Rear Axle Shaft & Hub ([04.2000 - ] (0004- )GS171) Diagram Toyota CROWN/ MAJESTA
- Year
- 2001 - 2003
- Sales region
- Japan
- Frame
- GS171
- grade
- ATHE
- body
- WG
- ENGINE
- 1GFE
- TRANSMISSION
- ATM
- Model
- CROWN/ CROWN MAJESTA
- From
- 08.2001
- To
- 12.2003
- Gear Shift Type
- 4FC
- Fuel Induction
- HTWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04438C
|
04438C
04437-22150 Boot Kit, Rear Drive Shaft, Rh[08.2001 - 12.2003] GS171 |
04437-22150 |
US $145.60 |
||
| replacement | |||||
|
04438C
|
04438C
04429-26050 Boot Kit, Rear Drive Shaft, In & Outboard Joint, RhREAR DRIVE SHAFT, IN & OUTBOARD JOINT, RH [08.2001 - 12.2003] GS171 |
04429-26050 |
US $120.85 |
||
|
04438D
|
04438D
04437-28021
Boot Kit, Rear Drive Shaft Inboard Joint, Rh
[08.2001 - 12.2003] GS171 |
04437-28021 |
— | ||
| replacement | |||||
|
04438D
|
04438D
04439-26020
Boot Kit, Front Drive Shaft Inboard Joint
[08.2001 - 12.2003] GS171 |
04439-26020 |
— | ||
|
42330
|
42330
42330-22050 Shaft Assy, Rear Drive, Rh[08.2001 - 12.2003] GS171 |
42330-22050 |
US $835.74 |
||
|
42340B
|
42340B
42340-22130 Shaft Assy, Rear Drive, Lh[08.2001 - 12.2003] GS171 |
42340-22130 |
US $797.89 |
||
|
42341A
|
42341A
90520-26028 Ring, Snap (For Rear Drive Shaft)[08.2001 - 12.2003] GS171 |
90520-26028 |
from US $1.97 |
||
|
42346A
|
42346A
42345-14010 Clamp, Rear Drive Shaft Boot[08.2001 - 12.2003] GS171 内径＝３５．７５ |
42345-14010 |
US $12.54 |
||
|
42346B
|
42346B
90949-01473 Clamp (For Rear Drive Shaft Outboard Joint Boot)[08.2001 - 12.2003] GS171 |
90949-01473 |
US $2.91 |
||
|
42347A
|
42347A
42345-14010 Clamp, Rear Drive Shaft Boot[08.2001 - 12.2003] GS171 内径＝３５．７５ |
42345-14010 |
US $12.54 |
||
|
42347B
|
42347B
42345-30010 Clamp (For Rear Drive Shaft Inboard Joint Boot)[08.2001 - 12.2003] GS171 |
42345-30010 |
US $12.58 |
||
|
42360
|
42360
42360-30040 Joint Assy, Rear Drive Shaft Inboard[08.2001 - 12.2003] GS171 |
42360-30040 |
US $198.02 |
||
|
42370A
|
42370A
42370-29177 Shaft Assy, Rear Drive Outboard Joint, Rh[08.2001 - 12.2003] GS171 |
42370-29177 |
US $698.88 |
||
| replacement | |||||
|
42370A
|
42370A
42370-29605 Shaft Assy, Rear Drive Outboard Joint, Rh[08.2001 - 12.2003] GS171 |
42370-29605 |
US $698.88 |
||
|
42380
|
42380
42380-29077 Shaft Assy, Rear Drive Outboard Joint, Lh[08.2001 - 12.2003] GS171 |
42380-29077 |
US $677.04 |
||
| replacement | |||||
|
42380
|
42380
42380-29185 Shaft Assy, Rear Drive Outboard Joint, Lh[08.2001 - 12.2003] GS171 |
42380-29185 |
US $677.04 |
||
|
42451A
|
42451A
42453-50010 Deflector, Rear Wheel Bearing Dust, No.1 Rh[08.2001 - 06.2007] GS171,JKS175,JZS17#,UZS17# |
42453-50010 |
US $12.36 |
||
|
42451B
|
42451B
42453-50010 Deflector, Rear Wheel Bearing Dust, No.1 Rh[08.2001 - 06.2007] GS171,JKS175,JZS17#,UZS17# |
42453-50010 |
US $12.36 |
||
|
9017010191
|
9017010191
90170-10191 Nut(For Rear Drive Shaft) |
90170-10191 |
US $1.97 |
||
|
9020110068
|
9020110068
90201-10068 New Genuine Part |
90201-10068 |
US $1.61 |
||
