Steering Column & Shaft ([09.1979 - ] (7909- )) Diagram Toyota CROWN/ MAJESTA
- Year
- 1982 - 1983
- Sales region
- Japan
- Frame
- LS111
- grade
- SDX
- body
- SED
- ENGINE
- 2LT
- TRANSMISSION
- MTM
- Model
- CROWN
- From
- 08.1982
- To
- 07.1983
- Gear Shift Type
- 5F
- No.of Doors
- 4D
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44101D
|
44101D
90201-30003 Washer, Plate(For Steering Worm)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90201-30003 |
US $13.10 |
||
|
44101E
|
44101E
90301-44001
Ring, O(For Steering Worm)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90301-44001 |
— | ||
|
44101H
|
44101H
90374-30003 Bearing, Thrust Needle Roller(For Steering Worm)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90374-30003 |
US $8.91 |
||
|
44101J
|
44101J
90562-47002
Ring(For Steering Worm)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90562-47002 |
— | ||
|
44105
|
44105
44105-30060 Housing Sub-Assy, Valve[07.1982 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44105-30060 |
US $246.06 |
||
|
44105A
|
44105A
90301-32002 Ring, O(For Valve Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90301-32002 |
US $4.37 |
||
|
44105B
|
44105B
90562-30002 Ring(For Valve Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90562-30002 |
US $39.65 |
||
|
44105C
|
44105C
90410-05035 Seat, Union(For Valve Body Housing)[09.1979 - 12.1982] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90410-05035 |
US $3.49 |
||
|
44105C
|
44105C
90410-06006 Seat, Union(Pressure Control Valve Assy)[12.1982 - 07.1983] RS110..TAX; GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE |
90410-06006 |
US $2.62 |
||
|
44107
|
44107
44107-30070 Housing Sub-Assy, Power Steering GearPOWER STEERING GEAR [10.1980 - 07.1983] GS11#,LS111,MS110..(BTP,CTE,DLX,SDX,SPE)..(CBR,EFI,LPG,TD,TDE) |
44107-30070 |
US $387.30 |
||
| replacement | |||||
|
44107
|
44107
44107-30120 Housing Sub-Assy, Power Steering Gear[10.1980 - 07.1983] GS11#,LS111,MS110..(BTP,CTE,DLX,SDX,SPE)..(CBR,EFI,LPG,TD,TDE) |
44107-30120 |
US $353.81 |
||
|
44107A
|
44107A
90364-32003 Bearing, Needle Roller(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90364-32003 |
US $16.25 |
||
|
44107B
|
44107B
90301-33002 Ring, O (For Oil Pump Inner Bush)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE 内径＝３３．７，外径＝４０．７,OD=40.7,T=3.5; RS110..TAX 内径＝３３．７，外径＝４０．７,OD=40.7,T=3.5 |
90301-33002 |
from US $3.16 |
||
|
44107B
|
44107B
90301-65145 Ring, O(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE 内径＝６５．０，外径＝７０．０,OD=70,T=2.5; RS110..TAX 内径＝６５．０，外径＝７０．０,OD=70,T=2.5 |
90301-65145 |
from US $3.02 |
||
|
44107B
|
44107B
96711-19010 Ring, O(For Oil Level Gage Guide)[11.1981 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE 外径＝１３．６，内径＝９．８,OD=13,T=1.9; RS110..TAX 外径＝１３．６，内径＝９．８,OD=13,T=1.9 |
96711-19010 |
from US $2.28 |
||
|
44107C
|
44107C
90562-31002 Ring(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE 内径＝３１．７，外径＝３４．１，厚さ＝４,OD=34.1,T=4; RS110..TAX 内径＝３１．７，外径＝３４．１，厚さ＝４,OD=34.1,T=4 |
90562-31002 |
US $8.91 |
||
|
44107C
|
44107C
90562-32002 Ring(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE 内径＝３２，外径＝４０,OD=40,T=3; RS110..TAX 内径＝３２，外径＝４０,OD=40,T=3 |
90562-32002 |
US $8.21 |
||
|
44107D
|
44107D
90521-44002 Ring, Hole Snap(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90521-44002 |
US $8.21 |
||
|
44107E
|
44107E
90312-32002 Seal, Oil(For Power Steering Gear Housing)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90312-32002 |
from US $3.14 |
||
|
44108
|
44108
44108-30030 Cover Sub-Assy, Side[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44108-30030 |
US $94.64 |
||
| replacements | |||||
|
44108
|
44108
44108-30040 Cover Sub-Assy, Side[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44108-30040 |
