Brake Booster & Vacuum Tube ([08.1984 - 05.1987] (8408-8705)RX70,71 ; (8705- )RX73) Diagram Toyota CRESSIDA/ CRESSIDA WAGON
- Year
- 1984 - 1987
- Sales region
- Europe
- Frame
- RX70
- grade
- GL
- body
- SED
- ENGINE
- 21R
- TRANSMISSION
- MTM
- Model
- CRESSIDA
- From
- 08.1984
- To
- 05.1987
- Gear Shift Type
- 5F
- Vehicle Model
- Cressida
- Driver's Position
- RHD
- Fuel Induction
- CBR
- Destination
- GEN
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44730F
|
44730F
90404-51237 Union, No.3[08.1984 - 05.1987] RX70,71 |
90404-51237 |
US $9.68 |
||
|
44773F
|
44773F
44773-22400 Hose, Union To Check ValveUNION TO CHECK VALVE [08.1984 - 08.1988] RX70,72..RHD |
44773-22400 |
US $26.06 |
||
|
44773G
|
44773G
90467-16002
Clip(Vaccum Transmitting Hose No.1)
[08.1984 - 08.1988] GX71,RX70,72..RHD; LX7#,MX7#..LHD |
90467-16002 |
— | ||
| replacement | |||||
|
44773G
|
44773G
96133-41500 Clamp Or Clip(For Air Hose, No.5)[08.1984 - 08.1988] GX71,RX70,72..RHD; LX7#,MX7#..LHD |
96133-41500 |
from US $2.32 |
||
|
9011906234
|
9011906234
90119-06234 New Genuine Part |
90119-06234 |
US $1.75 |
||
