Throttle Link & Valve Lever (Atm) ([08.1984 - ] (8408- )LX7#..4FC) Diagram Toyota CRESSIDA/ CRESSIDA WAGON
- Year
- 1984 - 1988
- Sales region
- General
- Frame
- LX70
- grade
- GL
- body
- SED
- ENGINE
- 2L
- TRANSMISSION
- ATM
- Model
- CRESSIDA
- From
- 08.1984
- To
- 08.1988
- Gear Shift Type
- 4FC
- Vehicle Model
- Cressida
- Driver's Position
- LHD
- Fuel Induction
- DSL
- Destination
- GEN
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35520
|
35520
35520-22100 Cable Assy, ThrottleTHROTTLE [08.1984 - 08.1988] LX70..4FC |
35520-22100 |
US $69.74 |
||
|
35520B
|
35520B
90301-09004
Ring, O(For Throttle Cable)
[08.1984 - 08.1988] GX71,LX7#,MX7#,RX70,72..4FC |
90301-09004 |
— | ||
|
35525
|
35525
35525-22080 Bracket, Throttle CableTHROTTLE CABLE [08.1984 - 08.1988] LX70..4FC |
35525-22080 |
US $21.40 |
||
|
9161161014
|
9161161014
91611-61014
New Genuine Part
|
91611-61014 |
— | ||
| replacement | |||||
|
9161161014
|
9161161014
91612-B1014 BOLT WWASHER |
91612-B1014 |
US $1.16 |
||
|
9165140610
|
9165140610
91651-40610 RIVET |
91651-40610 |
US $2.87 |
||
|
9461111001
|
9461111001
94611-11001 Plate, Rear Seat Back Stopper |
94611-11001 |
US $1.43 |
||
|
9622110710
|
9622110710
96221-10710 Clamp, Throttle Cable, No.2 |
96221-10710 |
US $2.18 |
||