US $96.10 |
||
|
44108
|
44108
44157-30010
Cap, Bleeder Plug(For Power Steering Gear Housing)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44157-30010 |
— | ||
|
44108
|
44108
47547-20010 Plug, Bleeder(For Release Cylinder)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
47547-20010 |
from US $3.20 |
||
|
44108A
|
44108A
90301-61001 Ring, O(For Control Shaft Tube)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90301-61001 |
US $4.66 |
||
|
44111
|
44111
44111-30050 Shaft, CrossCROSS [09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44111-30050 |
US $281.01 |
||
|
44114A
|
44114A
90562-67001
Ring(For Power Piston Nut)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90562-67001 |
— | ||
| replacement | |||||
|
44114A
|
44114A
90562-67002 Ring(For Power Piston Nut)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90562-67002 |
US $3.20 |
||
|
44114B
|
44114B
90301-63001
Ring, O(For Power Piston Nut)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90301-63001 |
— | ||
|
44114C
|
44114C
90360-06021 Ball(For Power Piston Nut)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90360-06021 |
US $2.24 |
||
|
44115
|
44115
44115-20010 Guide, Ball[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44115-20010 |
US $4.22 |
||
|
44116
|
44116
44116-20010 Clamp, Ball Guide[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44116-20010 |
US $1.75 |
||
|
44141
|
44141
44104-22011 Plug Sub-Assy, Adjuster[11.1981 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44104-22011 |
US $33.20 |
||
|
44141A
|
44141A
90301-51001 Ring, O(For Adjuster Plug)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90301-51001 |
from US $2.26 |
||
|
44141B
|
44141B
90311-19002 Seal, Oil(For Adjuster Plug)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90311-19002 |
from US $3.04 |
||
|
44141C
|
44141C
90369-22001 Bearing(For Adjuster Plug)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90369-22001 |
US $35.24 |
||
| replacement | |||||
|
44141C
|
44141C
90369-22004 Bearing(For Adjuster Plug)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90369-22004 |
US $22.89 |
||
|
44142
|
44142
44142-22010 Nut, Lock[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44142-22010 |
US $20.44 |
||
|
44142A
|
44142A
44142-22020 Nut, Lock[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44142-22020 |
US $6.29 |
||
|
44210
|
44210
44120-30081 Valve Assy, Power Steering Control[07.1982 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
44120-30081 |
US $627.54 |
||
|
44257
|
44257
45357-22010
Screw, Cross Shaft Adjusting
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
45357-22010 |
— | ||
| replacement | |||||
|
44257
|
44257
45357-60030 Screw, Cross Shaft Adjusting[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
45357-60030 |
from US $3.36 |
||
|
44257A
|
44257A
90210-10001 Washer, Seal(For Cross Shaft Adjusting Screw)[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110..BTP,CTE,DLX,ROY,SAL,SDX,SPE; RS110..TAX |
90210-10001 |
from US $5.30 |
||
|
9010910041
|
9010910041
90109-10041 Bolt, Hexagon(For Rear Caliper) |
90109-10041 |
US $3.06 |
||
| replacement | |||||
|
9010910041
|
9010910041
90119-10206 Bolt, Hexagon(For Rear Caliper) |
90119-10206 |
US $3.20 |
||
|
9011908035
|
9011908035
90119-08035 New Genuine Part |
90119-08035 |
US $2.04 |
||
|
9011910206
|
9011910206
90119-10206 Bolt, Hexagon(For Rear Caliper) |
90119-10206 |
US $3.20 |
||
|
9017010208
|
9017010208
90170-10208 NUT |
90170-10208 |
US $1.28 |
||
|
9331915008
|
9331915008
93319-15008 SCREW |
93319-15008 |
US $2.72 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.76 |
||
|
9452100500
|
9452100500
94521-00500
New Genuine Part
|
94521-00500 |
— | ||
