Switch & Relay & Computer ([12.2009 - ] ENGINE & TRANSMISSION (0912- )GRS20#) Diagram Toyota CROWN/ MAJESTA
- Year
- 2009 - 2012
- Sales region
- General
- Frame
- GRS202
- grade
- ROYEX
- ENGINE
- 3GRFE
- TRANSMISSION
- ATM
- Model
- CROWN (CHINA)
- From
- 12.2009
- To
- 07.2012
- Gear Shift Type
- 6FC
- Vehicle Model
- Crown
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[12.2009 - 07.2012] GRS20# DENSO |
83530-28020 |
from US $26.60 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [12.2009 - 07.2012] GRS20# DENSO |
83530-60020 |
from US $25.55 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[12.2009 - 07.2012] GRS20# DENSO |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [12.2009 - 07.2012] GRS20# YAZAKI |
83530-60020 |
from US $25.55 |
||
|
84540
|
84540
84540-71010 Switch Assy, Neutral Start[12.2009 - 07.2012] GRS20#,UZS200 |
84540-71010 |
from US $112.48 |
||
|
89465
|
89465
89465-0P010
Sensor, Oxygen
[12.2009 - 09.2010] GRS20# |
89465-0P010 |
— | ||
|
89465
|
89465
89465-0P020
Sensor, Oxygen
[09.2010 - 07.2012] GRS20# |
89465-0P020 |
— | ||
|
89467B
|
89467B
89467-22050 Sensor, Air Fuel RatioAIR FUEL RATIO [09.2010 - 07.2012] GRS202 |
89467-22050 |
US $188.64 |
||
|
89467B
|
89467B
89467-30040 Sensor, Air Fuel Ratio[12.2009 - 09.2010] GRS202 |
89467-30040 |
from US $210.89 |
||
|
89467C
|
89467C
89467-22040 Sensor, Air Fuel RatioAIR FUEL RATIO [09.2010 - 07.2012] GRS20# |
89467-22040 |
from US $188.64 |
||
|
89467C
|
89467C
89467-30030 Sensor, Air Fuel Ratio[12.2009 - 09.2010] GRS20# |
89467-30030 |
from US $200.69 |
||
|
89491
|
89491
89491-30060
Sensor, Engine Oil Level
[12.2009 - 10.2011] GRS20# |
89491-30060 |
— | ||
| replacement | |||||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[12.2009 - 10.2011] GRS20# |
89491-30061 |
from US $140.60 |
||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[11.2011 - 07.2012] GRS20# |
89491-30061 |
from US $140.60 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[12.2009 - 07.2012] GRS20#,UZS200 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[12.2009 - 07.2012] GRS20#,UZS200 |
89615-20090 |
from US $36.02 |
||
|
90105C0088
|
90105C0088
90105-C0088
New Genuine Part
|
90105-C0088 |
— | ||
|
90119C0204
|
90119C0204
90119-C0204
New Genuine Part
|
90119-C0204 |
— | ||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.84 |
||
|
8271522850
|
8271522850
82715-22850 Bracket,wiring Harness Clamp |
82715-22850 |
US $2.62 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
|
9167380610
|
9167380610
91673-80610 New Genuine Part |
91673-80610 |
US $0.44 |
||
