Rear Axle Shaft & Hub ([08.1984 - ] (8408- )GX71,LX71,MX73,RX71,73) Diagram Toyota CRESSIDA/ CRESSIDA WAGON
- Year
- 1984 - 1986
- Sales region
- General
- Frame
- LX71
- grade
- GL
- body
- SED
- ENGINE
- 2LT
- TRANSMISSION
- MTM
- Model
- CRESSIDA
- From
- 08.1984
- To
- 08.1986
- Gear Shift Type
- 5F
- Vehicle Model
- Cressida
- Driver's Position
- LHD
- Fuel Induction
- TD
- Destination
- EUR
- Destination 2
- EUG
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04438C
|
04438C
04437-22010
Boot Kit, Rear Drive Shaft
[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 INNER,NTN |
04437-22010 |
— | ||
|
04438C
|
04438C
04437-22020
Boot Kit, Rear Drive Shaft
[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 OUTER,NTN |
04437-22020 |
— | ||
|
42340
|
42340
42340-24020 Shaft Assy, Rear Drive[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42340-24020 |
US $741.10 |
||
|
42341
|
42341
42341-24020 Shaft, Rear Drive[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42341-24020 |
US $126.67 |
||
|
42341A
|
42341A
90520-26004 Ring, Snap (For Rear Drive Shaft)[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 ID=26.1,OD=31.7,T=1.5,NTN |
90520-26004 |
US $4.37 |
||
|
42341A
|
42341A
90520-26005 Ring, Snap (For Rear Drive Shaft)[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 ID=26.4,OD=32.4,T=2.5,NTN |
90520-26005 |
US $4.37 |
||
|
42343
|
42343
42343-22010
Cover, Outboard Joint End
[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42343-22010 |
— | ||
|
42344
|
42344
42344-22010 Cover, Rear Axle Inboard Joint End[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42344-22010 |
US $8.15 |
||
|
42345
|
42345
42345-22010 Clamp, Rear Drive Shaft Boot[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42345-22010 |
US $8.15 |
||
|
42346
|
42346
42346-22010 Clamp (For Rear Drive Shaft Outboard Joint Boot)[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42346-22010 |
US $6.64 |
||
|
42347
|
42347
42347-22010 Clamp (For Rear Drive Shaft Inboard Joint Boot)[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42347-22010 |
US $7.86 |
||
|
42350
|
42350
42350-22010 Joint Assy, Rear Drive Shaft Outboard[08.1984 - 08.1986] GX71,LX71,MX73 NTN |
42350-22010 |
US $243.15 |
||
| replacement | |||||
|
42350
|
42350
42350-22030 Joint Assy, Rear Drive Shaft Outboard[08.1984 - 08.1986] GX71,LX71,MX73 NTN |
42350-22030 |
US $241.70 |
||
|
42350A
|
42350A
90521-79001 Ring, Hole Snap[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
90521-79001 |
US $3.67 |
||
|
42360
|
42360
42360-22010 Joint Assy, Rear Drive Shaft Inboard[08.1984 - 08.1988] GX71,LX71,MX73,RX71,73 NTN |
42360-22010 |
US $260.62 |
||
|
9017010191
|
9017010191
90170-10191 Nut(For Rear Drive Shaft) |
90170-10191 |
US $1.97 |
||
|
9451101000
|
9451101000
94511-01000 Washer(For Rear Drive Shaft) |
94511-01000 |
US $1.97 |
||
