Valve Body & Oil Strainer (Atm) ([09.1999 - 08.2001] A340E (9909-0108)JZS171..TWC) Diagram Toyota CROWN/ MAJESTA
- Year
- 2000 - 2001
- Sales region
- Japan
- Frame
- JZS171
- grade
- ATHE
- body
- WG
- ENGINE
- 1JZGE
- TRANSMISSION
- ATM
- Model
- CROWN/ CROWN MAJESTA
- From
- 08.2000
- To
- 08.2001
- Gear Shift Type
- 4FC
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82125K
|
82125K
82125-30470 Wire, Transmission[09.1999 - 08.2001] JZS171..4FC..TWC |
82125-30470 |
US $30.05 |
||
|
85420K
|
85420K
85420-22150 Solenoid Assy, Transmission[09.1999 - 08.2001] JZS171,173..4FC..TWC ＮＯ．１ |
85420-22150 |
US $80.08 |
||
| replacement | |||||
|
85420K
|
85420K
35250-30050 Solenoid Assy, Transmission[09.1999 - 08.2001] JZS171,173..4FC..TWC ＮＯ．１ |
35250-30050 |
from US $72.60 |
||
|
85420K
|
85420K
85420-22170 Solenoid Assy, Transmission[09.1999 - 08.2001] JZS171,173..4FC..TWC ＮＯ．２ |
85420-22170 |
US $80.08 |
||
| replacement | |||||
|
85420K
|
85420K
35250-30070 Solenoid Assy, Transmission[09.1999 - 08.2001] JZS171,173..4FC..TWC ＮＯ．２ |
35250-30070 |
from US $72.60 |
||
|
85420L
|
85420L
90301-06004 Ring, O No.3(For Transmission Solenoid)[04.2000 - 08.2001] JZS173..SED;GS171,JZS171,175,177,179,UZS17#..D4,HTWC,TWC |
90301-06004 |
from US $2.15 |
||
|
85420M
|
85420M
96721-24018 Ring, O[09.1999 - 08.2001] GS171,JZS17#,UZS17# |
96721-24018 |
from US $3.69 |
||
|
91611B0616
|
91611B0616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.84 |
||
|
3548260030
|
3548260030
35482-60030 Clamp, Temperature Sensor |
35482-60030 |
US $5.39 |
||
|
9010505005
|
9010505005
90105-05005 Bolt (For Transfer Relief Valve Plate) |
90105-05005 |
US $1.25 |
||
