Clutch Pedal & Flexible Hose ([09.1990 - ] (9009- )MTM) Diagram Toyota CORSA/ TERCEL
- Year
- 1990 - 1994
- Sales region
- Japan
- Frame
- EL43
- grade
- VX
- ENGINE
- 5EFE
- TRANSMISSION
- MTM
- From
- 09.1990
- To
- 09.1994
- Gear Shift Type
- 5F
- No.of Doors
- 4DS
- Vehicle Model
- Tersel
- Fuel Induction
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-16090 Pedal Sub-Assy, Clutch[09.1990 - 09.1994] EL4#,NL40..MTM |
31301-16090 |
US $33.63 |
||
|
31301A
|
31301A
90507-14035
Spring(For Clutch Pedal)
[09.1990 - 09.1994] EL4#,NL40..MTM |
90507-14035 |
— | ||
|
31301B
|
31301B
90541-06032
Cushion, No.1(For Clutch Pedal)
[09.1990 - 08.1992] EL4#,NL40..MTM |
90541-06032 |
— | ||
| replacement | |||||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[09.1990 - 08.1992] EL4#,NL40..MTM |
90541-06036 |
from US $0.98 |
||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[08.1992 - 09.1994] EL4#,NL40..MTM |
90541-06036 |
from US $0.98 |
||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[09.1990 - 09.1994] EL4#,NL40..MTM |
90386-13015 |
from US $0.72 |
||
|
31301F
|
31301F
90101-08052 Bolt(For Clutch Pedal Stopper)[09.1990 - 09.1994] EL4#,NL40..MTM |
90101-08052 |
US $1.40 |
||
|
31321
|
31321
31321-14020 Pad, Clutch Pedal[09.1990 - 09.1994] EL4#,NL40..MTM |
31321-14020 |
from US $3.18 |
||
| replacement | |||||
|
31321
|
31321
31321YE010
PAD PEDAL
[09.1990 - 09.1994] EL4#,NL40..MTM |
31321YE010 |
— | ||
|
31324
|
31324
90101-10015 Shaft, Clutch Pedal[09.1990 - 09.1994] EL4#,NL40..MTM |
90101-10015 |
from US $2.56 |
||
| replacement | |||||
|
31324
|
31324
90101100151 Bolt, Hexagon[09.1990 - 09.1994] EL4#,NL40..MTM |
90101100151 |
US $1.11 |
||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[09.1990 - 09.1994] EL4#,NL40..MTM |
90387-10003 |
from US $4.11 |
||
|
31453A
|
31453A
90249-08243 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[09.1990 - 09.1994] EL4#,NL40..MTM 長さ＝３０ |
90249-08243 |
US $2.80 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[09.1990 - 09.1994] EL4#,NL40..MTM |
90386-08002 |
from US $3.84 |
||
|
55107A
|
55107A
55107-16070 Support Sub-Assy, Clutch Pedal[09.1990 - 09.1994] EL4#,NL40..MTM |
55107-16070 |
US $30.43 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.88 |
||
|
9165660818
|
9165660818
91656-60818 Clamp Or Clip, Hose(for Radiator Outlet No.1) |
91656-60818 |
US $1.89 |
||
| replacement | |||||
|
9165660818
|
9165660818
91651-B0814 Bolt with washer |
91651-B0814 |
from US $0.88 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $2.08 |
||
|
9412040800
|
9412040800
94120-40800 Nut(For Clutch Pedal Stopper) |
94120-40800 |
US $1.44 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.76 |
||
