Valve Body & Oil Strainer (Atm) ([09.1999 - 08.2001] A650E (9909-0108)5FC) Diagram Toyota CROWN/ MAJESTA
- Year
- 1999 - 2003
- Sales region
- Japan
- Frame
- JZS175
- grade
- ROYG
- body
- SED
- ENGINE
- 2JZFSE
- TRANSMISSION
- ATM
- Model
- CROWN/ CROWN MAJESTA
- From
- 09.1999
- To
- 12.2003
- Gear Shift Type
- 5FC
- Fuel Induction
- D4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82125K
|
82125K
82125-30460 Wire, Transmission[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC |
82125-30460 |
US $51.58 |
||
|
82125K
|
82125K
82125-50040 Wire, Transmission[08.2001 - 06.2007] JKS175,JZS175,177 |
82125-50040 |
US $48.22 |
||
|
85420K
|
85420K
35250-50010 Solenoid Assy, Transmission, No.3[04.2000 - 08.2001] JZS175..SED..ROY;JZS175,177..A,ATHG,C,ROYG ＮＯ．１; JZS175..WG..ROY |
35250-50010 |
US $211.41 |
||
|
85420K
|
85420K
35250-50030 Valve, Solenoid(S4)[08.2001 - 06.2007] JKS175,JZS171,175,177,UZS171,175..5FC ＮＯ．２ |
35250-50030 |
US $214.40 |
||
|
85420K
|
85420K
85420-30240 Valve, Solenoid(S2)[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＤＥＮＳＯ，ＮＯ．１ |
85420-30240 |
US $196.56 |
||
| replacement | |||||
|
85420K
|
85420K
35250-50010 Solenoid Assy, Transmission, No.3[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＤＥＮＳＯ，ＮＯ．１ |
35250-50010 |
US $211.41 |
||
|
85420K
|
85420K
85420-30260
Valve, Solenoid(S4)
[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＤＥＮＳＯ，ＮＯ．２ |
85420-30260 |
— | ||
| replacement | |||||
|
85420K
|
85420K
35250-50030 Valve, Solenoid(S4)[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＤＥＮＳＯ，ＮＯ．２ |
35250-50030 |
US $214.40 |
||
|
85420K
|
85420K
85420-30270
Valve, Solenoid(S4)
[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＡＩＳＩＮ，ＮＯ．２ |
85420-30270 |
— | ||
| replacement | |||||
|
85420K
|
85420K
35250-50030 Valve, Solenoid(S4)[09.1999 - 08.2001] JZS171,175,177,UZS171,175..5FC ＡＩＳＩＮ，ＮＯ．２ |
35250-50030 |
US $214.40 |
||
|
85420L
|
85420L
90301-06004 Ring, O No.3(For Transmission Solenoid)[09.1999 - 04.2000] JZS175;JZS171..SED..ROY;JZS171..ATH,ROYEX;JZS173,177,179,UZS17#..SED |
90301-06004 |
US $2.15 |
||
|
85420M
|
85420M
96721-24018 Ring, O[09.1999 - 08.2001] GS171,JZS17#,UZS17# |
96721-24018 |
US $7.17 |
||
|
9010506075
|
9010506075
90105-06075 New Genuine Part |
90105-06075 |
US $1.60 |
||
| replacement | |||||
|
9010506075
|
9010506075
91511-C0622 Strainer Bolt |
91511-C0622 |
US $1.08 |
||
|
9010506261
|
9010506261
90105-06261 Bolt(For Manual Detent Spring) |
90105-06261 |
US $0.73 |
||
|
9161160616
|
9161160616
91611-60616
Bolt(For Transaxle Case Receiver)
|
91611-60616 |
— | ||
| replacement | |||||
|
9161160616
|
9161160616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $1.19 |
||
