-06184 BOLT WASHER BASED |
90105-06184 |
US $1.12 |
||
|
9010506204
|
9010506204
90105-06204 New Genuine Part |
90105-06204 |
US $1.92 |
||
|
9010508251
|
9010508251
90105-08251 New Genuine Part |
90105-08251 |
US $2.56 |
||
|
9015980050
|
9015980050
90159-80050 New Genuine Part |
90159-80050 |
US $1.60 |
||
|
9017906097
|
9017906097
90179-06097 Clip(For Front Bumper), No.1 |
90179-06097 |
US $0.86 |
||
| replacement | |||||
|
9017906097
|
9017906097
90179-06206 Nut |
90179-06206 |
from US $0.78 |
||
|
9017908096
|
9017908096
90179-08096 NUT |
90179-08096 |
from US $1.46 |
||
| replacement | |||||
|
9017908096
|
9017908096
90080-18061 New Genuine Part |
90080-18061 |
US $4.47 |
||
|
9095901209
|
9095901209
90959-01209 Clamp, No.1(For Luggage Door Lock Control Cable) |
90959-01209 |
US $1.46 |
||
|
9151260618
|
9151260618
91512-60618 Bolt, W/washer(For Repair Actuator Set) |
91512-60618 |
US $1.16 |
||
| replacement | |||||
|
9151260618
|
9151260618
91621-60620 Bolt, W/washer(For Repair Actuator Set) |
91621-60620 |
US $0.44 |
||
|
9165160614
|
9165160614
91651-60614 Bolt |
91651-60614 |
from US $1.12 |
||
