Switch & Relay & Computer ([08.2008 - ] ENGINE & TRANSMISSION (0808- )) Diagram Toyota CROWN COMFORT
- Year
- 2008 - 2018
- Sales region
- General
- Frame
- TSS10
- ENGINE
- 1TRFPE
- TRANSMISSION
- ATM
- Model
- CROWN COMFORT
- From
- 08.2008
- Gear Shift Type
- 4FC
- Vehicle Model
- Crown Comfort
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[09.2007 - 04.2011] TSS10,YXS10 |
83530-28020 |
from US $29.33 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [09.2007 - 04.2011] TSS10,YXS10 |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[09.2007 - 04.2011] TSS10,YXS10 |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [04.2011 -] TSS10 YAZAKI |
83530-60020 |
from US $25.21 |
||
|
84540
|
84540
84540-30270 Switch Assy, Neutral Start[08.2008 -] TSS10 |
84540-30270 |
US $145.44 |
||
|
89438
|
89438
89438-33010 Switch, Power Steering Oil Pressure[08.2008 - 11.2016] TSS10 |
89438-33010 |
from US $34.56 |
||
|
89438
|
89438
89438-71010 Switch, Power Steering Oil Pressure[11.2016 -] TSS10 |
89438-71010 |
from US $29.58 |
||
|
89454C
|
89454C
89454-43010 Sensor, Fuel Gas Temperature[08.2008 -] TSS10 |
89454-43010 |
US $36.78 |
||
|
89458D
|
89458D
89458-43010 Sensor, Fuel Pressure[08.2008 -] TSS10 |
89458-43010 |
US $85.84 |
||
|
89465
|
89465
89465-43160 Sensor, Oxygen[08.2008 -] TSS10 |
89465-43160 |
from US $139.12 |
||
|
89467B
|
89467B
89467-43010 Sensor, Air Fuel Ratio[10.2013 -] TSS10 |
89467-43010 |
US $190.08 |
||
|
89467B
|
89467B
89467-43020 Sensor, Air Fuel Ratio[08.2008 - 10.2013] TSS10 |
89467-43020 |
US $228.96 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[08.2008 -] TSS10 |
89615-20090 |
from US $36.02 |
||
|
9155180830
|
9155180830
91551-80830 Bolt, Compressor, No.2 |
91551-80830 |
from US $0.88 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
